EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v6.49.1 or the latest version to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be professionally installed
This is Wireless Network Device. You can find the product model name on the case label (ID).
Please visit the user manual page on
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, brochures, and more info about products at
Configuration manual for software in your language with additional information can be found
MikroTik devices are for professional use. If you do not have qualifications please seek a
Depending on the antenna used, you must set its gain. This is to ensure that EIRP meets the limit set by the local authorities. This is done in the WebFig Quickset
menu.
This Device accepts input of a 24V DC power adapter, which is provided in the original packaging of this device. This Device can be powered using a PoE injector
(Provided in the packaging).
First steps:
Connect the device to the included PoE injector with Ethernet cable;
Connect the PoE injector into the PC;
Connect the power adapter to the PoE injector;
Download WinBox configuration tool
Open WinBox and connect to the device;
Default IP: 192.168.88.1, user name:
wireless passwords on the
Download the latest RouterOS software from
Choose MIPSBE packages, and save them to your PC;
Open WinBox and upload downloaded packages, drag and drop into any windows;
Restart the device;
QuickSet
Connect again and in the
Secure your device and set a strong password.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the
correc
t hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 40 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
Note:
English, For some models, check the user and wireless passwords on the sticker.
Bulgarian, За някои модели проверете потребителската и безжичната парола на стикера.
Czech, U některých modelů zkontrolujte uživatelské a bezdrátové heslo na štítku.
Danish, For nogle modeller skal du kontrollere bruger- og trådløs adgangskoder på mærkaten.
German, Überprüfen Sie bei einigen Modellen die Benutzer- und Wireless-Passwörter auf dem Aufkleber.
Greek, Για ορισμένα μοντέλα, ελέγξτε τους κωδικούς πρόσβασης χρήστη και ασύρματης σύνδεσης στο αυτοκόλλητο.
Spanish, Para algunos modelos, verifique las contraseñas de usuario e inalámbricas en la etiqueta.
Estonian, Mõne mudeli puhul kontrollige kleebis olevaid kasutaja- ja traadita ühenduse paroole.
Finnish, Joissakin malleissa tarkista käyttäjän ja langattoman verkon salasanat tarrasta.
French, Pour certains modèles, vérifiez les mots de passe utilisateur et sans fil sur l'autocollant.
Croatian, Za neke modele provjerite korisničku i bežičnu lozinku na naljepnici.
Hungarian, Egyes modelleknél ellenőrizze a felhasználói és vezeték nélküli jelszavakat a matricán.
Italian, Per alcuni modelli, controlla le password utente e wireless sull'adesivo.
Icelandic, Athugaðu notanda- og þráðlausa lykilorðin á límmiðanum fyrir sumar gerðir.
Norwegian, For noen modeller, sjekk bruker- og trådløse passord på klistremerket.
Lithuanian, Kai kuriuose modeliuose patikrinkite vartotojo ir belaidžio ryšio slaptažodžius ant lipduko.
https://mt.lv/um
for the full up-to-date user manual. Or scan the QR code with your mobile phone.
https://mt.lv/winbox
;
admin
, no password, or use
sticker);
https://mikrotik.com/download
menu set your Country, to apply country regulation settings;
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
https://mikrotik.com/products
at https://mt.lv/help
consultant https://mikrotik.com/consultants
Neighbors tab and connect with MAC address (or, for some models, check user and
;
.
