  • Page 1 Activate Your Warranty By Registering TODAY!!! 9281 LeSaint Drive • Fairfield, Ohio 45014 Phone (513) 874-2818 • Fax (513) 874-2914 Sales: 1-800-543-7166 T120-II HydroSeeder ® Parts and Operator’s Manual Model SB Serial No. _____________ LBT120-SB...
  • Page 2 NOTES...
  • Page 3 IF FINN CORPORATION DOES NOT HAVE YOUR COMPLETED REGISTRATION FORM ON FILE, YOUR WARRANTY CLAIM WILL BE DENIED. Once your Finn equipment has been registered, your Finn Limited Warranty will be activated per the warranty statement on the other side of this notice.
  • Page 4 (except those referred to herein) that are manufactured any representation or promise on behalf of Finn Corporation or to by Finn to be free from defects in material and workmanship for a modify the terms or limitations of this warranty in any way.

  • Page 5: Table Of Contents

    Definition of Hydroseeding ........6 The Finn HydroSeeder® & How It Works ......6 Mounting The HydroSeeder®...
  • Page 6 INDEX Continued . . . PARTS SECTION ........39-79 Notes .

  • Page 7: Safety First

    SAFETY FIRST With any piece of equipment, new or used, the most important part of its operation is SAFETY! Finn Corporation encourages you and your employees to familiarize yourselves with your new equipment and to stress safe operation. The first six pages of this manual are a summary of all the main safety aspects associated with this unit.

  • Page 8: Safety Summary Section

    The FINN HydroSeeder® is designed to mix and apply water, seed, fertilizer, agricultural lime and hydraulic mulch to the prepared seedbed. The resultant slurry from mixing one or more of the above materials may react causing harmful or deadly gasses within the tank.
  • Page 9 6. Operator(s) equipment 3. Recirculation valve must be open and material flow- should never ride on the ing back into the tank when using the remote valve. A machine at speeds of greater closed or plugged recirculation line will cause extreme than 5 MPH (8 kmh).
  • Page 10 29 CFR 1910.146. Including the following: 9. It is recommended that only authorized genuine FINN Drain, flush and ventilate tank interior. replacement parts be used on the machine. Turn off engine and disconnect battery cables and perform lockout/tagout procedures.
  • Page 11 FIGURE 1 - Current Set of Safety Decals...

  • Page 12: Definition Of Hydroseeding

    OPERATION AND MAINTENANCE MANUAL FOR ® THE FINN T120 HYDROSEEDER This manual gives you step-by-step instructions for the operation and maintenance of the Finn T120 ® HydroSeeder . For best results and to insure longer life of the equipment, please follow the instructions care- fully. For your safety read the entire manual before operating this unit.

  • Page 13: Attachments

    Mounting the HydroSeeder® to the truck must allow for tire clearance as well as frame twist. Place hard wood spacers along the length of truck rails or use Finn spring mounting kit (#011562) or equivalent. ® C. Place chains over the HydroSeeder and around truck bed and secure with binders.

  • Page 14: Pre-Start Check

    ® 3. Hose Reel. The live hose reel will mount either on the HydroSeeder or on the truck frame. The 200 foot (60.96 m) capacity electric rewind reel will wind up and store empty hose. It can be electrically ® connected to the HydroSeeder battery.
  • Page 15 Turn thumb nut clockwise until stem rises to maximum height. b) Remove cap and fill cap with sodium (water soluble) base grease. (FINN part num- ber 000698). DO NOT use lithium base (chassis lube) grease. c) Replace cap.

  • Page 16: Two Valve Operation

    TWO VALVE OPERATION: The T120 HydroSeeder ® is equipped with two independently operated ball valves to control slurry flow. One is located in the recirculation line below the platform, and the other is located in the discharge line above the platform. The recirculation valve is open when the handle is in line with the valve ports and is closed when the handle is at a right angle to the valve ports.
  • Page 17 CLOSED Figure 4- Discharge Through Boom or Extension Hose Through Boom 3. EXTENSION HOSE OR HOSE REEL THROUGH REMOTE PORT: Flow is through recirculation with no flow through closed discharge valve (Figure 3). Flow through extension hose is controlled by engaging and disengaging slurry pump clutch, or by remote valve at end of hose. Open recirculation valve allows flow back into tank. OPEN FLOW FLOW...

