R I D I N G T R O W E L

HDX600

PARTS &

DECALS MANUAL

Man ual Par t #: 06 997 0P | Re vi si on : C

Languag e: E n g lish | O r igin a l In stru cti on s

Table of Contents

Need help?

Do you have a question about the HDX600 and is the answer not in the manual?

Questions and answers

Summary of Contents for allen HDX600

Page 1 R I D I N G T R O W E L HDX600 PARTS & DECALS MANUAL Man ual Par t #: 06 997 0P | Re vi si on : C Languag e: E n g lish | O r igin a l In stru cti on s...
Page 2 For information regarding the following, please see the “HDX600 - Safety & Operator Manual” • Warranty Information • Dealer Information • How to identify the Model / Serial Numbers on the machine • Engine Detail Page 2 069970P...
Page 3 No part of this manual may be reproduced or transmitted in any form or by any means, electronics or mechanical, for any purpose, without the express written permission of Allen Engineering Corporation (AEC). AEC assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
Page 4: Table Of Contents
Table of Contents Table of Contents .................. 4 PARTS ....................5 Factory Service Information ..............6 Replacement Part Procedure ..............7 General Arrangement ................8 Seat Frame Assembly ................10 Lower Unit Assembly ................14 Engine Assembly ..................16 Rotor Assembly - Left Hand ..............18 Rotor Assembly - Right Hand ..............
Page 5: Section 1: Parts
SECTION 1 PARTS SECTION 1: PARTS 069970P Page 5...
Page 6: Factory Service Information
Factory Service Information SECTION 1 PARTS This section contains the illustrated drawings and parts list for help in identifying and/or ordering replacement parts for your machine. Follow the instructions in the front section of this manual “Ordering Parts” when ordering replacement parts to ensure prompt and accurate delivery.
Page 7: Replacement Part Procedure
Replacement Part Procedure SECTION 1 PARTS ALL REFERENCES MADE TO LEFT/RIGHT SIDES IN THIS MANUAL ARE SITTING ON MACHINE (SOM) [i.e. Left / Right are in reference from a sitting position on the machine] We recommend AEC quality replacement parts, available from the AEC Customer Service Department or your nearest AEC Dealer.
Page 8: General Arrangement
General Arrangement SECTION 1 PARTS Page 8 069970P...
Page 9 General Arrangement SECTION 1 PARTS ITEM PART NO. DESCRIPTION 068360 Assembly, HDX600 - 5 Boss 068175 Assembly, Main Frame 068180 Assembly, Seat Frame 065168 Harness F/ Lights 069101 Kit, Decal 070072 Main Wiring Harness 070308 Kit, Component 070316 Kit, Hydraulic Fitting...
Page 10: Seat Frame Assembly
Seat Frame Assembly SECTION 1 PARTS FRONT BOTTOM VIEW Page 10 069970P...
Page 11 Seat Frame Assembly SECTION 1 PARTS ITEM PART NO. DESCRIPTION 068180 Assembly, Seat Frame, HDX600 Fuse Block 034524 Fuse, 20 Amp (Not Shown) 036554 Fuse, 5 Amp (Not Shown) 043481 Fuse, 10 Amp (Not Shown) 047665 Bumper, Rubber 047886 Cap, Filler Breather...
Page 12 Seat Frame Assembly Continued SECTION 1 PARTS FRONT BOTTOM VIEW Page 12 069970P...
Page 13 Arm Rest, Left / Right Combo, for seat 069874 074251 Cup Holder 071122 Cup Holder Trim Material 1.9FT 076952 LED, RED 077525 Buzzer, 12V 077893 Antenna F/ Telematics 077894 Controller F/ Telematics 080279 Riser, For Joystick HDX600 069970P Page 13...
Page 14: Lower Unit Assembly
Lower Unit Assembly SECTION 1 PARTS 10 11 Page 14 069970P...
Page 15 Lower Unit Assembly SECTION 1 PARTS ITEM PART NO. DESCRIPTION 068175 Assembly, Main Frame, HDX600 012702 Tip, Brass, 80° x 0.10 GPM 041624 Retainer, Nylon Spray Tip 045757 Isolator, Motor Mount 046696 Box, Battery 047604 Battery, 700CCA, 12V 047700 Tank, 6 Gallon, Water, Plastic 047701 Cap, 3-1/2”, Vented Black...
Page 16: Engine Assembly
Engine Assembly SECTION 1 PARTS Page 16 069970P...
Page 17 Engine Assembly SECTION 1 PARTS ITEM PART NO. DESCRIPTION 068290 Assembly, Engine, HDX600 010070 Fastener, HHCS 1/2-13 x 1-3/4 010093 Fastener, Lock Washer 1/2 021072 Fastener, Washer, Lock, 10mm 064357 Assembly, Housing and Coupling 065126 Cover, Radiator Shroud, Bottom 065127...
Page 18: Rotor Assembly - Left Hand
Rotor Assembly - Left Hand SECTION 1 PARTS ITEM Page 18 069970P...
