ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1 RUS016V-CS01
2
RUS016V-CS02
3 62RUS023DH101
4 RUS0175-CS02
5 RUS016U-CS01
6 17C40A0710001YX
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
Step 1:
Insert the right and left arms (#1 and #2) into the cross
braces (#3) on both sides. Fasten them together by using
bolts (#6), washers (#9), and plastic nuts (#10). Keep the
bolts loose. See Figure 1.
Note:
The labels marked "L" and "R" on the arms (#1 and #2)
should coincide with Figure 1 to ensure proper assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until the
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
RUS016U
PART
RIGHT ARM
LEFT ARM
CROSS BRACE
BOTTOM FRAME
SEAT ASSEMBLY
BOLT M6*30
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO THE STORE!
STOP
PAGE 1 OF 3
7 17C40A0719001YX
Q'TY
1 8 17C40A0725091YX
1 9
17FA05040301-YX
2 10 18000C23001
1 11 17KAA0101----Y4
1 12 17KAB1101----Y4
4 13 61R016UC00001BA
FIGURE 1
Arm
assembly
6
BOLT M6*55
BOLT M6*75
WASHER d6.5*D13*1.0
PLASTIC NUT M6*P1.0
HEX. KEY WRENCH 4MM
NUT WRENCH 10&13MM
CUSHION
R
#6 BOLT M6*30
is completely assembled.
glider
COURTYARD CREATIONS INC.
4
4
24
12
1
1
2
L
30