  • Page 18: Starting Procedure

    ® The following tables on page 13 show loading versus coverage rates for the Finn HydroSeeder . Table A shows rates for “one step” applications. The coverage area is determined by the fiber mulch capacity of the ®...
  • Page 19 TABLE A USING SEED, FERTILIzER AND MULCH Unit Amount of Material in Tank (pounds(kilograms)) Coverage Area Seed Fertilizer Mulch (sq. ft.(sq.m.)) T120 II 115 (52) 133 (60 500 (227) 14,520 (1,350) Above Table is based on 1,500 pounds (680.39 kg) of mulch, 400 pounds (181.44 kg) of fertilizer and 345 pounds (156.49 kg) of seed ((8 pounds (3.6287 kg)/1000 square feet) per acre.

  • Page 20: Tank Capacity Chart

    T120 II Gallons in. (cm) from in. (cm) from (Liters) bottom 1150 (4353) 9.25 (23.5) 42.75 (108.6) 1180 Gallons 1100 (4163) 11 (27.9) 41 (104.1) 1050 (3975) 12.5 (31.8) 39.5 (100.3) 1000 (3785) 14 (35.6) 38 (96.5) 950 (3596) 15.5 (39.4) 36.5 (92.7) 900 (3407) 10 (25.4)
  • Page 21 3. Piping System Cleanout Procedure (Purging Line): A. Remove discharge nozzle and gasket from discharge boom. B. Aim discharge boom assembly into an open area away from any persons, obstructions or high voltage power lines. C. Open discharge valve and close recirculation valve. D.

  • Page 22: Prior To Application

    PRIOR TO APPLICATION: 1. Operator should familiarize self with area to be seeded and develop a plan to insure uniform applica- tion. 2. Develop a plan for communication between operator and driver of the carrying or towing vehicle to sig- nal for start, stop, turn, etc. through the use of the signal horn. 3.

  • Page 23: Ii. Discharge Through The Boom

    4. Generally the most remote area of the seed bed should be covered first. Distance is controlled by engine speed and nozzle selection. Do NOT partially close the valve to control the distance. 5. While moving along area to be seeded, the operator should move the nozzle back and forth in a slow, even arc.

  • Page 24: Reloading Procedure

    B. EXTENSION HOSE SYSTEM - WITHOUT REMOTE VALVE: 1. Connect the extension hose into the end of the discharge boom. 2. A person controlling the end of the hose directs a second operator at the machine to control the clutch and adjust the engine speed. CAUTION: Since the extension hose will be seeing the full output of the pump with the recirculation closed, the equipment operator and indi- vidual at the end of the hose should exercise extreme care when operating unit on high pressure. The high pressure on the hose...
  • Page 25 7. Engage the clutch, and move the throttle to full engine speed. A stream of water should be coming from the end of the recirculation pipe beside the hatch opening, as well as from the boom. 8. As soon as both streams are clear, close the discharge valve and make sure water is being recirculated back to the tank.

  • Page 26: Cleaning And Maintenance

    CLEANING AND MAINTENANCE: AFTER FIRST 4-8 HOURS OF OPERATION: 1. Check and adjust clutch - see page 27. 2. Re-torque wheel lugs - again after 7 days. (Trailer option only). DAILY: ® 1. Cleaning the HydroSeeder A. Fill the slurry tank to the center of the agitator shaft. B.

  • Page 27: Seasonal & Winter Storage Maintenance

    12. Add fuel stabilizer to fuel tank. HYDRAULIC SYSTEM: The hydraulic system on your Finn HydroSeeder® is designed to give trouble free service, if maintained. The most important areas of maintenance are the hydraulic oil and filtration. The reservoir holds 19 gallons of ISO Grade 46 hydraulic oil.
  • Page 28 VIEW SEE VIEW (Showing Hose Reel) Figure 7 - Lubrication & Adjustment Points...

