7350 Series Version 2
Positive Drive Conveyors
Installation, Maintenance and Parts Manual
For other service manuals visit our website at:
www.dornerconveyors.com/manuals-literature
Record Conveyor Serial Number Here
851-880 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AquaGard 7350 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorner AquaGard 7350 Series

Summary of Contents for Dorner AquaGard 7350 Series

  • Page 1 7350 Series Version 2 Positive Drive Conveyors Installation, Maintenance and Parts Manual For other service manuals visit our website at: www.dornerconveyors.com/manuals-literature Record Conveyor Serial Number Here 851-880 Rev. A...

  • Page 2: Table Of Contents

    Belt Returns Under 660 mm Wide ........ 39 Configuring Conveyor Belt Part Number ...... 40 Flat Belt Part Number Configuration ......40 Notes.................. 41 Return Policy ..............42 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 3: Introduction

    The Dorner Limited Warranty applies. CAUTION Dorner 7350 Series conveyors have patents pending. Some illustrations may show guards Dorner reserves the right to make changes at any time without notice or obligation. removed. DO NOT operate equipment without guards. Dorner has convenient, pre-configured kits of Critical Service Parts for all conveyor products.

  • Page 4: Warnings - General Safety

    Handle drive shaft keyway with care. It may be sharp and could puncture the skin, causing SEVERE HAZARD! serious injury. • Dorner cannot control the physical installation and application of conveyors. Taking protective measures is the responsibility of the user. • When conveyors are used in conjunction with...

  • Page 5: Product Description

    Product Description Refer to (Figure 1) for typical conveyor components. Conveyor Gearmotor Belt Support Stands Drive End Idler End Guides Figure 1 Figure 1 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 6: Specifications

    Auxiliary Shaft Exists Belt Type Profile D side Profile A side Idler Stand Location Drive Stand Location Drive Shaft Position Drive Tail Type Conveyor Length Conveyor Width Document Language 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 7: Conveyor Supports

    • Non-accumulating product • Product moving toward gearmotor • Conveyor being mounted horizontally • Conveyor being located in a dry environment • Conveyor equipped with standard belt only 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 8: Installation

    Join both conveyor sections and install connecting plates (Figure 4, item 1) with four screws (Figure 4, item 2) on both sides. Tighten to 14-16 ft-lbs (19-22 Nm). 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 9: Stand Installation

    Position the stands on a flat, level surface. Attach the stands (Figure 7, item 1) to the frame. Tighten to 14-16 ft-lbs (19-22 Nm). Figure 7 Figure 9 Figure 7 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 10: Return Shoe

    Figure 12 Figure 12 Figure 15 Repeat procedure for the opposite end of the conveyor to fully install the belt. Adjust bracket to engage belt. Tighten screws. 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 11: Belt Returns

    Repeat on the opposite side of the conveyor. Install belt return assembly (Figure 20, item 1) onto Figure 17 return brackets (Figure 20, item 2). Figure 20 Figure 17 Figure 20 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 12: Belt Returns Under 660 Mm Wide

    Install return clip (Figure 25, item 1) and loosely secure Carriage Bolt with nut (Figure 25, item 2). Figure 22 Figure 25 Figure 25 Repeat on the opposite side of the conveyor. Figure 22 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 13: Guide Installation

    Install the connecting plate (Figure 31, item 1) over the Guide Installation studs. Figure 31 High Side Guides Remove the top screw (Figure 28, item 1) from the conveyor side. Figure 28 Figure 31 Figure 28 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 14: Adjustable Guides

    Figure 35 Figure 33 Install the guide post (Figure 33, item 2) resting on lower screw (Figure 33, item 3). Reinstall top screw and tighten. Figure 35 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 15: Preventive Maintenance And Adjustment

    Conveyor Belt Replacement CAUTION WARNING Dorner recommends cleaning all the “food zones” prior to placing conveyor into service. Ensure adequate access is provided for cleaning and servicing equipment so that the required level of hygiene can be maintained.
  • Page 16 (Figure 41, item 1) to its maximum up position, and move locking lever (Figure 41, item 2) up to disengage lock. Lower tail slowly. Figure 41 Figure 38 Figure 41 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 17: Wear Strips

    Figure 44 Figure 44 Remove the wear strip (Figure 44, item 2) from the frame rail. Replace with new wear strip and self-tapping screws. 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 18: Drive Spindle Replacement

    Remove four headplate screws (Figure 46, item 1). Figure 49 Repeat on opposite side of the conveyor. Figure 46 Figure 49 Figure 46 Slide the headplate with bearing off the shaft. 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 19: Idler Spindle Replacement

