ORIGINAL INSTRUCTIONS
OPERATOR'S MANUAL
R400
Rotavator
Part number 51487406
1
edition English
st
September 2018

Advertisement

Table of Contents
loading

Related Manuals for Kongskilde R400

Summary of Contents for Kongskilde R400

  • Page 1 ORIGINAL INSTRUCTIONS OPERATOR’S MANUAL R400 Rotavator Part number 51487406 edition English September 2018...

  • Page 2: Table Of Contents

    Contents 1 GENERAL INFORMATION Note to the owner................1-1 Intended use.
  • Page 3 Power Take-Off (PTO) drive shaft guards ..........6-4 Selectatilth gearbox .

  • Page 5: General Information

    NOTICE: Always use genuine KONGSKILDE Service Parts or parts that match at least the same quality, reliability and functionality as the equivalent original Service Parts when you service and repair your implement and do not modify your implement without a written permission of the manufacturer.
  • Page 6 KONGSKILDE is not liable for any damage caused by the use of ''non-genuine” parts and accessories. Rely on your authorized dealer to supply you with genuine KONGSKILDE parts only. These parts are covered by our warranty and will give you the best performance.
  • Page 7 It is prohibited to carry out any modifications to the implement unless specifically authorized, in writing, by a KONGSKILDE representative. CLEANING YOUR implement When you use a high pressure washer, do not stand too close to the implement and avoid directing the jet at electronic components, electrical connections, breathers, seals, filler caps, and so on.

  • Page 8: Intended Use

    The KONGSKILDE rotavator is a tractor driven ground cultivator. No other use is intended. However over the years some models have been adapted for new uses, such as road-base preparation and semi-industrial mixing operations. The KONGSKILDE rotavator is designed to be attached to a tractor and driven by the Power Take-Off (PTO) of the tractor.

  • Page 9: Level Requirements For Operation, Service And Converting Activities

    KONGSKILDE dealer. Normal operation means the use of the machine for the Periodical service means activities that must be done at...

  • Page 10: Machine Orientation

    1 - GENERAL INFORMATION Machine orientation The terms "right-hand", "left-hand, "front", and "rear" are used in this manual to indicate the sides as they are seen from the operator seat. 1. Front 2. Right-hand 3. Rear 4. Left-hand ZEIL18TIL0284BA...

  • Page 11: Product Identification Number (Pin)

    The unit is identified by a serial number. Serial number, model and other specifications can be found on the PIN plate. Provide your KONGSKILDE dealer with the model and PIN when you order parts. Record the PIN on the front side of this manual for quick reference.

  • Page 12: Product Identification

    1 - GENERAL INFORMATION Product identification The implement is identified with a PIN (Product Identifica- tion Number). Serial number and model can be found on the PIN plate (1). According to the destination and speci- fication, additional data are given. ZEIL18TIL0284BA...

  • Page 13: Supplement

    1 - GENERAL INFORMATION Supplement Stability with the combination tractor - implement The combination of your tractor and implement can become unstable, due to the additional weight that the implement adds to the tractor. In order to guarantee stable and safe transport, you must check if you need ballast weights for transport and field work.
  • Page 14 1 - GENERAL INFORMATION ZEIL18HT00277FA Example of references to stability of the combination tractor – implement List of signs Te [kg] The tractor own weight. See operator’s manual of the tractor. Tf [kg] Front axle load with empty tractor. See operator’s manual of the tractor. Tr [kg] Rear axle load with empty tractor.

  • Page 15: Safety Information

    2 - SAFETY INFORMATION 2 - SAFETY INFORMATION###_2_### Safety rules and signal word definitions Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions.

  • Page 16: General Recommendations

    Once or missing decals immediately and place orders for an accident has occurred it is too late to think about these with your local KONGSKILDE dealer. Keep the what you should have done! safety decals free from dirt or grime.

  • Page 17: Fire Or Explosion Prevention

    2 - SAFETY INFORMATION Fire or explosion prevention 1. Crop material, trash, debris, bird nests or flammable non-flammable solvent before you weld or cut with a material can ignite on hot surfaces. flame. 2. Inspect the electrical system for loose connections or 5.

  • Page 18: Maintenance

    2 - SAFETY INFORMATION Maintenance • Raised equipment and/or loads can fall unexpectedly and crush persons underneath. Never enter or allow WARNING anyone to enter the area underneath raised equipment Maintenance hazard! during operation. Before you start servicing the machine, attach Unsupported hydraulic cylinders can lose pressure a DO NOT OPERATE warning tag to the ma- and drop the implement and cause a crushing hazard.

