7350 Series Version 2 Modular
Belt Curved Conveyors
Installation, Maintenance and Parts Manual
For other service manuals visit our website at:
www.dornerconveyors.com/manuals-literature
Record Conveyor Serial Number Here
851-878 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AquaGard 7350 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorner AquaGard 7350 Series

Summary of Contents for Dorner AquaGard 7350 Series

  • Page 1 7350 Series Version 2 Modular Belt Curved Conveyors Installation, Maintenance and Parts Manual For other service manuals visit our website at: www.dornerconveyors.com/manuals-literature Record Conveyor Serial Number Here 851-878 Rev. A...

  • Page 2: Table Of Contents

    The Dorner Limited Warranty applies. CAUTION Dorner 7350 Series conveyors have patents pending. Some illustrations may show guards Dorner reserves the right to make changes at any time without notice or obligation. removed. DO NOT operate equipment without guards. Dorner has convenient, pre-configured kits of Critical Service Parts for all conveyor products.

  • Page 3: Warnings - General Safety

    Handle drive shaft keyway with care. It may be SEVERE HAZARD! sharp and could puncture the skin, causing • Dorner cannot control the physical installation serious injury. and application of conveyors. Taking protective measures is the responsibility of the user.

  • Page 4: Product Description

    • Non-accumulating product • Product moving toward gearmotor • Conveyor being mounted horizontally • Conveyor being located in a dry environment • Conveyor equipped with standard belt only 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 5: 7350 Series Version 2 Curve Conveyor Modules

    Profile D Side Profile A Side Profile A Side Stand Location Direction Drive Position Angle Drive Tail Type Width (mm) Length (mm) Document Language Width (mm) Document Language 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 6: Conveyor Supports

    Curve Module: Reference chart below for support stand quantities: Degree/Width 152 mm (6") 305 mm (12") 457 mm (18") 610 mm (24") 45° 90° 135° 180° 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 7: Installation

    Join both conveyor sections and install connecting plates (Figure 4, item 1) with four M8x10 hex head cap screws (Figure 4, item 2) on both sides. 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 8: Stand Installation

    A minimum of one space, and a maximum of three spaces, is required between bearings. Figure 7 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...
  • Page 9 (Figure 11, item 2) and (Figure 12, item 2). Figure 11 Figure 13 Bring the ends of the belt together (Figure 14). Figure 14 Figure 11 Figure 14 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 10: Guide Installation

    High Side Guides studs. Remove and discard the top bolt (Figure 17, item 1) Figure 20 from the conveyor side. Figure 17 Figure 20 Figure 17 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 11: Adjustable Guides

    (Figure 24, item 2). Figure 24 Figure 22 Install the guide post (Figure 22, item 3) behind lower bolt. Reinstall top bolt and tighten bolts. Figure 24 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 12: Preventive Maintenance And Adjustment

    Proper conveyor application, cleaning, and WARNING sanitation are the responsibility of the end user. CAUTION CAUTION Dorner recommends cleaning all the “food zones” before placing the conveyor into SEVERE HAZARD! service. Ensure that adequate access is LOCK OUT POWER before removing guards provided for cleaning and servicing or performing maintenance.
  • Page 13 Replace the old belt with a new one. Refer to “Belt Installation” on page 8. CAUTION CAUTION DO NOT reuse belt rods that are damaged or show signs of wear. Figure 27 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 14: Conveyor Belt Tensioning

    Belt should not be stretched during installation. A proper length of belt can be Figure 31 installed by interlocking the ends by hand without excess links. Figure 31 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 15: Wear Strips

    Figure 36 Replace the wear strips if they become worn. Typical straight wear strips (Figure 35). Wear Strip Wear Strips, Bed Rail Figure 35 Figure 35 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 16: Wear Strip Removal

    Remove the bolt (Figure 38, item 1) retaining the wear Figure 40 strip support bracket (Figure 38, item 2) to the frame crossmember (Figure 38, item 3). Figure 38 Figure 38 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 17: Curve Bearing Guide Wear Strip

    Remove the bottom wear strip (Figure 44, item 1) from Figure 42 the frame rail (Figure 44, item 2). Figure 44 Figure 42 Install a new wear strip. Figure 44 Install a new wear strip. 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 18: Drive Sprocket And Spindle Replacement

    Loosen set screws (Figure 48, item 1). Figure 48 Figure 45 Remove the four headplate bolts (Figure 46, item 1) on both sides of the conveyor. Figure 46 Figure 48 Figure 46 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 19: Idler Puck And Spindle Replacement

    Idler tails are equipped with plain bushing headplate bolt from the shaft. pucks, replace when worn. Figure 52 Open conveyor belt. Refer to “Conveyor Belt Replacement” on page 12. Figure 52 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 20: Power Transfers

    Loosen hex head screw (Figure 57, item 1) on both sides of the power transfer. Figure 57 Figure 54 Figure 57 Slide idler assembly within slot (Figure 57, item 2) to remove tension on belt. 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...
  • Page 21 (Figure 62, item 3). Replace worn parts. Figure 62 Note that head of pin (Figure 59, item 1) should be removed in direction shown. Remove belt. Figure 62 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.
  • Page 22 13. Loosen two set screws (Figure 64, item 1) on bearing Figure 66 (Figure 64, item 2) on both sides of the power transfer. Figure 64 Figure 66 Figure 64 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 23: Installation

