Specifications

• Feed-back Voltage: 1-Phase, 2-Wire, 230Volt Ac, (+/- 10%)
• AC Mains Supply Line Frequency: 50/60 Hz.
• Current input: Selectable 1A or 5A for load.
• Auxiliary Supply: 1-Phase, 230V (+/- 10%).
• Correction time:
Selectable in Seconds from 1 Sec. to 65530 Sec.
• Output Commands: 4 (APFC-05/4) or 6 (APFC-05/6)
or 8 (APFC-05/8).
(Isolated 'NO' contacts of rating Inductive Load 0.5A/250Vac).
• Operating Temperature: 0 to +55
• Storage temperature: 0 to +70
• Relative Humidity: 10% to 95% (Non Condensing).
• AC Mains Supply frequency: 47Hz to 53Hz,or 57Hz to 63Hz.
Mechanical
dimensions:
All Dimensions
given are in mm.
Recommended size for cut-out on panel door is 92 x 92 mm.
Max. weight: (with clamps and terminals) = Approx. 0.6 Kgs.
TAS POWERTEK PVT.LTD.
C.
o
C.
o
96
96
VERSION 1.0
- 3 -
91
100
Updated on: FEB. 18, 2015
91
