7350 Series Side Mount 90°
Installation, Maintenance & Parts Manual
US Version
DORNER MFG. CORP.
P.O. Box 20 • 975 Cottonwood Ave.
Hartland, WI 53029-0020 USA
851-679 Rev. C
Drive Package
For other service manuals visit our website at:
www.dorner.com/service_manuals.asp
INSIDE THE USA
TEL: 1-800-397-8664
FAX: 1-800-369-2440
CE Version
OUTSIDE THE USA
TEL: 262-367-7600
FAX: 262-367-5827

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AquaGard 7350 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dorner AquaGard 7350 Series

Summary of Contents for Dorner AquaGard 7350 Series

  • Page 1 7350 Series Side Mount 90° Drive Package Installation, Maintenance & Parts Manual US Version CE Version DORNER MFG. CORP. INSIDE THE USA OUTSIDE THE USA P.O. Box 20 • 975 Cottonwood Ave. TEL: 1-800-397-8664 TEL: 262-367-7600 Hartland, WI 53029-0020 USA...

  • Page 2: Table Of Contents

    Variable Speed 90° Stainless Gearmotors ....... 6 Introduction Dorner’s Limited Warranty applies. IMPORTANT Dorner reserves the right to make changes at any time without notice or obligation. Some illustrations may show guards removed. DO NOT operate equipment Dorner has convenient, pre−configured kits of Key Service without guards.

  • Page 3: Warnings - General Safety

    CONVEYOR. DO NOT OPERATE CONVEYORS IN AN A WARNING EXPLOSIVE ENVIRONMENT. A WARNING Dorner cannot control the physical installation and application of conveyors. Taking protective measures is the responsibility of the user. Exposed moving parts can cause severe When conveyors are used in conjunction injury.

  • Page 4: Product Description

    Specifications Gearmotor Mounting Package Models: Conveyor Sprocket Gearmotor Sprocket Drive Position Gearmotor Size Gearmotor Type Drive Type Language M = US Version U = CE English Version 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 5: Version

    0.75 230/400 3.65 73U015HS423FN 28.3 1.12 230/400 4.89 2.81 73U010HS423FN 42.7 1.12 230/400 4.89 2.81 73U007HS423FN 56.7 1.49 230/400 6.17 3.55 73U005HS423FN 85.0 1.49 230/400 6.17 3.55 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.

  • Page 6: Version

    1.11 208-230/460 5.3-5.4/2.7 49.9 74M007HZS423EN 23 to 233 7.1 to 71.0 1.11 208-230/460 5.3-5.4/2.7 40.7 NOTE For belt speed other than those listed, contact factory for details. 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 7: Installation

    Figure 4 causing serious injury. NOTE Gearmotor may be operated in positions 1 or 3 (Figure 2). Figure 2 Figure 4 Figure 2 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.
  • Page 8 Tighten four bolts (Figure 9, item 3) to 65 in−lbs (7.3 N−m). Figure 7 Install cover bracket (Figure 7, item 2) onto gear reducer with screws (Figure 7, item 3). 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 9: Ce Version Side Drive Package

    (Figure 12, item 1). causing serious injury. Figure 12 NOTE Gearmotor may be operated in positions 1 or 3 (Figure 10). Figure 10 Figure 12 Figure 10 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.
  • Page 10 (Figure 18, item 2). and secure with two hex socket head screws Figure 18 (Figure 15, item 2). Figure 15 Figure 18 Figure 15 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 11: Preventive Maintenance And Adjustment

    Motors may be HOT and can cause serious burn injuries. Figure 20 NOTE Be sure to retain the motor output shaft key. 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.

  • Page 12: Version Motor Replacement

    Figure 22 BURN HAZARD! DO NOT TOUCH the motor while operating, or shortly after being turned off. Motors may be HOT and can cause serious burn injuries. 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...
  • Page 13 With key (Figure 27, item 3) in keyway on motor shaft (Figure 27, item 4), slide new motor (Figure 27, item 1) and gear reducer (Figure 27, item 2) together. 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.

  • Page 14: Ce Version Gearmotor Replacement

    Remove gearmotor assembly from shaft and bracket. Retain key on gearmotor shaft. Replace gearmotor assembly in reverse order of removal. Tighten four screws to secure. Install end cap with socket head screw. 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 15: Service Parts

    US Version Side Mount Drive Package for 90° Gearmotors NOTE For replacement parts other than those shown in this section, contact an authorized Dorner Service Center or the factory. Key Service Parts and Kits are identified by the Performance Parts Kits logo .

  • Page 16: Ce Version Side Mount Drive Package For 90° Gearmotors

    Mounting Bracket 921040MSS Socket Head Screw, M10-.50 x 40 mm 960820MSS Hex Head Cap Screw, M8-1.25 x 20 mm 960840MSS Hex Head Cap Screw, M8-1.25 x 40 mm 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 17: Version Gearmotor Assembly

    917-104 Stainless Steel Socket Head Cap Screw 10-32 x .25 for Painted Gearmotor 916-126 Stainless Steel Button Head Cap Screw 1/4-20 x .31 for Stainless Steel Gearmotor 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.

  • Page 18: Ce Version Gearmotor Assembly

    12-80 Hz, 149 RPM 73U010HS423EN Gearmotor, Variable Speed, 1.12 Kw 230/400V 3 Phase, 12-80 Hz, 224 RPM 73U007HS423EN Gearmotor, Variable Speed, 1.49 Kw 230/400V 3 Phase, 12-80 Hz, 298 RPM 7350 Series Side Mount 90° Drive Package Dorner Mfg. Corp. 851-679 Rev. C...

  • Page 19: Notes

    Notes 7350 Series Side Mount 90° Drive Package 851-679 Rev. C Dorner Mfg. Corp.

  • Page 20: Return Policy

    RMA will automatically close 30 days after being issued. To get credit, items must be new and undamaged. There will be a return charge on all items returned for credit, where Dorner was not at fault. It is the customer’s responsibility to prevent damage during return shipping.
