Steps -- 26 - TAS POWERTEK APFC-05 User Manual

Step
Steps connected
: 08
Default mode
Auto :0
Compensation kVAr
Mean :1
Cap Bank Voltage
0415 V
Correction Time
Seconds :00010
Discharge Time
Seconds :00060
Step Response Time
Cycles : 00045
Fix-Bank Setting
_ _ _ _ _ _ _ _
Bin/C / E Series Bank kVAr
: 200
Ext Fix Bank
KVAr : 000
Correction Type
C Series : 2
C – Series : 00
11111111111111
E - Series
1488888888888888
Unequal Bank [1]
KVAr = 050
Unequal Bank [2]
KVAr = 050
Unequal Bank [3]
KVAr = 050
Unequal Bank [4]
KVAr = 050
Unequal Bank [5]
KVAr = 050
Unequal Bank [6]
KVAr = 050
Unequal Bank [7]
KVAr] = 050
Unequal Bank [8]
KVar = 050
TAS POWERTEK PVT.LTD.
Steps Connected: Defines the number of steps
operational. Depending on PF system banks, this
parameter is set.
• Default Mode: 0: Auto and 1: Manual. This parameter
defines the mode during Power up. (Default is 0: Auto)
• Compensation kVAr: 0:Instantaneous & 1:Mean.
Defines the method for kVAr compensation. If it should be
instant at which the compensation is made or it is mean
of kVAr that is required from previous
present compensation.
• Capacitor Bank Voltage: Capacitor bank voltage line to
line value is defined here. i.e. it defines the Voltage value
at the defined kVAr.
• Correction Time: Defined in seconds. This is the Time
between two consecutive kVAr compensations.
• Discharge Time: Time defined here is the time for
discharge of the capacitors to a level, so that they can be
turned ON again.
• Step Response Time: Defines the time after which the
kVAr of any step should be measured when the step turns
on .
• Fix-Bank Setting: Defines the banks that are to be
declared as fixed. These banks even in spite of
overcompensation cannot be turned OFF. The banks can
only be turned OFF under fault conditions. (if settings in
fault are defined).
• Correction Type: APFC-05 can have bank configurations
that are defined by four various methods. 0=Binary,
1=Unequal, 2=C Series, 3=E Series.
Binary is in ratio of 1:2:4:8:16---.
Un-equal is used with banks not having definite ratio.
C series is predefined Control Series. The standard
ratios are preloaded in APFC-05 that can be selected here.
E series is User defined Control Series. The bank ratios
that are not defined in C series can be defined here.
Digits can be 1,2,-- 9,
VERSION 1.0
- 26 -
compensation to
continued..
Updated on: FEB. 18, 2015