  • Page 19: Illustrations

    2 - SAFETY INFORMATION Hazardous chemicals 1. If you are exposed to or come in contact with haz- well as the information in this manual when you ser- ardous chemicals you can be seriously injured. vice the machine. The fluids, lubricants, paints, adhesives, coolant, 4.

  • Page 20: Driving On Public Roads And General Transportation Safety

    2 - SAFETY INFORMATION Driving on public roads and general transportation safety Comply with the relevant traffic regulations When transporting the implement attached to a tractor on public roads, ensure that you comply with the relevant local regulations. Travel may be restricted to certain road types. Transport may be restricted to daytime or outside peak traffic hours.
  • Page 21 2 - SAFETY INFORMATION Do not allow passengers Do not allow anyone to ride on the implement when it is being transported or while in operation.

  • Page 22: Ecology And The Environment

    KONGSKILDE dealer, who will dispose of the used • In general, avoid skin contact with all fuels, oils, acids, batteries or recycle the used batteries properly. In some solvents, etc.

  • Page 23: Safety Decals

    2 - SAFETY INFORMATION Safety decals The following safety signs are on your implement as a guide for your safety and for the safety of those who work with you. Walk around the implement and note the content and location of all safety signs before you operate your implement.
  • Page 24 2 - SAFETY INFORMATION Decal 1 Shut off the engine and remove the ignition key before performing maintenance or repair work. WARNING Avoid injury! Shut off the engine, remove the key, and make sure all machine motion stops before you ser- vice the machine.
  • Page 25 2 - SAFETY INFORMATION Decal 5 Risk of flying objects. Keep a safe distance from the implement as long as the engine is running. ZEIL18TIL1132AA Decal 6 Never touch the gearboxes, lubricant and other trans- mission components which may be hot enough to inflict burns.
  • Page 26 2 - SAFETY INFORMATION 2-12...

  • Page 27: Controls And Instruments

    3 - CONTROLS AND INSTRUMENTS 3 - CONTROLS AND INSTRUMENTS###_3_### Access to operator's platform Operating principles This chapter is not available.
  • Page 28 3 - CONTROLS AND INSTRUMENTS...

  • Page 29: Operating Instructions

    4 - OPERATING INSTRUCTIONS 4 - OPERATING INSTRUCTIONS###_4_### Starting the unit Connection to the tractor The rotavator has two mounting positions: the central po- sition (A) or the offset to the right-hand position (B). The offset mounting is achieved by repositioning the lower link mounting brackets.
  • Page 30 NOTE: If the PTO drive shaft halves have too little overlap, or if the male half bottoms out, it might be necessary to make alterations to the PTO drive shaft. Contact your local KONGSKILDE dealer for more info.

  • Page 31: Transport Operations

    5 - TRANSPORT OPERATIONS 5 - TRANSPORT OPERATIONS###_5_### Preparing for road transport Transport Power Take-Off (PTO) shaft For transport purposes dismantle and refit the Power Take-Off (PTO) drive shaft. For safety information see Page 2-6.

  • Page 32: Shipping Transport

    5 - TRANSPORT OPERATIONS Shipping transport Lifting the machine WARNING Crushing hazard! Use the machine lifting points when you lift and/or move the machine with heavy handling equipment. Lift the machine only from the indicated lifting eye hookup points. Always use adequate lifting equip- ment.

  • Page 33: Working Operations

    Rotor Depth control skids Hull The R400 rotavator is designed for tractors with an 18.39 – 55.16 kW (25 – 75 Hp) engine and a category I or cate- gory II linkage. The rotavator is driven by a Power Take-Off (PTO) shaft from a 540 RPM tractor PTO to a single speed or four speeds gearbox.

  • Page 34: Safety Guards

    6 - WORKING OPERATIONS Safety guards NOTE: The safety guards are not fitted at the factory due to freight limitations. NOTE: Fit all safety guards before operating. Operation is not permitted without safety guards fitted. ZEIL18TIL1135FA Working width Quantity Safety guard (1) Safety guard (2) 120 mm (4.72 in) 200 mm (7.87 in)

  • Page 35: Rotor And Blades

    6 - WORKING OPERATIONS Rotor and blades The L blades (1) and (2) are standard on all the R400 rotavators. The blade (1) is the left-hand blade and the blade (2) is the right-hand blade. The L blade is characterized by a good crumbling and mixing effect, suitable for a full cut.