    (Figure 72, item 2) on both sides of Tighten set screw (Figure 69, item 1) on drive sprocket the power transfer. (Figure 69, item 2). Figure 72 Figure 69 Figure 72 Figure 69 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.
  • Page 24 (Figure 75, item 2). Tighten hex head screws (Figure 75, item 3). Figure 77 CAUTION CAUTION DO NOT overtighten belt or excessive wear will occur. Figure 75 Figure 75 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 25: Bearing Replacement

    Refer to “Drive Sprocket and Spindle Replacement” on page 18. Follow steps 1 through 7. Twist the bearing out (Figure 80, item 1). Figure 80 Figure 79 Figure 80 Replace the bearing. 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev. A Dorner Mfg. Corp.

  • Page 26: Notes

    Notes 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 27: Service Parts

    Service Parts NOTE For replacement parts other than those shown in this section, contact an authorized Dorner distributor or Dorner directly. Recommended Critical Service Parts and Kits are identified by the Key Service Parts symbol . Dorner recommends keeping these parts on hand.

  • Page 28: Idler Tail

    LLLLL = Part length in inches with 2 decimal places. Example: Part Length = 95.25" LLLLL = 09525 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg.

  • Page 29: Idler Tail With Auxiliary Shaft

    532121-LLLLL Square Key Example: Part Length = 95.25" LLLLL = 09525 802-161 Bearing Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 807-1454 Bearing Cap customerservice@dorner.com 912-108SS Square Key, .25" x 1.00"...

  • Page 30: Power Transfer

    Service Parts Power Transfer 36 Power Transfer Kit 35 Belt Kit 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...
  • Page 31 2, 5, 10, 15, 16, 17, 19 and 21) WW = Conveyor width reference in inches 06, 12, 18, 24 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev.

  • Page 32: Straight Frame

    Service Parts Straight Frame 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...
  • Page 33 LLLLL = Part length in inches with 2 decimal places. Example: Part Length = 95.25" LLLLL = 09525 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev.

  • Page 34: Curve Frame

    Service Parts Curve Frame 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...
  • Page 35 LLLLL = Part length in inches with 2 decimal places. Example: Part Length = 95.25" LLLLL = 09525 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev.

  • Page 36: Connecting Assembly

    960810MSS Hex Head Cap Screw, M8-1.25 x 10 mm Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg. Corp. 851-878 Rev. A...

  • Page 37: 25 Mm High Sides For Straight Sections

    Example: Part Length = 95.25" LLLLL = 09525 516935 Guide Connecting Plate (for Multiple Guide Sections Only) Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 990801MSS Hex Nut customerservice@dorner.com 518400-05-LLLLL-LH Guiding, Left Hand (for Multiple...

  • Page 38: 25 Mm High Sides For Curve Sections

    AA = Conveyor angle reference 45, 90 WW = Conveyor width reference in inches 06, 12, 18, 24 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg.

  • Page 39: 75 Mm High Sides For Straight Sections

    Example: Part Length = 95.25" LLLLL = 09525 516935 Guide Connecting Plate (for Multiple Guide Sections Only) Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 990801MSS Hex Nut customerservice@dorner.com 518400-04-LLLLL-LH Guiding, Left Hand (for Multiple...

  • Page 40: 75 Mm High Sides For Curve Sections

    AA = Conveyor angle reference 45, 90 WW = Conveyor width reference in inches 06, 12, 18, 24 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg.

  • Page 41: 152 Mm High Sides For Straight Sections

    Example: Part Length = 95.25" LLLLL = 09525 516935 Guide Connecting Plate (for Multiple Guide Sections Only) Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 990801MSS Hex Nut customerservice@dorner.com 518400-06-LLLLL-LH Guiding, Left Hand (for Multiple...

  • Page 42: 152 Mm High Sides For Curve Sections

    AA = Conveyor angle reference 45, 90 WW = Conveyor width reference in inches 06, 12, 18, 24 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg.

  • Page 43: Fully Adjustable Round Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1387 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev.

  • Page 44: Tool-Less Fully Adjustable Round Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1470 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg.

  • Page 45: Fully Adjustable Flat Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1387 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Modular Belt Curved Conveyors 851-878 Rev.

  • Page 46: Tool-Less Fully Adjustable Flat Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1470 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Modular Belt Curved Conveyors Dorner Mfg.

  • Page 47: Ordering A Replacement Chain

    Determine the length of chain required for the conveyor and round up to the nearest foot length. Order the proper number Flat Belt Chain Kit of chain repair kits (1' long each) for your conveyor. Dorner will ship chain kits that are of a reasonable length fully assembled Example: Overall chain length = 42' 5"...

  • Page 48: Return Policy

    Return Policy Returns must have prior written factory authorization or they will not be accepted. Items that are returned to Dorner without authorization will not be credited nor returned to the original sender. When calling for authorization, please have the following information ready for the Dorner factory representative or your local distributor: Name and address of customer.
