Networks warrants that software will operate substantially in accordance with its functional specifications for 90 days and that it has been properly recorded on non-defective media. Fluke Networks does not warrant that software will be error free or operate without interruption.
Introduction Description ......................1-1 Unpacking ......................1-1 General Safety Information .................. 1-2 Registration ......................1-2 Contacting Fluke Networks ................... 1-3 Operation Keys ......................... 2-1 Icons ........................2-3 Connecting the TS1200 to an ADSL Line .............. 2-4 Using ADSL Mode ....................2-5 Using POTS Mode ....................
Page 4
TS1200 Test Set Users Guide Potential Failures in the Copper Loop ..............4-3 Poor POTS Performance on an ADSL Line ............4-3 Data Safe Practices ....................4-5...
Chapter 1 Introduction Description The TS1200 ADSL/POTS Test Set is an analog test telephone used by installers, repair technicians, and other authorized personnel for the testing of copper wire, voice subscriber, and ADSL lines. The TS1200 can test ADSL lines for throughput, noise margin, and other parameters. It can monitor ADSL and POTS lines simultaneously and can test ADSL service in either a snapshot or a continuous mode.
Registration Registering your product with Fluke Networks gives you access to valuable information on product updates, troubleshooting tips, and other support services. To register, fill out the online registration form on the Fluke Networks website...
Chapter 2 Operation Warning When connecting to metallic network wires, handle alligator clips by insulated boots. Keys Table 2-1 describes the TS1200 Test Set keys. Figure 2-1 shows icons associated with some of the keys. Table 2-1. TS1200 Keys Description Power Allows the user to apply power to and remove power from the test set.
Page 10
TS1200 Test Set Users Guide Table 2-1. TS1200 Keys (continued) Description Up/Down Arrow The Up/Down arrow keys have two functions: to move the user through options Keys and to control the speaker volume. In Speed Dial, Saving Reports, or Bits per Bin screens, the Up/Down arrow keys are used to move the cursor through a list of options depending on the context on the display.
Icons Icons Figure 2-1 shows the icons used on the TS1200 Test Set screens, and Table 2-2 describes the icons. bdx01.eps Figure 2-1. TS1200 Test Set Icons Table 2-2. Icon Descriptions Icon Description Polarity When the test set is connected to a line with DC voltage, one of the two Polarity icons indicates the DC polarity of the line.
TS1200 Test Set Users Guide Table 2-2. Icon Descriptions (continued) Icon Description Speaker A speaker icon appears when the Speaker is on. On/Off Hook The test set displays a telephone in the upper left-hand corner of the LCD screen that indicates when the test set is on or off hook.
Using ADSL Mode bdx02.eps Figure 2-2. Line with Both ADSL and POTS Using ADSL Mode The TS1200 performs either Auto or Manual ADSL tests. In ADSL mode, the user can maintain an active POTS call. To enter ADLS mode, press 2 on the Home Screen (the first screen displayed upon powering up the unit) or press the POTS/ADSL key.
Page 14
TS1200 Test Set Users Guide Auto Test Showtime Once a connection is made and the test is complete, the ADSL test results are shown on the screen. The user can scroll through the test data using the Up/ Down arrow keys. The user may also transition to screens displaying either Bits Per Bin Graphs or Alarm Status.
Page 15
Using ADSL Mode Auto and Manual Out Pwr (Output Power): Displays the aggregate power which is a measure of total output power. Results are presented in dBm. Typically the power output ADSL Test Results is the minimum required to achieve the noise margin that the ATU-C had (continued) been configured for.
TS1200 Test Set Users Guide Saving Test Results The user can save the test results or print out the results. Save Results can be selected from either Auto or Manual Test. To save or print the results: F3 - Exit. From the Showtime Test Results screen, press F1 - Yes.
Page 17
Using POTS Mode Caution When testing circuits that are close to a battery source, the pops in the handset receiver that result from clipping onto a line may be quite loud. Although there is protection against acoustic shock built into the test set, if the receiver is held tightly against the ear, acoustical shock may occur.
TS1200 Test Set Users Guide To activate data lockout override, press F1 - Ovride from the Data Lockout screen. If DC voltage is present on the line, the test set stops alarming and goes off hook, allowing the user to perform normal Talk mode functions.
Page 19
Using POTS Mode Answering a Call To answer an incoming call: If a ringing signal is received, go to the POTS screen and press F2 - Talk . The test set automatically tests for high-speed data on the line. If no data is detected, the test set will go off hook. If data is detected, the test set will lock out and alarm.
Page 20
TS1200 Test Set Users Guide Speed Dial (continued) To store a new speed dial number: Select an empty number using Up/Down arrow keys or number keys. Press F2 - Edit. Enter the name in the NAME field and the telephone number in the NUMBER field.
Configuring Your Test Set Configuring Your Test Set Note Pressing the Home key at any screen will return you to the Home screen. Your test set can be configured by selecting either 3 - POTS CONFIG , 4 - ADSL CONFIG , or on the Home Screen (the first screen displayed upon powering up the unit).
Page 22
TS1200 Test Set Users Guide Tone/Pulse The Tone/Pulse feature is used to switch between tone and pulse dialing. It is only active when the test set is off hook. Any time the test set goes off hook, the TS1200 is automatically set to tone dialing. To change the tone/pulse selection: Press 4 - Tone/Pulse.