  • Page 29: Lubrication & Fluids Chart

    LUBRICATION AND FLUIDS CHART (Reference Figure 7) Ref. No. Location Lubricant Frequency Number Check Grease Level in Pressure Lubricator Daily Check Clutch Lever Bearings Daily Grease Agitator Shaft Bearings Daily Grease Discharge Swivels Daily Check Engine Oil Level Daily Change Engine Oil and Filter See Engine Manual Grease Pump Bearings Weekly...

  • Page 30: Clump Maintenance

    CLUMP MAINTENANCE: CAUTION: Clump maintenance should to be done only while engine is not running, and battery cables are disconnected. Figure 8 - Clump Assembly Components...
  • Page 31 CLUTCH/PUMP ASSEMBLy (Reference Figures 8 and 9) Ref. No. Part Number Description No. Req’d 005146 Suction Cover X0824SS Suction Cover Bolt Y08SS Suction Cover Nut 005150 O-Ring 005543 Impeller 006443 Mechanical Seal Assembly 005144 Pump Casing X0824SS Suction Cover Bolt W08FSS Suction Cover Washer 006444 Grease Retainer Seal 005446...

  • Page 32: Pump Maintenance

    PUMP MAINTENANCE SECTION: (Reference Figures 5 and 6) CAUTION: Pump maintenance to be done only while engine is not run- ning, and battery cables are disconnected. Figure 9 - Cross-Section Through Clump A. FACTORY-TOLERANCES. 1. To check pump tolerances loosen the two clamps on the pump suction piping and remove the inlet elbow. Through the pump suction hole, insert a feeler gauge between the pump impeller (3) and the suction cover (1).

  • Page 33: Clutch Maintenance

    C. CLEANING. 1. To clean pump impeller (3), loosen the two victaulic pipe clamps and remove the suction pipe assembly. The eye of the impeller can then be seen through the suction cover plate (1) and is readily accessible for cleaning. 2.
  • Page 34 HANDLE PRESSURE: Variation in handle length directly affects the pressure required at the handle for proper clutch adjust- ment. See the table below to determine the correct handle pressure. Reference Pressure Clutch Size Handle Length at Lever 7-1/2" 7-5/8" 110 to 130 Lbs IMPORTANT: A new clutch generally requires several adjustments until the friction surfaces are worn in.

  • Page 35: Trouble Shooting Your Hydroseeder

    1. Disengage the clutch operating lever and remove the old facing plates (30). 2. Insert the new facing plates (three segments) in between the clutch body (34) and the pressure plate (29), and center the facings as close as possible. 3.
  • Page 36 2. Plugging or clogging: DANGER: Turn off engine and disconnect battery cables before working on equipment. Serious injury or death can result from moving parts or high pressure spray. Sometimes when a stoppage occurs, you will not be able to find anything in the line. When this happens, it means that the system became airbound instead of plugged. To remedy this, see “Foaming”. Plugging can occur in any one of four places;...
  • Page 37 ® TROUBLE SHOOTING YOUR HYDROSEEDER Problem Probable Causes Suggested Solutions LEAKS: Tank bearing Leaks. Lack of lubrication - seal Replace seal and follow lube worn. schedule. Bolts not tightened. Tighten uniformly to 25 ft. lbs. Properly. Pressure Clamps. Rubber seal cracked, Replace, always grease seal before pinched or torn.
  • Page 38 ® (CONTINUED) TROUBLE SHOOTING YOUR HYDROSEEDER Problem Probable Causes Suggested Solutions CLUTCH CONT’D: Pump looses prime - Pump worn. Reset pump tolerance page 22. lacks distance - leaves excessive amount in Suction partially plugged. Clean out machine see page 16. tank (100 gal (378 liters) or more).
  • Page 39 ® (CONTINUED) TROUBLE SHOOTING YOUR HYDROSEEDER Problem Probable Causes Suggested Solutions PUMP: Excessive wear. Fertilizer with highly Change fertilizer. Avoid abrasive abrasive filler. fillers. Overloading machine Load machine to recommended with dry material. capacities. Too much time allowed After loading and mixing has been between loading and completed, set agitator at 1/2 speed discharging.