Page 19 Rotor Assembly - Left Hand SECTION 1 PARTS ITEM PART NO. DESCRIPTION 068036 Assembly, Rotor, Left Hand, HDX600 010036 Fastener, HHCS, 3/8”-16 x 1”, Grade 8 010068 Fastener, HHCS, 1/2”-13 x 1-1/4”, Grade 8 010069 Fastener, HHCS, 1/2”-13 x 1-1/2”, Grade 8 010091 Fastener, Washer, Lock, 3/8”, Grade 8...
Page 20: Rotor Assembly - Right Hand
Rotor Assembly - Right Hand SECTION 1 PARTS ITEM Page 20 069970P...
Page 21 Rotor Assembly - Right Hand SECTION 1 PARTS ITEM PART NO. DESCRIPTION 068037 Assembly, Rotor, Right Hand, HDX600 010036 Fastener, HHCS, 3/8”-16 x 1”, Grade 8 010069 Fastener, HHCS, 1/2”-13 x 1-1/2”, Grade 8 010091 Fastener, Washer, Lock, 3/8”, Grade 8 010093 Fastener, Washer, Lock, 1/2”, Grade 8...
Page 22: Lower Rotor Assembly - Left Hand
Lower Rotor Assembly - Left Hand SECTION 1 PARTS ITEM PART # DESCRIPTION 060543 Assembly, Lower Rotor, Left Hand 010024 Fastener, Bolt, HHCS, 5/16”-18 x 2”, Grade 8 010090 Fastener, Washer, Lock, 5/16”, Grade 8 015694 Cap, Grease, W-1, Red, Plastic, Tapered 025091 Fastener, Bolt, Shoulder, 3/8”...
Page 23: Lower Rotor Assembly - Right Hand
Lower Rotor Assembly - Right Hand SECTION 1 PARTS ITEM PART # DESCRIPTION 060544 Assembly, Lower Rotor, Right Hand 010024 Fastener, Bolt, HHCS, 5/16”-18 x 2”, Grade 8 010090 Fastener, Washer, Lock, 5/16”, Grade 8 015694 Cap, Grease, W-1, Red, Plastic, Tapered 025091 Fastener, Bolt, Shoulder, 3/8”...
Page 24: Spider Assembly - Left Hand
Spider Assembly - Left Hand SECTION 1 PARTS ITEM PART # DESCRIPTION 067587 Assembly, Spider, Left Hand 010050 Fastener, Nut, Hex, 1/2”-13 015682 Fastener, External Tooth, 3/8” 015683 Fastener, Bolt, Hex Head, 3/8”-16 x 7/8” 015684 Fastener, Nut, Hex, 3/8”-16 015686 Fastener, Bolt, SQHSS, 3/8”-16 x 1”...
Page 25: Spider Assembly - Right Hand
Spider Assembly - Right Hand SECTION 1 PARTS ITEM PART # DESCRIPTION 067588 Assembly, Spider, Right Hand 010050 Fastener, Nut, Hex, 1/2”-13 015682 Fastener, External Tooth, 3/8” 015683 Fastener, Bolt, Hex Head, 3/8”-16 x 7/8” 015684 Fastener, Nut, Hex, 3/8”-16 015686 Fastener, Bolt, SQHSS, 3/8”-16 x 1”...
Page 26: Hydraulic Schematic
Hydraulic Schematic SECTION 1 PARTS TEST PANEL Reference Quantity Part Number Rotor Motor Rotor Motor Primary Pump HYD Cooler Return Header Y- Strainer Charge Filter Page 26 069970P...
Page 27 Hydraulic Schematic SECTION 1 PARTS RIGHT JOYSTICK PRESSURE RIGHT PITCH LEFT PITCH LEFT JOYSTICK PRESSURE LJSP RJSP TSTP TANK TO MOTOR CASE 069970P Page 27...
Page 28: Hydraulic System
Hydraulic System SECTION 1 PARTS Replacement Parts ITEM PART # DESCRIPTION 070522 Filter, Steering Element 043418 Filter, Charge 070097 Flow Divider / Combiner, Spool 070098 Check Valve - Ball 070099 Flow Control Valve, Pressure Compensated 071150 Refief Valve, Direct 071151 Solenoid Valve, 3/4”...
Page 29: Section 2: Decals
SECTION 2 DECALS SECTION 2: DECALS 069970P Page 29...
Page 30: Decals - Front (Kit #: 069101)
Decals - Front (Kit #: 069101) SECTION 2 DECALS Part # 056339 Allen Globe Part # 070402 Hydraulic Pressure Warning Part # 069106 HDX 600 - Front Plate Part # 070128 Fuse & Relay Detail Part # 070658 Teir 4 Compliance...
Page 31: Decals - Rear (Kit #: 069101)
Decals - Rear (Kit #: 069101) SECTION 2 DECALS Part # 069225 Prop. 65 Warning Part # 065653 Part # 065653 Lifting Point Lifting Point Part # 066068 Hand Tool Area Part # 066103 Grease Pressure Plate Part # 066103 Grease Pressure Plate Part # 070129 Part # 065655...
Page 32: Decals - Top (Kit #: 069101)
Decals - Top (Kit #: 069101) SECTION 2 DECALS Part # 069105 Part # 069105 Side Model Number Side Model Number Part # 068459 Part # 065653 Part # 065653 Lifting Point Tie Down Lifting Point Part # 069102 Part # 068459 Cup Holder Area Tie Down Part # 068459...
Page 33: Decals - Right / Left (Kit #: 069101)
Decals - Right / Left (Kit #: 069101) SECTION 2 DECALS Part # 065653 Lifting Point Part # 069105 Side Model Number LEFT SIDE Part # 069104 Diesel Only Part # 066103 Grease Pressure Plate Part # 065656 Drop Hazard Part # 065653 Lifting Point RIGHT SIDE...
Page 34: Revision Detail
Revision Detail MANUAL REVISION DETAIL REVISION # REVISION DATE REVISION REFERENCE # REVISION BY 12/19 Initial Release 01/22 Updated Covers 06/22 Updated Trowel Arm PN 11/24 Telematics Info, 24-523, 24-554 Page 34 069970P...
Page 36 AEC FACTORY & HEADQUARTERS 8 1 9 S . 5 T H S T R E E T P A R A G O U L D , A R K A N S A S 7 2 4 5 0 8 7 0 .
