SCOPIA Elite 5200 Series MCU
Maintenance Guide
Version 7.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCOPIA Elite 5200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RADVision SCOPIA Elite 5200 Series

Summary of Contents for RADVision SCOPIA Elite 5200 Series

  • Page 1 SCOPIA Elite 5200 Series MCU Maintenance Guide Version 7.7...
  • Page 2 If there is any software on removable media described in this publication, it is furnished under a license agreement included with the product as a separate document. If you are unable to locate a copy, please contact RADVISION Ltd and a copy will be provided to you.

  • Page 3: Table Of Contents

    Installing or Replacing the MCU Redundant Power Supply Unit ........9 Backing Up Your SCOPIA Elite MCU Configuration ............ 13 Restoring Your SCOPIA Elite MCU Configuration............13 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 Table of Contents| i P/N 61546-00011...

  • Page 4: Performing Hardware Maintenance

    Performing Hardware Maintenance The SCOPIA Elite 5200 Series MCU contains replaceable units, which allow for quick and efficient maintenance of the system. Before starting the maintenance, carefully read the Safety Guide for the SCOPIA Elite MCU for detailed safety and electrostatic discharge (ESD) precautions.

  • Page 5: Replacing The Mcu Chassis

    Power off the MCU and disconnect it from the power outlet. Step 2 Take the required antistatic precautions to avoid static electricity damages. This includes reading the Safety Guide for the SCOPIA Elite 5200 Series MCU and among other precautions wearing a wrist strap. Step 3 Remove the grounding cable from the MCU chassis and disconnect all other connections.

  • Page 6: Replacing The Mcu Media Blade

    Before You Begin You can order a replacement media blade by contacting your local RADVISION representative. Use the part number listed in this table, and state the version of your MCU. The replacement blade must be programmed with a software version compatible with the one used in the media blade currently installed in the MCU.
  • Page 7 Power off the MCU. Disconnect it from the power outlet. Disconnect all other cables. Step 3 Take the required antistatic precautions to avoid static electricity damages. This includes reading the Safety Guide for the SCOPIA Elite 5200 Series MCU and among other precautions wearing a wrist strap. Step 4...

  • Page 8: Replacing The Mcu Control Blade

    Procedure Step 1 Take the required antistatic precautions to avoid static electricity damages. This includes reading the Safety Guide for the SCOPIA Elite 5200 Series MCU and among other precautions wearing a wrist strap. Step 2 Unscrew the retention screws of the control blade (see Figure 1-1 on page 2).
  • Page 9 To install or replace the fan drawer, you need these parts and tools: • A grounding strap • A replacement fan drawer. To order, contact your local RADVISION representative using the reference listed in this table. Table 1-4 Ordering a replacement fan drawer for SCOPIA Elite 5200 Series...
  • Page 10 Make sure that the fan drawer is inserted up to the stop. Turn the fan drawer knob clockwise to lock the fan drawer in the chassis. Performing Hardware Maintenance | 7 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 P/N 61546-00011...

  • Page 11: Cleaning Or Replacing The Mcu Air Filter

    8) and slide the filter drawer out of the chassis (Figure 1-6 on page Figure 1-5 Unscrewing the fan drawer panel Performing Hardware Maintenance | 8 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 P/N 61546-00011...

  • Page 12: Installing Or Replacing The Mcu Redundant Power Supply Unit

    Verify you have the following equipment: • A cross head screwdriver 2x100mm long (or different length) • A slot head screwdriver 3.5x100mm (or longer) Performing Hardware Maintenance | 9 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 P/N 61546-00011...
  • Page 13 • An antistatic wrist strap • A PSU. To order, contact your local RADVISION representative using the reference listed in this table. Table 1-5 Replacement power supply for SCOPIA Elite 5200 Series MCU Name Part number SCOPIA Elite 5200 Series MCU AC Power Supply...
  • Page 14 11). Inspect the PSU to verify that it is not damaged and that the blue connector pins are intact. Figure 1-9 Opening the PSU handle Performing Hardware Maintenance | 11 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 P/N 61546-00011...
  • Page 15 LED location. Turn the redundant PSU on, and check that its LED lights green. Step 16 Replace the PSU cover. Performing Hardware Maintenance | 12 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 P/N 61546-00011...

  • Page 16: Backing Up Your Scopia Elite Mcu Configuration

    The restore procedure causes all current configuration to be permanently lost. The system restarts automatically. All active conferences are disconnected. Step 7 Select OK to complete the restore procedure. Performing Hardware Maintenance | 13 RADVISION | Maintenance Guide for SCOPIA Elite 5200 Series MCU Version 7.7 P/N 61546-00011...
  • Page 17 F +44 20 3178 5717 F +852 2801 4071 infoUSA@radvision.com infoUK@radvision.com infoAPAC@radvision.com This document is not part of a contract of license as may be expressly agreed RADVISION is registered trademarks of RADVISION, Ltd. All trademarks recognized. All rights reserved © 2011 RADVISION, Ltd.