  • Page 40: T120 Skid-Mount/Trailer Hydroseeder® Technical Specifications

    T120 SKID-MOUNT HYDROSEEDER® TECHNICAL SPECIFICATIONS 6′8″ (203 cm) 12′10″ (391 cm) 8′5″ (257 cm) T120 TRAILER HYDROSEEDER® TECHNICAL SPECIFICATIONS 7′4″ (223 cm) 18′7″ (568 cm) 9′8″ (294 cm)
  • Page 41 FINN T120 SKID & TRAILER-MOUNTED HyDROSEEDER® TECHNICAL SPECIFICATIONS POWER ............Diesel Kubota V1505, 33.5 hp (25 kw), 4 cylinder water-cooled ENGINE SAFETY SYSTEM ......Low oil pressure, high temperature shutoff TANK SIZE ............1,1800 gallon (4,468 liter) liquid capacity 1,000 gallon (3,785 liter) working capacity FUEL TANK CAPACITY ........ 15 gallon (57 liter) PUMP ............Centrifugal 4"...

  • Page 42: T120 Gooseneck Trailer Hydroseeder® Technical Specifications

    T120 GOOSENECK TRAILER HYDROSEEDER® TECHNICAL SPECIFICATIONS 7′ (214 cm) 20′9″ (633 cm) 9′10″ (300 cm)
  • Page 43 FINN T120 GOOSENECK TRAILER HYDROSEEDER® TECHNICAL SPECIFICATIONS POWER ............Diesel Kubota V1505, 33.5 hp (25 kw), 4 cylinder water-cooled ENGINE SAFETY SYSTEM ......Low oil pressure, high temperature shutoff TANK SIZE ............1,1800 gallon (4,468 liter) liquid capacity 1,000 gallon (3,785 liter) working capacity FUEL TANK CAPACITY ........ 15 gallon (57 liter) PUMP ............Centrifugal 4"...

