Front fascia
Keyboard
Keyboard with soft touch keys are provided on the front facia
of the controller. The various keys are:
TAS POWERTEK PVT.LTD.
–
UP key. Used to scroll up the menu screen;
increment values when entering numbers.
Also used for changing the status of banks.
DOWN key. Used to scroll down the menu
screen; decrement values when entering
numbers. Also use to change status of bank.
RIGHT key. Used to shift the cursor to right;
also used to increase the contrast of LCD in
default display screen mode.
LEFT key. Used to shift the cursor to left;
also used to decrease the contrast of LCD in
default display screen mode.
ENTER key. Used for entering a submenu
or for setting up values.
PROGRAM key. Used for selecting modes
of operation and editing of parameters
MEMORY key. Used to save all changes
made in Edit Parameters menu.
VERSION 1.0
- 14 -
Updated on: FEB. 18, 2015
