MikroTik LHG R Quick Start Manual
Hide thumbs Also See for LHG R:

Advertisement

Quick Links

LHG R
LHG R
(RBLHGR)
LHG R without factory installed modem, you can choose your own solution.
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
All installation methods for mounting an access point on any wall surface is subject to the acceptance of local jurisdiction.
The Installation of the equipment must comply with local and national electrical codes.
This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.
Exposure to Radio Frequency Radiation: This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
uncontrolled environment. This MikroTik device should be installed and operated no closer than 120 centimeters from your body, occupational user, or the
general public.
Quickstart
1.
While holding the unit by its central column, apply force to the tab, which holds the latch closed, until the latch pops open.
2.
Insert the SIM card into the slot, with chips facing UP.
3.
Install your desired modem.
4.
Assemble case by attaching legs to the base of the unit, please see
5.
Mount unit in your desired place, please see
6.
Connect an Ethernet cable to the Ethernet port, connect the other end of the Ethernet cable to the included PoE injector.
7.
Plug the PoE injector into your PC.
8.
Plug the included power supply into the PoE injector to start up the device. please see the
9.
Set LAN computer IP configuration to
10.
Open
 https://192.168.88.1
11.
User name: a
dmin
and there is no password by default you will be logged in automatically to the Quick Set screen.
12.
Update the device by clicking the "Check for updates" button on the right side and updating your RouterOS software to the latest version to
ensure the best performance and stability. Must have a valid SIM card inserted.
13.
To manually update the device, please
14.
Choose MIPSBE packages for this device and download it to your PC.
15.
Upload downloaded packages to the WebFig "Files" menu and reboot the device. Updating your RouterOS software to the latest version will
ensure the best performance, stability, and security updates.
 Mounting
paragraph.
  automatic
(DHCP).

in your web browser to start the configuration.
go https://mikrotik.com/download
 Case
assembly
paragraph.
powering
paragraph.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LHG R and is the answer not in the manual?

Questions and answers

Summary of Contents for MikroTik LHG R

  • Page 1 Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed. Exposure to Radio Frequency Radiation: This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an uncontrolled environment. This MikroTik device should be installed and operated no closer than 120 centimeters from your body, occupational user, or the general public.
  • Page 2: Expansion Slots And Ports

    Expansion slots and ports One 10/100 Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X). Either straight or crossover cable can be used for connecting to other network devices. The Ethernet port accepts 9-30 V DC powering from a passive PoE injector. MiniPCIe slot and SIM slot (can't be used separately) to be used with a 3G/4G/LTE modem.
  • Page 3 To access the miniPCIe slot, the opening of the unit's top cover is required. As an opening tool, you can use a large size flat head screwdriver or a small coin. Be extremely cautious when opening, because the incorrect opening of the clip can break it off! Mounting and configuration of this device should be done by a qualified person.
  • Page 4 Attach provided a thick thermal pad to the card, and install the card into miniPCIe slot so that the thermal pad is between PCB and card. Insert your desired card. The secure card in place using previously removed two screws. Attach the black uFL connector to the MAIN antenna connector of the modem, attach the gray cable to the DIV connector.
  • Page 5: Reset Button

    Slide the included metallic mounting rings into the two slots on the back of the antenna dish. Attach the unit to a pole, with the Ethernet port pointing downward. Use a PH2 screwdriver to tighten the rings. Fix the Ethernet cable to the pole using zip ties, less than one meter from the unit, to avoid the cable being pulled out of the port. Check mounting angle and positioning.
  • Page 6: Mode Button

    For more information about this product, specification and pictures please visit our web page: https://mikrotik.com/product/lhg_r Accessories Operating system support The device supports RouterOS software version 6. The specific factory-installed version number is indicated in the RouterOS menu /system resource. Other operating systems have not been tested. MikroTik mobile app...
  • Page 7: Federal Communication Commission Interference Statement

    Use the MikroTik smartphone app to configure your router in the field, or to apply the most basic initial settings for your MikroTik home access point. To avoid pollution of the environment, please separate the device from household waste and dispose of it in a safe manner, such as in designated waste disposal sites.
  • Page 8 Информация о дате изготовления устройства указана в конце серийного номера на его наклейке через дробь. Первая цифра означает номер года (последняя цифра года), две последующие означают номер недели. Изготовитель: Mikrotikls SIA, Aizkraukles iela 23, Riga, LV-1006, Латвия, support@mikrotik.com. Сделано в Китае, Латвии или Литве. Cм. на упаковке.
  • Page 9 WLAN et LTE conformément aux réglementations ETSI. Pour plus d'informations, voir la déclaration de conformité ci-dessus / Questo dispositivo MikroTik è conforme ai limiti massimi di potenza di trasmissione WLAN e LTE in conformità con le normative ETSI. Per ulteriori informazioni, consultare la dichiarazione di conformità...