  • Page 44: Notes

    NOTES...
  • Page 45 T120 HydroSeeder ® Parts Manual Model SB...
  • Page 46 NOTES...
  • Page 47 T120 STRAIGHT PULL TRAILER PICTORIAL REFERENCE HOSE REEL OPERATOR’S PLATFORM Hose Reel Assembly ......Pages 64-65 Operator’s Platform ......Pages 52-53 Hydraulic System w/Hose Reel ..Pages 66-67 Discharge Boom Assembly....Pages 68-69 Nozzles, Remote Valve & Tool Kit ... Page 79 Control Box Wiring......Pages 70-71 STRAIGHT PULL TRAILER Straight Pull Trailer......
  • Page 48 T120 GOOSENECK TRAILER PICTORIAL REFERENCE HOSE REEL OPERATOR’S PLATFORM Hose Reel Assembly ......Pages 64-65 Operator’s Platform ......Pages 52-53 Hydraulic System w/Hose Reel ....66-67 Discharge Boom Assembly....Pages 68-69 Nozzles, Remote Valve & Tool Kit ... Page 79 Control Box Wiring......Pages 70-71 TRAILER Gooseneck Trailer ......
  • Page 49 T120 SKID PICTORIAL REFERENCE OPERATOR’S PLATFORM HOSE REEL Hose Reel Assembly ......Pages 64-65 Operator’s Platform ......Pages 52-53 Hydraulic System w/Hose Reel ..Pages 66-67 Discharge Boom Assembly....Pages 68-69 Control Box Wiring......Pages 70-71 Nozzles, Remote Valve & Tool Kit ... Page 79 SKID PIPING, CLUMP &...
  • Page 50 VIEW B VIEW C OPERATOR’S PLATFORM (See Pages 52-53) VIEW C SEE VIEW D VIEWS E & F (Page 45) (Page 45) VIEW A WHEEL & HUB ASSEMBLY (See Pages 54-55) WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 51 VIEW E VIEW F VIEW D 40, 41 & 42 STRAIGHT PULL TRAILER Ref. No. Part Number Description No. Req’d 080701 Jack Weldment w/Bracket 041007 Tow Ring F120-0005 Tank Top 190047 Foam Gasket 3/8" x 1-1/4" (Order By Foot) F120-0006 Hatch Safety Rail 012833 Poly Hatch 005433 Soft Latch 012834...
  • Page 52 VIEW A VIEW B SEE VIEW A VIEWS E & F VIEW D (Page 47) (See Page 47) VIEW C WHEEL & HUB ASSEMBLY (See Pages 56-57) WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 53 VIEW E VIEW F VIEW D 34, 35 & 36 GOOSENECK TRAILER Ref. No. Part Number Description No. Req’d 004798 Trailer Jack 004798A Trailer Jack Handle 005614-09 Jack Extension Shaft 005614-08 Coupling Tube 005169 Clevis Grab Hook 190007 Safety Chain 005710 Coupling Link 012833 Poly Hatch 005433 Soft Latch...
  • Page 54 VIEW A See View A WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 55 GOOSENECK RAILING Ref. No. Part Number Description No. Req’d 004799 Gooseneck Coupler 005617 Front Cross Rail 005599 Gooseneck Deck Rail 005596 Slide Gate 005600 Right Rear Rail 005598 Left Rear Rail 005698 Tool Box Mount Weldment 052160 Tool Box 005619 U-Bolt For 1-1/4" Pipe FW71225 3/8"...
  • Page 56 VIEW B VIEW C VIEW A 24, 25 & 26 SEE VIEWS B & C OPERATOR’S PLATFORM (See Pages 52-53) SEE VIEW A WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 57 SKID Ref. No. Part Number Description No. Req’d 012833 Poly Hatch Assembly 005433 Soft Latch 012834 Bag Cutter - Stainless Steel F120-0005 Tank Top 190047 Foam Gasket 3/8" x 1-1/4" (Order By Foot) F120-0006 Hatch Safety Rail 005600 Right Rear Rail 005596 Slide Gate 005652 Front Cross Rail 052136-07...
  • Page 58 VIEW B VIEW A VIEW C WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 59 VIEW D VIEW E OPERATOR'S PLATFORM Ref. No. Part Number Description No. Req’d 005538 Right Rear Rail Weldment 002258 Clamp Handle Weldment 012487-05 Boom Clamping Strap 005161 Rubber Strap w/S-Hooks 005533 Gate Weldment 005532-03 Spacer 012052 Gate Spring 005532-05 Hinge Mounting Strap 005462-03 Platform Right Toe Rail 005540 Left Rear Rail Weldment 005534-01...
  • Page 60 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 61: Wheel & Hub Assembly

    WHEEL AND HUB ASSEMBLY (STRAIGHT PULL TRAILER) Ref. No. Part Number Description No. Req’d 005741 Axle, 8000# (Includes Hub, Drum & Brakes) WL8-285-10 Hub and Drum Assembly 2 per WL46-32 Oil Cap Plug 1 per WL21-35 Oil Cap 1 per WL10-45 O-Ring 1 per WL19-2 Cotter Pin 1 per WL006-176-00 Spindle Nut...
  • Page 62 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 63 WHEEL AND HUB ASSEMBLY (GOOSENECK TRAILER) Ref. No. Part Number Description No. Req’d 005637 Axle Assembly (Includes Hub, Drum & Brakes) WL8-219-4 Hub and Drum Assembly WL605 Grease Cap 1 per WL19-2 Cotter Pin 1 per WL6-1 Spindle Nut 1 per WL5-57 Spindle Washer 1 per WL14125A Outer Bearing 1 per...
  • Page 64 BEARING ASSEMBLY NOTE: BEARING ASSEMBLY (ITEM #1) INCLUDES ITEMS #2 THRU #11. AGITATOR SHAFT THROUGH BACKSIDE NOTE: TO TIGHTEN, TURN NUT NOT BOLT. TORQUE TO OUTSIDE 25 FT. LBS. OF TANK WALL DO NOT OVER TORQUE. AGITATOR SHAFT ASSEMBLY NOTE: AGITATOR SHAFT ASSEMBLY (ITEM #12) INCLUDES ITEMS #13 THRU #23.

