- Page 1 AV over IP Extender User Manual Model : HKM02BP-4K 4K HDMI KVM & USB, RS232 , IR, Audio over PoE Extender Smart Cabling & Transmission Corp. V1.0_2010160...
- Page 2 HKM02BP-4K Introduction HKM02BP-4K uses AV over IP technology to route up to 1,000 4K HDMI sources to up to 60,000 displays over IGMP and Jumbo frame protocol gigabit PoE switches, which can achieve HDMI signal extending, distributing, switching and routing.
-
Page 3: Installation View
User Manual HKM02BP-4K Installation view... -
Page 4: Panel View
User Manual HKM02BP-4K Panel view HKM02BT-4K HKM02BR-4K Panel Button Function Button Menu Reduce Number Increase Number Short Press Enter Menu/Cancel Press 1 seconds Carry Decomposition Press 3 seconds Lock/Unlock Button(When no OSD menu) Press and hold then power on Factory Default... - Page 5 User Manual HKM02BP-4K MSG/IR LED Status Indication Times HKM02BP-4K MSG LED Always ON IR control, RS232 control, system setting IR control disabled Transmitters channel conflict DHCP server not found Rest to factory default Engineering mode / Firmware update mode Manufacture setting mode...
- Page 6 User Manual HKM02BP-4K System Default Casting Mode/IP Settings Casting Mode Transmitter / receiver support Unicast and Multicast two mode, default is Multicast. In Multicast mode it could be one to one, one to multi, multi to on or multi to multi applications.
- Page 7 User Manual HKM02BP-4K IR Remote Control Setting You could use the IR infrared remote control to preset channel selection and other menu function. Using the IR remote control aim to the front panel of receiver or external IR receiver cable will be ok.
-
Page 8: Ir Remote Control Operation
User Manual HKM02BP-4K IR Remote Control Operation Select Channel: Mode 1: use or or or to select channel and press ENTER to confirm. Mode 2: enter the channel number and press ENTER to confirm the input channel. Select Menu Function: Mode 1: press MENU then use ... - Page 9 User Manual HKM02BP-4K IR Menu Function List Menu Description Option / Remark System Information System Information Network Information Network Information Function Information Function Information Control Information Control Information Video & Audio Video & Audio Information Information RS232 Control RS232 Control Information...
- Page 10 User Manual HKM02BP-4K 2 = Auto Analog Input Volume Analog Input Volume 0 = Mute 1 ~ 100 = Volume % Analog Output Volume Analog Output Volume 0 = Graphic Mode Video Quality Video Quality setting 1 ~ 5 = Mode 1 ~ 5...
- Page 11 User Manual HKM02BP-4K Auto Sort Favorites Auto Sort Favorites Channel Sort Favorites Sort Favorites Channel Immediately sort favorite channel Scan Channel To Scan Channel To Favorites Favorites Direct Access Menu Run menu function even hide Menu Item “Advanced 0 = Disable Display/Hide “Advanced Menu”...
- Page 12 User Manual HKM02BP-4K Caution of IR Menu Function Menu 17 Free Routing function only works in Multicast mode. Menu 22 When disable USB extender function it will also disable keyboard mouse function. Menu 25 Display or hide TV wall setting in the webpage.
- Page 13 User Manual HKM02BP-4K Menu 200 Will not backup the parameters of men function 107 Save Video Wall. Menu 333 Will clear the parameters of men function 107 Save Video Wall. RS232 Control In RS232 extender mode, user could use RS232 port of transmitters to operate/setup the receivers at same channel by program like Hyper Terminal which built-in Windows XP and before version.
- Page 14 User Manual HKM02BP-4K NAME CLR Clear all channel name NAME IMPORT Import channel name FAST ? Status of current fast switch FAST [ ENABLE | DISABLE ] Enable/disable fast switch CHECK ? Status of channel conflict check CHECK [ ENABLE | DISABLE ] Enable/disable channel conflict check Usage of favorite channel (MAX.32)
- Page 15 User Manual HKM02BP-4K COLUMN [ 0~15 ] Set position in column STRETCH ? Status of stretch type STRETCH [ 0~2 ] Set stretch, 0 = Auto, 1 = Stretch Out, 2 = Fit In ROTATE ? Status of rotate type...
- Page 16 User Manual HKM02BP-4K KEY [ 0~32 ] = address, command Set mapping of third party IR remote KEY IMPORT Import IR key setting BLOCK ? Status of IR quick block BLOCK [ ENABLE | DISABLE ] Enable/disable IR quick block...
- Page 17 User Manual HKM02BP-4K RESOLUTION Status of video resolution VERSION Status of firmware version BAUD ? Status of auxiliary baudrate 0=115200, 1=57600, 2=38400… 9=300 BAUD [ 0~9 ] NEWLINE ? Status of auxiliary newline AUXILIARY NEWLINE [ 0~3 ] 0=Linux, 1=Windows, 2=Mac, 3=Other...
