Courtyard Creations RUS014K Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
RUS014G-CS01
2
RUS014G-CS02
3
62RUS023DH101
4
RUS014G-CS03
5
RUS014G-CS04
6
17C01A0710002Y4
7
17C01A0719072Y4
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
Step 1:
Insert the right and left arms (#1 and #2) into the cross
braces (#3) on both sides. Fasten them together by using
bolts (#6), washers (#9), and plastic nuts (#10). Keep the
bolts loose. See Figure 1.
Note:
The labels marked "L" and "R" on the arms (#1 and #2)
should coincide with Figure 1 to ensure proper assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until the glider is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
RUS014K
PART Q'TY
RIGHT ARM
LEFT ARM
CROSS BRACE
BOTTOM FRAME
SEAT ASSEMBLY
BOLT M6*30
BOLT M6*55
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP DON'T RETURN TO STORE!
PAGE 1 OF 3
PART
MATERIAL CODE
NO.
1 8
17C01A0725101Y4
1 9
17FA05040301-Y4
2 10
18000C23001
1 11
18000337002
1 12
17KAA0201----Y4
4 13
17KAB1101----Y4
4 14
61R014KC00001BA
FIGURE 1
1
R
Arm
Assembly
1
9
6
11
#6 BOLT M6*30
PART
BOLT M6*75
WASHER d6.5*D13*1.0
PLASTIC NUT M6*P1.0
BOLT CAP M6
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
CUSHION
3
3
11
11
11
3
3
10
9
COURTYARD CREATIONS INC.
Q'TY
4
32
12
16
1
1
2
2
L
11
2
30