  • Page 65: Agitator Assembly

    TOE GUARD DETAIL AGITATOR ASSEMBLY Ref. No. Part Number Description No. Req’d 007420 Bearing & Seal Assembly (Includes Items 2 Thru 11) 0Y08SS Agitator Nut 4 per 012605 Bevel Sealing Washer 4 per 007211 Flangette w/Lube Coupling 1 per 007705 Grease Fitting 1 per 003022 Bearing 1 per...
  • Page 66 *NOTE: See Page 62 For Hydraulic System Schematic. HYDRAULIC AGITATOR DRIVE Ref. No. Part Number Description No. Req’d 070660 Hydraulic Motor 070660K 1/4" x 5/16" x 1-1/2" Key 005463 Torque Arrestor Plate 004630 Rubber Bushing X0824 1/2-13 UNC x 1-1/2" Lg. Hex Hd. Cap Screw Y08L 1/2-13 UNC Lock Nut 023156...

  • Page 67: Trailer Wiring

    TRAILER PLUG LH BRAKE ASSY TAIL LIGHTS (BROWN) NOT USED RIGHT LEFT WHITE BROWN TURN TURN (GREEN) (YELLOW) BLACK GROUND ELECTRIC BRAKES (WHITE) (BLACK) BROWN BROWN WHITE STARTER BLACK WHITE BROWN RH BRAKE ASSY TRAILER WIRING Ref. No. Part Number Description No. Req’d 075592 7-Blade RV-Style Trailer Plug 023424 Breakaway Switch...
  • Page 68 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 69: Hydraulic System

    HYDRAULIC SYSTEM Ref. No. Part Number Description No. Req’d REF ONLY Hydraulic Reservoir 080329 Hydraulic Level Sight Gauge 004900 Filler Breather Cap 023616 Straight Adapter 005551 Fill Adapter Hose 160763 Reducer Bushing 011466 Suction Strainer 041162 Pipe Nipple 021802 Adapter Union 021559 Ball Valve 012358 Male 90°...
  • Page 70 NOTE: ITEM #1 (HOSE REEL ASSEMBLY) INCLUDES ITEMS #2 - 9. VIEW A WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 71 HYDRAULIC HOSE REEL ASSEMBLY (OPTION) Ref. No. Part Number Description No. Req’d 008212H Hydraulic Hose Reel and Swivel Assembly 008212A Hose Reel 080302 Flanged Riser 080302G Hose Reel Riser Gasket 008144 Hose Reel Ring Gear 008200 Hose Reel Chain w/Connecting Link - 69" Lg. 008433 Pin Lock w/Brackets Assembly 008313 Idler Side Bearing 008314...
  • Page 72 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 73 HyDRAULIC SySTEM w/HOSE REEL Ref. No. Part Number Description No. Req’d REF ONLY Hydraulic Reservoir 080329 Hydraulic Level Sight Gauge 004900 Filler Breather Cap 023616 Straight Adapter 005551 Fill Adapter Hose 160763 Reducer Bushing 011466 Suction Strainer 041162 Pipe Nipple 021802 Adapter Union 021559 Ball Valve 012358 Male 90°...
  • Page 74 NOTE: ITEM #1 INCLUDES ITEMS #2 - 10. WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 75: Discharge Boom Assembly

