Pubis support 10-567
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-16
Document number: M10-567EN rev.01
1
Advertisement
Table of Contents
Related Manuals for Reison 10-567
Summary of Contents for Reison 10-567
- Page 1 Pubis support 10-567 Warning! This symbol indicates important information related to safety. Follow these instructions carefully. Read User Manual before use! It is important to fully understand the content of the user manual before attempting to use the equipment. 2021-04-16...
- Page 2 Intended use Pubis support intended for support and positioning of a patient in side position, on the operating table, during surgery. The product is to be used by medical professionals within a medical facility. Safety regulation Maximum load: 25 kg, corresponding to a patient weight of 175 kg, according to EN 60601-1 and EN 60601-2.
- Page 3 User instruction Installation Position adjustment...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
- Page 5 Spare parts Description Pcs. Article no. Post 10123 Stay 10416 Support 11865 Spring 2547 Knob 11473 Washer BRB 10,5x20x2 nylon 11870 Screw MKFX M5x12 A2 Spring 1602 Gear ring 11163 Washer 10119 Technical specification Maximum workload 25 kg, corresponding to a patient weight of 175 kg, according to EN 60601-1 and EN 60601-2 Weight 2,2 kg...
- Page 6 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
