Summary of Contents for allen WB2434
- Page 1 W O R K B R I D G E S WB2434 SAFETY, ASSEMBLY & PARTS MANUAL Man ual Par t #: 06 852 3 | R evis io n : B Languag e: E n g lish | O r igin a l In stru cti on s...
- Page 2 No part of this manual may be reproduced or transmitted in any form or by any means, electronics or mechanical, for any purpose, without the express written permission of Allen Engineering Corporation (AEC). AEC assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
-
Page 3: General Information Limited Warranty
Allen reserves the choice to repair or replace. 2. If Allen chooses to replace the part, it will be at no cost to the customer and will be made available to the Allen Distributor, Dealer, or Rental Center from whom the End User purchased the product. -
Page 4: Table Of Contents
Table of Contents GENERAL INFORMATION Sect Title Page General Information Limited Warranty ................3 Load Capacity Ratings ................ 5 Information Contained in This Manual ..........6 Dealer Information / Ordering Parts ............. 7 Model Number - Serial Number Codes ..........8 Technical Specifications .............. -
Page 5: Load Capacity Ratings
AEC product support specialist or Authorized AEC dealer FIRST! 6. Calculations are done without factoring weather. Please note that in adverse weather conditions, capacity ratings need to be decreased. Please contact Allen Engineering PRODUCT SUPPORT with any questions reguarding load capacity. 068521 Page 5... -
Page 6: Information Contained In This Manual
Complete any warranty requirements as specified by the engine manufacturer in their instructions found inside the manual box located on the back of the riding trowel operator’s seat. Your engine and clutch is not manufactured by Allen Engineering Corporation, Inc, and therefore is not covered under Allen Engineering Corporation, Inc warranty. -
Page 7: Dealer Information / Ordering Parts
INFORMATION Ordering Parts Your Dealer has Allen Engineering Corporation trained mechanics and original Allen replacement parts. Always contact the Allen Dealer who sold you this machine for Allen Certified repairs and replacement parts. Place Allen Dealer information below for future reference. -
Page 8: Model Number - Serial Number Codes
Model Number / Serial Number GENERAL INFORMATION Manufacturer’s Codes: When ordering parts or requesting service information, you will always be asked to specify the model and serial numbers of the machine. The legends below specifically defines each significant character or group of characters of the Model Number and Serial Number codes. Model Number WB 2434 Series... -
Page 9: Technical Specifications
INFORMATION These work bridges are ideal for joint work, applying curing compounds, bull-floating, applying tex- tures or whenever a suitable platform for doing bridge work is required. The Allen Work Bridge is an economical workhorse on any job site. Work Bridge 2434 Dimensions (H x W x L) 24”... -
Page 10: Safety
SECTION 1 SAFETY SECTION 1 SAFETY Page 10 068521... -
Page 11: Federal / State Warning Regulations
Federal / State Warnings SECTION 1 SAFETY RESPIRATORY HAZARDS Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as respiratory disease, cancer, birth defects or other reproductive harm. SILICOSIS WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may... -
Page 12: Manual Tag Safety Detail
Manual Tag Safety Detail SECTION 1 SAFETY Safety-Alert Signs This manual contains Safety-Alert Signs, as defined below, which must be followed to reduce the possibility of improper servi ce damage to the equipment or personal injury. Read and follow all Safety-Alert Signs included in this manual. NOTE defines an operating procedure, condition, etc. -
Page 13: Spark Arrestor Notice / Hazard Symbols
Spark Arrestor Notice / SECTION 1 SAFETY Hazard Symbols Some states require that in certain locations arrestors be used on internal combustion engines. A spark arrester is a device designed to prevent the discharge of spark or flames from the engine exhaust. It is often required when operating equipment on forested land to prevent the risk of fires. -
Page 14: Operating Safety
Operating Safety SECTION 1 SAFETY Familiarity and proper training are required for the safe operation of this equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions contained in both this manual and the engine manual and familiarize yourself with the location and proper use of all controls. •... -
Page 15: Engine Safety
Engine Safety SECTION 1 SAFETY Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the warnings and safety guidelines could result in severe injury or death. •... -
Page 16: Service Safety
Service Safety SECTION 1 SAFETY Poorly maintained equipment can become a safety hazard! In order for the equipment to operate safely and properly over a long period of time, periodic maintenance and occasional repairs are necessary. • ALWAYS disconnect the battery before servicing the equipment. •... -
Page 17: Lifting Safety
Lifting Safety SECTION 1 SAFETY ALWAYS DO A THOROUGH INSPECTION OF THE SLINGS, CHAINS, AND HOOKS BEFORE ATTEMPTING TO LIFT THE MACHINE! OSHA has set forth guidelines which detail the use of Rigging Equipment for Material handling. This guide- line is found under OSHA Standard Number: 1926.251 Please read and follow all guidelines found in this standard. - Page 18 Lifting Safety SECTION 1 SAFETY PLEASE CONSULT ON-SITE SAFETY COORDINATOR BEFORE ATTEMPTING TO LIFT MACHINE. IMPROPER RIGGING AND LIFTING CAN RESULT IN INJURY OR DEATH. BELOW IS AN EXAMPLE OF STRAP PLACEMENT AND LIFTING PROCEDURES, BUT THIS SHOULD NOT BE USED AS A GUIDE FOR LIFTING THE MACHINE! (ON LONGER WORKBRIDGES, A SPREADER BEAM MAY BE REQUIRED.) TO CRANE USE A 5,000 lb SHACKLE AS...
