STMicroelectronics PREFERRED
SALESTYPES
FULLY INSULATED PACKAGE (U.L.
COMPLIANT) FOR EASY MOUNTING

DESCRIPTION

The TIP122FP is a silicon Epitaxial-Base NPN
power transistor
configuration mounted in Jedec TO-220FP fully
molded isolated package. It is intented for use in
power linear and switching applications.
The complementary PNP type is TIP127FP.

ABSOLUTE MAXIMUM RATINGS

Symbol
V Collector-Base Voltage (I
CBO
V Collector-Emitter Voltage (I
CEO
V Emitter-Base Voltage (I
EBO
I Collector Current
C
I Collector Peak Current (t
CM
I Base Current
B
P
Total Dissipation at T
tot
V Insulation Withstand Voltage (RMS) from All
isol
Three Leads to External Heatsink
T Storage Temperature
stg
T Max. Operating Junction Temperature
j
For PNP types voltage and current values are negative.
March 2003
COMPLEMENTARY SILICON POWER
in monolithic Darlington
Parameter
= 0)
E
= 0)
B
= 0)
C
< 5 ms)
p
≤ 25 o
C
case
≤ 25 o
T C
amb
DARLINGTON TRANSISTORS
INTERNAL SCHEMATIC DIAGRAM
R Typ. = 5 KΩ
1
NPN
PNP
TIP122FP
TIP127FP
3
2
1
TO-220FP
Typ. = 150 Ω
R
2
Value
TIP122FP
TIP127FP
100
100
5
5
8
0.1
29
2
1500
-65 to 150
150
Unit
V
V
V
A
A
A
W
W
V
o
C
o
C
1/6
