- Page 1 BARCO PROJECTION 6000 IT FOR SERIES NIVERSAL ROJECTORS R9841550 NSTALLATION ANUAL 15032002 R5976452/01...
- Page 2 Barco nv Intelligent Displays Noordlaan 5, 8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.35.86.51 E-mail: presentations.bid@barco.com Visit us at the web: www.barco.com Printed in Belgium...
- Page 3 Copyright © All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or stored in a retrieval system without the prior written consent of BARCO.
-
Page 5: Revision Sheet
Revision Sheet Barco nv Intelligent Displays Noordlaan 5, 8520 Kuurne Phone: +32 56.36.82.11, Fax: +32 56.35.86.51 E-mail: presentations.bid@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5976452/01): page wrong correct R5976452 U 6000 LCD P 15032002... -
Page 7: Safety Warnings
Do not exceed the indicated maximum total lifetime of the lamp for safe operation in normal power mode. Do not use it longer ! Always replace the lamp with the BARCO lamp kit for 6500 projectors. R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002... - Page 8 1. Safety R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
-
Page 9: Kit Content
The mechanical design allows to shift the lamp unit by means of two adjustments, hereby insuring the best optical performances of the lamp in both projector configurations. This kit is designed for the 6500(R+G), 6400i and SIM6(HB) projectors. 2.2 Partslist of the Kit Partslist overview Depending on the Kit ordered, R9841550 single lamp R98415501 12 pack R98415502 60 pack... - Page 10 2. Kit content 2.3 Illustration of the Lamp Universal lamp Image 2-1 R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
- Page 11 3. Access to the lamp unit 3. ACCESS TO THE LAMP UNIT 3.1 Removing the protection cover What has to be done ? • The lamp house door has to be opened and removed. • The lamp protection cover has to be removed. Make sure that the projector is turned off ! Never open the lamp house when the projector is on! Necessary tools flat screwdriver of 5 mm...
- Page 12 3. Access to the lamp unit Image 3-2 How to remove the protection cover 1. Loosen with a screwdriver the 3 indicated bolts. (image 3-3) 2. Pivote the plate a little downwards. (image 3-4) 3. Take out the protection cover. Image 3-3 Image 3-4 Hot surface !
- Page 13 4. Removing the old lamp unit 4. REMOVING THE OLD LAMP UNIT 4.1 Extracting the lamp unit Necessary tools No tools. How to remove the lamp unit ? 1. Slide the lamp unit backwards. (image 4-1) 2. Take out the lamp unit and put it on the table. (image 4-2) 3.
- Page 14 4. Removing the old lamp unit R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
- Page 15 5. Installing the lamp unit 5. INSTALLING THE LAMP UNIT 5.1 Installing What has to be done ? a) the lamp has to be adjusted according to the mounting configuration of the projector b) the lamp has to be placed in the projector housing and has to be connected Do not touch the front lamp glass with your fingers since this can reduce the light output of the lamp ! If the glass is touched, finger prints can be removed by cleaning the lamp with alcohol.
- Page 16 5. Installing the lamp unit Image 5-4 Image 5-3 Switching from CM (Ceiling Mount) to TM (Table Mount) Image 5-5 Ceiling Mount configuration Table Mount configuration Placing and connecting the lamp 1. Place the lamp in the housing (as shown on the image). 2.
- Page 17 5. Installing the lamp unit Image 5-7 reference holes R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
- Page 18 5. Installing the lamp unit R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
- Page 19 6. Closing the lamp house 6. CLOSING THE LAMP HOUSE 6.1 Mounting the covers Necessary tools flat screwdriver of 5 mm Mounting the protection cover 1. Put the protection cover on its place. (image 6-1) Warning: Warning : be careful for the lamp power cable. Do not stick this cable between the protection cover and the lamp house 2.
- Page 20 6. Closing the lamp house Image 6-3 Image 6-4 R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
-
Page 21: Additional Operations
7. Additional operations 7. ADDITIONAL OPERATIONS 7.1 Reset Lamp Run time Resetting the lamp run time Reset lamp run time is only allowed when a new lamp is installed. How to reset the lamp run time ? 1. Start up the projector. 2. - Page 22 7. Additional operations Image 7-2 Image 7-1 R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
- Page 23 Index INDEX content Illustration Additional operations partslist purpose Cover 5, 13 mounting Lamp 5, 9 removing access installing Lamp run time reset Filters Lamp unit 7, 13 cleaning the dust filters closing extracting removing Installing lamp safety 3–4 R5976452 UNIVERSAL LAMP KIT FOR 6000 SERIES LCD PROJECTORS 15032002...