-
Page 19: Transportation Safety
Transportation Safety SECTION 1 SAFETY • Make sure the hitch and coupling of the towing vehicle are rated equal to, or greater than the trailer “gross vehicle weight rating.” • ALWAYS inspect the hitch and coupling for wear. Never tow a trailer with defective hitches, couplings, chains, etc. •... -
Page 20: Assembly
SECTION 2 ASSEMBLY SECTION 2 ASSEMBLY Page 20 068521... -
Page 21: Assembly Instructions
Assembly Instructions SECTION 2 ASSEMBLY Please follow the instuructions below for assembly: Work Bridge Section Connections: Bolt Connecting Pin Hairpin Connecting Clevis Rod End Clevis Pin 1. Align WB sections so that the connecting clevis sits outside the rod end. 2. - Page 22 Assembly Instructions SECTION 2 ASSEMBLY Installing Pneumatic Wheel Type Bracket: Adjustable End Frame Bracket Paving Style Wheel Slide Assembly Workbridge Section Pneumatic Tire Assembly 1. Loosen clip and slide adjustable end frame bracket around workbridge section, and tighten clips back to secure end frame bracket. 2.
- Page 23 Assembly Instructions SECTION 2 ASSEMBLY Installing Power Wheel Option: 1. Place Power Wheel Power Unit on Work Bridge as shown in figure. 2. Attach Power Unit with 1/2”-13 Power Wheel Power Unit x 3-1/2” bolt (045855 x 4) and Nut (011238 x 4) 3.
- Page 24 Assembly Instructions SECTION 2 ASSEMBLY Installing Cable Tension Kit: 1. Loop dead end of cable through the Hook & Eye Turnbuckle. 2. Apply first clip one base width from dead end of wire rope. U-Bolt over dead end. Live end rests in clip saddle. Tighten nuts evenly to recommended torque. 3.
- Page 25 Assembly Instructions SECTION 2 ASSEMBLY 068521 Page 25...
-
Page 26: Parts
SECTION 3 PARTS SECTION 3 PARTS Page 26 068521... -
Page 27: Mainframe Sizes
Mainframe Sizes SECTION 3 PARTS ITEM PART # DESCRIPTION 051689 Assembly, Mainframe, 3’ Section 069524 Assembly, Mainframe, 3’ Section, Powered 051688 Assembly, Mainframe, 6’ Section 069523 Assembly, Mainframe, 6’ Section, Powered 051687 Assembly, Mainframe, 12’ Section 069522 Assembly, Mainframe, 12’ Section, Powered 051690 Assembly, Mainframe, Telescopic Section 069525... -
Page 28: Mainframe Assembly - 3 Foot
Weldment, Mainframe, 6 FT, WB2434 059654 Fastener, Bolt, HHCS, 5/16”-18 x 1-3/4”, Grade 8 For Powered Option also Include: ITEM PART # DESCRIPTION 068632 Kit, Hose and Fitting, WB2434, 3’ Section 051077 Ring, Color, Green, Coding 051078 Ring, Color, White, Coding Page 28 068521... -
Page 29: Mainframe Assembly - 6 Foot
Weldment, Mainframe, 6 FT, WB2434 059654 Fastener, Bolt, HHCS, 5/16”-18 x 1-3/4”, Grade 8 For Powered Option also Include: ITEM PART # DESCRIPTION 068631 Kit, Hose and Fitting, WB2434, 6’ Section 051077 Ring, Color, Green, Coding 051078 Ring, Color, White, Coding 068521 Page 29... -
Page 30: Mainframe Assembly - 12 Foot
Weldment, Mainframe, 12 FT, WB2434 059654 Fastener, Bolt, HHCS, 5/16”-18 x 1-3/4”, Grade 8 For Powered Option also Include: ITEM PART # DESCRIPTION 068630 Kit, Hose and Fitting, WB2434, 12’ Section 051077 Ring, Color, Green, Coding 051078 Ring, Color, White, Coding Page 30 068521... -
Page 31: Adjustable End Frame Bracket
Adjustable End Bracket Assembly SECTION 3 PARTS ITEM PART N 010050 010093 010106 029708 050233 050987 051635 051638 051905 069122 ITEM PART # DESCRIPTION 051691 Assembly, Adjustable End Bracket 010050 Fastener, Nut, Hex, 1/2”-13, Grade 8 010093 Fastener, Washer, Lock, 1/2”, Grade 8 010106 Fastener, Nut, Hex, 1/2”-13, Grade 8 029708... -
Page 32: Mainframe Assembly - Telescoping, 15-25 Foot
Mainframe Assembly - Telescoping, 15-25 Foot SECTION 3 PARTS ITEM Page 32 068521... - Page 33 Fastener, HHCS, 5/16”-18 x 1-3/4”, Grade 8 065566 Spacer, for Telescoping Section For Powered Option also Include: ITEM PART # DESCRIPTION 068633 Kit, Hose and Fitting, WB2434, 12’ Section 051077 Ring, Color, Green, Coding 051078 Ring, Color, White, Coding 068521 Page 33...