    11. Repeat for opposite side headplate. 12. If necessary, refer to “Bearing Replacement” on page 21 for replacing bearing in each headplate. 13. Install parts in reverse order of removal. Figure 53 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.
  • Page 20 Figure 57 Figure 55 Slide off puck (Figure 55, item 2) and replace if worn. Repeat as needed. Figure 57 11. Install parts in reverse order of removal. 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 21: Bearing Replacement

    Insert bearing (Figure 58, item 1) into housing slot. Locate anti-rotation nub (Figure 58, item 3) to align Figure 60 with slot (Figure 58, item 2) and twist bearing into housing. 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.
  • Page 22 (Figure 64, item 2) away from each other. Figure 64 Figure 62 Repeat steps 3 through 5 as needed. Figure 64 Install belt return assembly in reverse order of removal. 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 23: Belt Returns Under 660 Mm Wide

    (Figure 66, item 2), and spacer (Figure 66, item 3) from return bracket (Figure 66, item 4). Figure 66 Figure 66 Replace worn or damaged parts. Install parts in reverse order of removal. 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 24: Service Parts

    Service Parts NOTE For replacement parts other than those shown in this section, contact an authorized Dorner distributor or Dorner directly. Recommended Critical Service Parts and Kits are identified by the Key Service Parts symbol . Dorner recommends keeping these parts on hand.
  • Page 25 WW = Conveyor width reference in inches 06 - 36 in 02 increments See Specifications chart on page 7 for conveyor belt widths. Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A...

  • Page 26: Tip-Up Idler Tail

    Service Parts Tip-Up Idler Tail 22 Idler Tail Kit 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...
  • Page 27 LLLLL = Part length in inches with 2 decimal places. Example: Part Length = 95.25" LLLLL = 09525 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev.

  • Page 28: Frame

    Service Parts Frame 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...
  • Page 29 LLLLL = Part length in inches with 2 decimal places. Example: Part Length = 95.25" LLLLL = 09525 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev.

  • Page 30: Connecting Assembly

    960810MSS Hex Head Cap Screw, M8-1.25 x 10 mm Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 31: 25 Mm High Sides

    Multiple Guide Sections Only) Example: Part Length = 95.25" LLLLL = 09525 990801MSS Hex Nut Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 518400-01-LLLLL-LH Guiding, Left Hand (for Multiple customerservice@dorner.com Guide Sections Only)

  • Page 32: Mm High Sides

    Multiple Guide Sections Only) Example: Part Length = 95.25" LLLLL = 09525 990801MSS Hex Nut Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 518400-03-LLLLL-LH Guiding, Left Hand (for Multiple customerservice@dorner.com Guide Sections Only)

  • Page 33: 152 Mm High Sides

    Multiple Guide Sections Only) Example: Part Length = 95.25" LLLLL = 09525 990801MSS Hex Nut Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or 518400-06-LLLLL-LH Guiding, Left Hand (for Multiple customerservice@dorner.com Guide Sections Only)

  • Page 34: Fully Adjustable Round Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1387 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg.

  • Page 35: Tool-Less Fully Adjustable Round Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1470 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev.

  • Page 36: Fully Adjustable Flat Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1387 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg.

  • Page 37: Tool-Less Fully Adjustable Flat Guides

    807-015 Rail Clamp Service parts can be obtained through your distributor or directly 807-1470 Cross Block Clamp from Dorner Mfg. Corp. (800) 397-8664 or 960812MSS Hex Head Cap Screw, customerservice@dorner.com M8-1.25 x 12 mm 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev.

  • Page 38: Belt Returns 660 Mm Wide And Wider

    LLLLL = Part length in inches with 2 decimal places. Example: Part Length = 95.25" LLLLL = 09525 Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg.

  • Page 39: Belt Returns Under 660 Mm Wide

    990801MSS Hex Nut 550369 Puck Kit (Includes item 2) Service parts can be obtained through your distributor or directly from Dorner Mfg. Corp. (800) 397-8664 or customerservice@dorner.com 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 40: Configuring Conveyor Belt Part Number

    From the model number determine the conveyor width (WWW), length (LLLLL) and belt type (BB). Use data to configure belt part number as indicated below. 73P1-WWW-LLLLL / BB 73P1- (Fill In) 7350 Series Version 2 Positive Drive Conveyors Dorner Mfg. Corp. 851-880 Rev. A...

  • Page 41: Notes

    Notes 7350 Series Version 2 Positive Drive Conveyors 851-880 Rev. A Dorner Mfg. Corp.

  • Page 42: Return Policy

    Return Policy Returns must have prior written factory authorization or they will not be accepted. Items that are returned to Dorner without authorization will not be credited nor returned to the original sender. When calling for authorization, please have the following information ready for the Dorner factory representative or your local distributor: Name and address of customer.
