- Page 1 Test Set Users Guide PN 2448469 October 2005, Rev. 2 12/2014 ©2005, 2008, 2014 Fluke Corporation All product names are trademarks of their respective companies.
- Page 2 Networks warrants that software will operate substantially in accordance with its functional specifications for 90 days and that it has been properly recorded on non-defective media. Fluke Networks does not warrant that software will be error free or operate without interruption.
-
Page 3: Table Of Contents
Table of Contents Title Page Overview of Features ............................1 Registration ............................... 1 Contacting Fluke Networks ..........................1 Safety Information ............................2 Physical Characteristics ............................. 2 Mode Controls ............................3 Keypad ................................ 3 Dialing Keys ..............................3 Light Emitting Diodes (LEDs) ........................3 Line Cord ................................ - Page 4 TS30 Test Set Users Guide...
-
Page 5: Overview Of Features
Overview of Features Registration The TS30 Test Set is a portable handset used by Registering your product with Fluke Networks gives installers, repair technicians and other authorized you access to valuable information on product updates, personnel for testing of telephone lines and for troubleshooting tips, and other support services. -
Page 6: Safety Information
TS30 Test Set Users Guide Safety Information Never hold the speaker against your ear when it is on, or when turning it on or off. Sounds emitted by the speaker can be loud The following symbols are used either on the test set or enough to damage your hearing. -
Page 7: Mode Controls
Physical Characteristics Mode Controls MUTE: Pressing the MUTE key shuts off the TS30 transmitter for as long as the key remains depressed. See Figure 2. POLAR: When an off-hook unit is connected to a The TALK/MONITOR switch is on the inside of the hand powered telephone line, pressing the POLAR key grip near the transmitter. -
Page 8: Line Cord
TS30 Test Set Users Guide Line Cord Dialing Note See Figure 4. If tone dialing is selected, the tones associated The TS30 comes with a line cord for connecting the test with each digit will be generated as its set to telephone lines. This line cord consists of one red respective key is pressed. -
Page 9: Last Number Redial
Fluke Networks. test lead. The red LED will light if the red test lead is connected to a more positive voltage than the black To replace the belt clip assembly: lead. -
Page 10: Line Cord Replacement
To obtain a replacement line DTMF Output cord contact your local distributor or Fluke Networks. Tone Frequencies per ITU-T Q.23 Tone Frequency Error ±1.5% maximum... - Page 11 Specifications Safety KCC-REM-FKN-012001001: EMC approval for Korea Telecom Electrical TNV-3 Safety Classification Class A Equipment (Industrial Broadcasting & Communication Equipment) IP54 This product meets requirements for industrial Regulatory Standards Used (Class A) electromagnetic wave equipment and 47 CFR Part 15, Subpart B the seller or user should take notice of it.
- Page 12 TS30 Test Set Users Guide...