-
Page 18: Keypad Control
User Manual HKM02BP-4K Keypad Control You can use RS232 Keypad or terminal program with number key to emulate IR remote operation. Before using RS232 keypad you have to select Keypad by Menu 50 RS232 Select, and set keypad baudrate by Menu 54 Auxiliary Baudrate. - Page 19 User Manual HKM02BP-4K IP Setting You could input the IP address of transmitter / receiver at link column of browser which printed in the label. If the label is missing or not able to identify you can check the IP address as below:...
- Page 20 User Manual HKM02BP-4K Web configuration System Version Information Firmware version and other information Update Firmware Click “Select File” to browse firmware at local disk drive then click “Upload” to start update. During update the web will shows the status as above message. Updated unit will reboot automatically after updating firmware.
- Page 21 User Manual HKM02BP-4K Utilities Factory Default Set system to factory default Reboot Reboot system Default EDID Set EDID to default 1080p 7.1 channel audio Console API Command Enter Console API command to change setting or control...
- Page 22 User Manual HKM02BP-4K Statistics Indicate system status...
-
Page 23: Video Wall
User Manual HKM02BP-4K Video Wall: Basic Setup Bezel and Gap Compensation: Set outer width/height of monitor and width/height of viewable area. OW: outside width OH: outside height VW: viewable width VH: viewable height Please note: 1. The viewable width/height must be less than the outside width/height. - Page 24 User Manual HKM02BP-4K Advance Setup: ...
- Page 25 User Manual HKM02BP-4K Before enter “Advanced Setup”, please complete the “Basic Setup” as follows: In “Basic Setup”, select Vertical and Horizontal Monitor Count. 2. In “Advanced Setup”, choose the target of the video wall to control Step 2: Control Options Reset to Basic Setup: ...
- Page 26 User Manual HKM02BP-4K Clockwise Rotate: Setup the rotation angle 0,180, 270 degree of the video output Screen Layout (Row x Column): Set up the number of vertical and horizontal monitor based on the video wall layout. Vertical number 1~8 and horizontal number 1~16.
- Page 27 User Manual HKM02BP-4K Horizontal/Vertical Shift: Horizontal/Vertical Scale Up Horizontal Shift: Set the video horizontal shift, Left or Right by pixels. Vertical Shift: Set the video vertical shift, Up or Down by pixels. Horizontal Scale Up: Set the video horizontal scale up by pixels.
- Page 28 User Manual HKM02BP-4K Network: IP Setup: IP Mode could be Auto IP, DHCP, Static three mode Host default setting is Static IP, client default setting is Auto IP For mass deploying please use static or DHCP mode. Notice: if there is no DHCP server in network the host/client will keep reboot, you need to set the host/client to factory default Press channel button “-”...
- Page 29 User Manual HKM02BP-4K Functions for Transmitter: Video over IP Enable Video over IP: This function setup the video signals send from network. Enable Video Wall: This function setup the video wall, default is not checked. Maximum Bit Rate: Set maximum bit rate.
- Page 30 User Manual HKM02BP-4K Serial over IP： Enable Serial over IP: setup Serial (RS232) signal sends from network Operation Mode:Default is “Type 2 (Recommended. Dumb redirection.)” Baudrate Setting for Type 2 : default is 115200, 8, None, 1...
- Page 31 User Manual HKM02BP-4K Functions for Receiver: Video over IP Enable Video over IP: This function setup the video signals send from network. Copy EDID from this Video Output: Copy EDID from TV when booting (unicast mode only), ...
- Page 32 User Manual HKM02BP-4K USB over IP: Enable USB over IP: Enable/disable USB extender function. Operation Mode: Set USB operation mode. Recommand Auto select mode. Compatibility Mode: Set USB compatibility mode. ...
-
Page 33: Troubleshooting
User Manual HKM02BP-4K Troubleshooting Transmitter/receiver boot time require 30 seconds and will be able to control after booting, First time reboot after reset to default will be longer than 30 seconds. Not recommend to work with existing LAN connection to avoid large video, data transmission or multicast packets to slow down your other LAN devices. -
Page 34: Package Include
User Manual HKM02BP-4K Package Include HKM02BT-4K Package Include: Transmitter x 1 pcs USB A to B cable x 1 pcs IR emitter cable x 1 pcs HKM02BR-4K Package Include: Receiver x 1 pcs IR emitter cable x 1 pcs IR remote control x1 pcs... -
Page 35: Specification
User Manual HKM02BP-4K Specification ITEM NO. HKM02BPT-4K HKM02BPR-4K Support Compliance HDCP 2.2, USB 1.1, USB 2.0 Max. Video Resolution 4K@30Hz 4:4:4 Max. Transmission Distance 150M over CAT5e Cable or Greater 7.1 LPCM 192kHz, Dolby True HD, DTS-HD Master Audio, ATMOS,...