  • Page 36: Power Take-Off (Pto) Drive Shaft Guards

    6 - WORKING OPERATIONS Power Take-Off (PTO) drive shaft guards The KONGSKILDE rotavator is supplied with a non-rotat- ing Power Take-Off (PTO) drive shaft which must be cor- rectly fitted and well maintained. Before and after each use, examine the PTO driven im-...

  • Page 37: Selectatilth Gearbox

    6 - WORKING OPERATIONS Selectatilth gearbox The selectatilth gearbox enables the rotor speeds to be altered by simply transposing or changing pairs of pick-off gears. The table below shows the range of pick-off gears avail- able and the rotor speeds resulting from their use. Gear (1) Gear (2) Roller RPM...

  • Page 38: Depth Control

    6 - WORKING OPERATIONS Working Depth control Adjust the side mounted skids (1) to regulate the tillage depth. ZEIL18TIL0284BA To adjust the skids proceed as follows: 1. Remove the bolt (2) from the adjusting bar (3). 2. There are four holes (4) on the adjusting bar. Change the hole to position the skid (1) to the required working depth.

  • Page 39: Adjustments

    6 - WORKING OPERATIONS Adjustments Through simple adjustments the rotavator will produce a range of tilths in most soil types and handle various cul- tivation techniques, for example weed control, seedbed preparation, trash and chemical incorporation. As a general principle a combination of a slow tractor speed and a lowered trailing board produces fine tilths.

  • Page 40: Working Operations

    1. Set the depth control skids to the required tillage depth (see Page 6-6). 2. Select a trial trailing board position and a rotor speed (only for R400 SS models) to give the type of tilth re- quired. 3. Engage the tractor Power Take-Off (PTO) and drive forward, progressively lowering the rotavator into the ground.

  • Page 41: Maintenance

    7 - MAINTENANCE MAINTENANCE###_7_### General information Recommendations Failure to follow recommended maintenance may jeopar- dise safety and will reduce the lifespan of the rotavator. Records of periodic maintenance are important as they detail when and who carried out the last maintenance and inspection.

  • Page 42: Lubrication And Maintenance

    2. Fill the gearbox to the level mark in the inside rod (2). The oil capacity is: ○ For R400 SM models: 1.5 L (0.40 US gal). ○ For R400 SS models: 3.5 L (0.92 US gal). NOTICE: Use only SAE 85W140 oil.

  • Page 43: Fluids And Lubricants

    Lubricant grade Item Capacity brand name specification specification Gearbox 1.5 L API GL-5 SAE 85W140 ( R400 SM models) (0.40 US gal) MIL-L-2105D 3.5 L Gearbox API GL-5 SAE 85W140 ( R400 SS models) (0.92 US gal) MIL-L-2105D API GL-5...

  • Page 44: Maintenance Planning

    7 - MAINTENANCE Maintenance planning Maintenance chart Grease Maintenance action Page no. Every 8 hours Power take-off (PTO) shaft and right-hand stub axle Every 40 hours Gearbox and side drive Every 500 hours Gearbox and side drive...

  • Page 45: Every 8 Hours

    7 - MAINTENANCE Every 8 hours Power take-off (PTO) shaft and right-hand stub axle Perform the lubrication every 8 h or once each day, whichever occurs first. Lubricant: SAE 85W140. Prior operation: Place the implement in safe conditions for maintenance. Lubricate the Power Take-Off (PTO) shaft (1) with a grease gun.

  • Page 46: Every 40 Hours

    7 - MAINTENANCE Every 40 hours Gearbox and side drive Perform the lubrication every 40 h or every week, whichever occurs first. Lubricant: SAE 85W140. Prior operation: Place the implement in safe conditions for maintenance. Top up the gearbox (1) with SAE 85W140. Top up the side drive (2) with SAE 85W140.

  • Page 47: Every 500 Hours

    7 - MAINTENANCE Every 500 hours Gearbox and side drive Perform the lubrication every 500 h. Lubricant: SAE 85W140. Prior operation: Place the implement in safe conditions for maintenance. Drain, flush and fill the gearbox (1) with SAE 85W140. Drain, flush and fill the side drive (2) with SAE 85W140. ZEIL18TIL1136FA...