-
Page 34: Mainframe Assembly - Telescoping, Opposite End, 15-25 Foot
Mainframe Assembly - Telescoping, Opposite End, SECTION 3 PARTS 15-25 Foot Page 34 068521... - Page 35 Mainframe Assembly - Telescoping, Opposite SECTION 3 PARTS End, 15-25 Foot ITEM PART # DESCRIPTION 070650 Assembly, Mainframe, Telescoping, Opposite End Section Assembly, Mainframe, Telescoping, Opposite End, Powered 010024 Fastener, HHCS, 5/16”-18 x 2” 010092 Fastener, Washer, Lock, 7/16”, Grade 8 012612 Fastener, Nut, Hex, Nylock, 5/16”-18, Grade 8 022110...
-
Page 36: Bridge Deck End Bracket Assembly
Bridge Deck End SECTION 3 PARTS Bracket Assembly Only one side shown in detail. For full BOM of parent part numbers, please multiply quantifies shown by 2. Page 36 068521... - Page 37 Bridge Deck End SECTION 3 PARTS Bracket Assembly ITEM PART # DESCRIPTION 051695 Assembly, Bridge Deck End Bracket, Cupped Wheels 051696 Assembly, Bridge Deck End Bracket, Flanged Wheels 010035 Fastener, Bolt, HHCS, 3/8”-16 x 3/4”, Grade 8 010037 Fastener, Bolt, HHCS, 3/8”-16 x 1-1/4”, Grade 8 010050 Fastener, Nut, Hex, 1/2”-13, Grade 8 010068...
-
Page 38: Power Wheel Conversion Kit
Power Wheel Converstion Kit SECTION 3 PARTS ITEM Page 38 068521... - Page 39 Power Wheel Converstion Kit SECTION 3 PARTS ITEM PART # DESCRIPTION 067525 Assembly, Power Wheel Conversion Kit 010002 Fastener, Bolt, HHCS, 1/4”-20 x 3/4”, Grade 8 010036 Fastener, Bolt, HHCS, 3/8”-16 x 1”, Grade 8 010037 Fastener, Bolt, HHCS, 3/8”-16 x 1-1/4”, Grade 8 010038 Fastener, Bolt, HHCS, 3/8”-16 x 1-1/2”, Grade 8 010069...
-
Page 40: Wb Power Wheel, Power Unit
WB Power Wheel, Power Unit SECTION 3 PARTS Page 40 068521... - Page 41 WB Power Wheel, Power Unit SECTION 3 PARTS ITEM PART # DESCRIPTION 052639 Assembly, WB Power Wheel, Power Unit 2404-10-16 Fitting, Adapter, Straight, 5/8” JIC Male x 1” NPTF Male 6407-10-10 Fitting, Swivel Union, #10 SAE/ORB Male 010005 Fastener, Bolt, HHCS, 1/4”-20 x 1-1/2”, Grade 8 010009 Fastener, Bolt, HHCS, 1/4”-20 x 2-1/2”, Grade 8 010035...
-
Page 42: Bridge Deck Style Wheel Options
Bridge Deck Style Wheel Options SECTION 3 PARTS Part #: 065015 Part #: 052745 Part #: 052744 Poly Coated, Double Flanged Steel, Double Flanged Steel, Double Flanged Drive Wheel for 2" Forms Idle Wheel for 2" Forms Drive Wheel for 2" Forms Part #: 065025 Part #: 042561 Part #: 042562... - Page 43 SECTION 3 PARTS PAGE LEFT BLANK INTENTIONALLY 068521 Page 43...
-
Page 44: Decal Kit
Decals, WB2434 SECTION 3 PARTS Page 44 068521... - Page 45 Warning Max Length Not To Exceed 120’ 075277 Made In America 075373 AEC Brand Logo Mark 8” x 8” 075383 Allen Concrete Pavers WB1224 8” x 2.110” 075430 AEC Info (Not Shown) 075191 QR Code Equipment Information (Not Shown) 068521...
-
Page 46: Cleaning Procedure
Cleaning Procedure SECTION 3 PARTS Machine Cleaning Procedure When cleaning the machine, please adhere to the following information to ensure proper cleaning and to keep the machine in the best condition possible. Power Washing Procedure: • Ensure that the water pressure is below 2000 PSI (14 MPa) •... -
Page 47: Revision Detail
Revision Detail SECTION 3 PARTS MANUAL REVISION DETAIL REVISION REVISION # REVISION REFERENCE # REVISION BY DATE 08/20 Initial Release 01/22 Updated Covers 02/22 Updated Decal Kit 068521 Page 47... - Page 48 AEC FACTORY & HEADQUARTERS 8 1 9 S . 5 T H S T R E E T P A R A G O U L D , A R K A N S A S 7 2 4 5 0 8 7 0 .