    DISCHARGE BOOM ASSEMBLY Ref. No. Part Number Description No. Req’d 005529 Discharge Boom Assembly Consisting of: 006102 2” Female Coupler 006514 2" Coupler Gasket 005734 Boom Pipe Weldment Z0632SCP Boom Handle Set Screw 080559-01 Boom Handle 005528-03 Boom Collar Weldment Z0612SCP Boom Collar Set Screw 007286 Discharge Boom Balance Spring 007288...
  • Page 76 BLACK GROUND GREEN TIMER HOURMETER HORN GLOW PLUG INDICATOR LIGHT BLACK SAFETY SWITCH BROWN RED/BLACK BLUE Brown/ Yellow/ Blue Black Black Yellow Black Black/ Orange Brown Orange/ Blue/ Red/ Black Black Black WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 77: Control Box Wiring

    CONTROL BOX WIRING Ref. No. Part Number Description No. Req’d 005604 Control Box Assembly 007274 Hour Meter 022119 Safety Switch KU15694-65990 Glow Plug Timer 020886 Horn Button KU15403-64490 Glow Plug Indicator Light 006245 Generator Light KU66711-55131 Ignition Key Switch KU66711-55140 Ignition Key (Not Included w/Switch) 023604 Electrical Housing 023601...
  • Page 78 CLUTCH/PUMP (See Pages 74-75) WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 79: Piping

    PIPING Ref. No. Part Number Description No. Req’d 005682 Clutch/Pump Assembly (See Pages 74-75 for Parts) 002383 Pressure Lubricator 005470 Pump Shaft Guard 006144 Pipe Clamp 006145 Clamp Gasket 006359 90° Pipe Elbow 005524-02 Suction Pipe Elbow Weldment 008280 Suction Line Shut-Off Valve 005523-06 Connector Pipe 006710...
  • Page 80 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 81: Clutch/Pump Assembly

    CLUTCH/PUMP ASSEMBLy Ref. No. Part Number Description No. Req’d 005682 Clutch/Pump Assembly Consisting of: 005146 Pump Suction Cover 005150 O-Ring 005543 Pump Impeller 006443 Mechanical Shaft Seal 005144 Pump Casing 006444 Grease Retainer Seal 005446 Flange Pilot Bearing 005447 Shaft Seal 005475 Thrust Bearing Retainer 005544-02 Bearing Retainer Gasket 005670...
  • Page 82 DETAIL A DETAILS B, C & D (See Page 77) WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...

  • Page 83: Engine & Radiator

    DETAIL B DETAIL C DETAIL D 18 (REF) 33 34 ENGINE & RADIATOR Ref. No. Part Number Description No. Req’d 031354 Air Cleaner Assembly KU15741-11080 Air Filter Element KU01123-50835 Bolt 055548 Mounting Band 022450 2-1/2" Worm Gear Clamp KU16616-11621 Air Cleaner Inlet Pipe 005681-07 Air Cleaner Extension Pipe F90-0012 Sheet Metal Hanger KU15501-72400...

  • Page 84: Engine Wiring

    FUEL PUMP GLOW PLUGS WHITE WHITE BLUE SHUT DOWN HORN SYSTEM TEMPERATURE SWITCH SWITCH BROWN ALTERNATOR HOSE REEL LEAD 16 Ga. Orange Brown Green Blue 12 Ga. Black BROWN ORANGE BLACK BLUE Blue Black Green Yellow 12 Ga. 16 Ga. GROUND STRAP YELLOW...
  • Page 85 Narrow Ribbon Nozzle Assembly 012117 Narrow Ribbon Nozzle 006096 Brass Adapter 160762 Reducer Bushing 004593 Drain Plug 006102 Brass Coupler 006514 Coupler Gasket 97898-70870 Kubota (Model V1505-BBS-SAE-1) Diesel Engine Parts Manual Finn T120-SB HydroSeeder ® Parts and Operator’s Manual LBT120-SB WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 86 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT120-SB...
  • Page 87 DECALS R ef. No. Part Number Description No. Req’d 023174 "FINN" Decal - Large 012661-04 "T120" Decal 011595 "Hydro Seeder" Decal 022199 "Throttle" Decal 011567 "Do Not Aim . . ." Decal 007230-02 "Service Daily" Decal 007230 "Service Daily" Decal 023391 "Diesel Fuel Only" Decal...