  • Page 48: Storage

    7 - MAINTENANCE Storage Storage Disengage the Power Take-Off (PTO) drive, stop the tractor, apply the park brake and remove the key from the ignition before you detach the rotavator from the tractor. Disconnect the universal drive shaft and remove the hitch pins to detach the rotavator from the tractor.

  • Page 49: Troubleshooting

    8 - TROUBLESHOOTING TROUBLESHOOTING###_8_### Fault code resolution Troubleshooting Problem Possible Cause Correction Insufficient depth Insufficient depth. Adjust depth control equipment. obtained. Insufficient power. Use the lower tractor gear, reduce the rotor speed. The soil is too hard. Till the field a second time. Blades “trowelling”...
  • Page 50 8 - TROUBLESHOOTING...

  • Page 51: Specifications

    9 - SPECIFICATIONS SPECIFICATIONS###_9_### Technical data Number of Number of Rotor Working Transport Weight blades blades Tractor engine Model Gearbox width width speed (Rotavator) (Rotacadet) 80 cm 102 cm 245 kg 18.39 – 55.16 kW R400S - 80M (31.50 in) (40.16 in) (540.13 lb) (25 –...

  • Page 52: Torque

    9 - SPECIFICATIONS Torque Minimum hardware tightening torques (in N m or lb in /lb ft) for normal assembly applica- tions unless otherwise stated The minimum hardware tightening torque on drawings, in specifications, etcetera have priority. In the following tables, torque specifications are shown following the standard ENS7001, applicable for material class 8.8 and material class 10.9.
  • Page 53 9 - SPECIFICATIONS Flange head bolt/Flange nut Nominal Class 10.9 in N m (lb ft) Size 2.0 N·m (1.5 lb ft) 4.6 N·m (3.4 lb ft) 9.4 N·m (6.9 lb ft) 15.9 N·m (11.7 lb ft) 38.7 N·m (28.5 lb ft) 76.5 N·m (56.4 lb ft) 134 N·m (98 lb ft) 213 N·m (157 lb ft)
  • Page 54 9 - SPECIFICATIONS Metric hex nuts and locknuts, Classes (CL) 05 and upward NHIL14RB00663AA Metric hex nut identification markings • (1) – Manufacturer's identification • (3) – Property class • (2) – Clockwise type markings indicate property class and may include manufacturer identification (if applied), Example: property marks 240°...

  • Page 55: Fluids And Lubricants

    Lubricant grade Item Capacity brand name specification specification Gearbox 1.5 L API GL-5 SAE 85W140 ( R400 SM models) (0.40 US gal) MIL-L-2105D 3.5 L Gearbox API GL-5 SAE 85W140 ( R400 SS models) (0.92 US gal) MIL-L-2105D API GL-5...
  • Page 56 9 - SPECIFICATIONS...

  • Page 57: Accessories

    The rotavator is characterized by a high degree of cus- tomization, as the market requests implements to match specialized operations and needs. Blades By default, the rotor unit on R400 rotavators is equipped with L blades (1). a = 75 mm (2.95 in) b = 57 mm (2.24 in) c = 5.5 mm (0.22 in)
  • Page 58 10 - ACCESSORIES On the specific models R400–180 and R400–205 a rota- cadet unit (3) with C blades (4) is available. The rotacadet is a special rotor with four C blades (4) per flange. a = 40 mm (1.57 in) b = 114 mm (4.49 in)
  • Page 59 ZEIL18TIL0414AA Single or double tube The R400 rotavator is equipped with single tube (9) by default. In addition, the R400-140/155/165/180/205 models can be modified with a double tube (10).
  • Page 60 10 - ACCESSORIES Trailing board Two different types of trailing boards are available for the rotavator. In addition to the trailing board with chains (11), an op- tional trailing board equipped with springs (12) is avail- able. The springs allow the user to adjust the pressure on the trailing board, improving the levelling effect and also serve as overload protection.
  • Page 61 Index ###_Index_### Adjustments ......... . . Connection to the tractor.
  • Page 62 Safety decals ......... . Safety guards .
  • Page 64 Kongskilde dealer. © 2018 CNH Industrial Belgium N.V. All Rights Reserved. Kongskilde is a trademark registered in the United States and many other countries, owned by or licensed to CNH Industrial N.V., its subsidiaries or affiliates. Any trademarks referred to herein, in association with goods and/or services of companies, other than owned by or licensed to...
