TRANSIT ENTRY | INSTALLATION GUIDE
Connections
3.5.4 GENERAL PURPOSE OUTPUTS
Three general purpose inputs are available on the TRANSIT Entry reader. The
installed firmware may use these outputs for synchronous communication interfaces
such as Wiegand, Barcode and Magstripe. See chapter 3.4.3 for more details.
Connections
OUT1
General purpose output 1
OUT2
General purpose output 2
OUT3
General purpose output 3
GND
Ground
Figure 17: GPIO inputs
General purpose outputs
17/30