Configuring Your Test Set System Configuration The following options can be accessed from the System Configuration screen. Light Timeout The default light timeout is 5 seconds. To change the light timeout length: Press 1 - Light. Use the number keys to select the desired light duration. Press F1 - Accept.
TS1200 Test Set Users Guide ADSL Configuration The following options can be accessed from the ADSL Configuration screen. Firmware To view current Firmware versions: Version Press 1 - Firmware Version. The ADSL, POTS, and Bootloader versions are displayed. Press 3 - Prev. Stored To view, erase, or send stored results to a PC: Results...
Downloading Stored Results to a PC Downloading Stored Results to a PC Connecting to a PC To prepare your TS1200 Test Set for downloading test results to a PC: Loosen the four retaining screws on the back cover of the TS1200 and remove the cover. The TS1200 comes with a RS-232 plug and a 7 foot long RJ-11 to RJ-11 cord.
TS1200 Test Set Users Guide Downloading Results To download results from the TS1200: Turn on the TS1200 Select 4 - ADSL Config , 2 - Stored Results . Use the arrow keys or the numeric keypad to select the results you would like to transfer (1-5).
Page 27
Downloading Stored Results to a PC bdx03.ups Figure 2-3. Selecting and Downloading Stored Results 2-19...
Chapter 3 Maintenance and Specifications Safety Information for Maintenance Warning Disconnect clips from any metallic connections before performing any maintenance. Read all instructions completely and understand possible hazards to end user if service is not performed by authorized service personnel. Use only specified replacement parts for maintenance.
TS1200 Test Set Users Guide Safety with Batteries Note Dispose of batteries in accordance with local regulations. Warning To reduce the risk of fire or injury when recharging, replacing, or otherwise handling the batteries: Do not allow the terminals to be shorted together. Severe burns or explosions can result.
Charging the Batteries Charging the Batteries The TS1200 Test Set is designed to operate on either four NiMH batteries or four AA alkaline batteries. An AC adapter (12 VDC ±10%, 600 mA) or a car adapter may be used to charge the NiMH batteries.
Page 32
TS1200 Test Set Users Guide Using a flat-blade screwdriver, loosen the four battery door screws; then remove the battery door. Note Battery door screws are captive. Remove the old batteries and dispose of them properly. If replacing NiMH batteries with alkaline batteries, first pull the movable wall out of its slot (see Figure 3-1) and move the wall forward to the first slot.
Replacing the Belt Clip The TS1200 Test Set belt clip can be replaced by the user if it becomes damaged or worn. To get a replacement belt clip, contact your local Fluke Networks distributor. To replace the belt clip: Using a Phillips screwdriver, remove the two screws that secure the belt clip to the test set housing (see Figure 3-2).
Disconnect from the telephone network when replacing the line cord. The line cord can be replaced by the user. To get a replacement line cord, contact your local Fluke Networks distributor. To remove the old line cord: Turn the Test Set off and disconnect the AC adapter/charger from the test set, if attached.
Page 35
Replacing the Line Cord To install a new line cord: Carefully slide the modular connector of a new line cord through the hole in the end of the test set. Do not damage the connector pins or plastic tab. Lay the line cord inside the groove in the bottom of the test set housing (see Figure 3-4, right).
TS1200 Test Set Users Guide Accessories Table 3-1 shows accessories available for the TS1200. To order accessories, contact your local distributor or Fluke Networks as described in Chapter 1. Table 3-1. TS1200 Accessories Fluke Networks Description Model Number Angled Bed-of-Nails Cord (ABN)
Page 37
Specifications Table 3-2. Specifications (continued) DTMF Output Tone Frequency Error ±1.5 % maximum Tone Level -3 dBm combined (typical) High versus Low Tone Difference 2 dB ± 2 dB Memory Capacity Memory Capacity 10 speed dial memories plus one last number redial memory Digit Capacity 23 digits per memory PBX Pause Duration...
Page 38
TS1200 Test Set Users Guide Table 3-2. Specifications (continued) Certifications and Compliance CAN/CSA-C22.2 No. 60950-1-03 CAN/CSA-C22.2 No. 1010.1-92 + CSA-C22.2 No. 1010.1B-97 UL/ANSI 3111-1 Specifications subject to change without notice. 3-10...
Chapter 4 Troubleshooting Information Gathering Problems discovered during or after ADSL service installation may require the technician to locate failures in either the CPE or wiring. When trouble is reported, it is critical that a detailed description of the problem be documented before troubleshooting. For example, customers have been known to forget to turn on the modem.
Page 40
TS1200 Test Set Users Guide Table 4-1. Basic Troubleshooting Questions Question If No If Yes Is voice service still functioning The problem is probably limited The problem is on the line (i.e., an on the line? to the ADSL service. open circuit).
Page 41
Potential Failures in the Copper Loop If the exhibited bit rate is significantly better at the NID, then inside wiring or bridged taps are most likely the problem, and installing a splitter may help (Figure 4-1). G.lite requires the connection of bridged taps, or laterals from the main line for voice service, whereas G.DMT isolates data from the voice service.
Page 42
TS1200 Test Set Users Guide bdx04.eps Figure 4-1. ADSL with and without a Splitter...
Page 43
Data Safe Practices Data Safe Practices When going from pair to pair searching for tracer tone or dial tone it is best to connect the test set to Tip and Ring of the pairs. Avoid the practice, either in Talk or Monitor mode, of clipping one lead of the test set to ground, and using the other lead to search for tracer tone or dial tone on a block.
Page 44
