  • Page 1 Reach installation guide 2021-06-14 | v4.8 | Doc. no. 5276888 www.nedapidentification.com...
  • Page 2 Copyright © Nedap N.V. All rights reserved. The information in this document is subject to change without notice, it is not to be reproduced in any way, in whole or in part, without the written consent of Nedap N.V. All trademarks...

  • Page 3: Table Of Contents

    Reach | installation guide Contents Introduction ..................................5 Firmware version ..............................5 Overview ................................... 5 Transit compatible mode............................6 Supported tags ................................. 7 Tag security ................................8 Installation ..................................9 Safety instruction ..............................9 Mounting instruction ..............................9 Antenna coverage ..............................10 Adjustable mounting bracket ..........................
  • Page 4 Reach | installation guide UHF frequencies ................................31 Frequency regulations ............................31 Frequency hopping ..............................31 Reader configuration ................................ 32 UHFTOOL software ..............................32 Settings ................................... 32 7.2.1 Read data ................................33 7.2.2 Decode Nedap-XS ............................. 34 7.2.3 Relay / timing ..............................35 7.2.4...

  • Page 5: Introduction

    UHF the uPASS Reach reader offers a cost effective and enduring solution for parking access. The system is based on an uPASS Reach reader and an UHF tag. The readers are installed next to the gate on a maximum height of 2 meters.

  • Page 6: Transit Compatible Mode

    This is very useful for anyone that has already developed an integration with NEDAP TRANSIT readers. The compatibility is ensured by embedding the TRANSIT processor in the uPASS Reach. This processor will support any firmware version developed for the TRANSIT reader, including P61, P81 and Q70. See separate TRANSIT firmware documentation.

  • Page 7: Supported Tags

    Reach | installation guide 1.4 Supported tags Any EPC Class 1 Gen 2 tag is supported by the uPASS Reach. NEDAP formatted UHF tags can have the following formats: NEDAP UHF Wiegand tags • These tags will contain all Wiegand information including facility code and parity bits. All Wiegand formats can be supported.

  • Page 8: Tag Security

    EPC number to ensure that the keys are different for each tag. Required is that the tags contain an EPC Gen2 V2 compliant RFID chip. Refer to NEDAP uPASS how to order guide for product numbers.

  • Page 9: Installation

    • Disconnect the power supply before removing or installing any parts. • To be sure of safety, do not modify or add anything to the uPASS Reach other than mentioned in this installation • guide or indicated by NEDAP N.V.

  • Page 10: Antenna Coverage

    Reach | installation guide 2.3 Antenna coverage The uPASS Reach antenna has a detection coverage area as shown in the picture below. The read range, which is up to 5 meters, can be adjusted by means of UHFTOOL software setting. See chapter 7.3.5.

  • Page 11: Adjustable Mounting Bracket

    2.4 Adjustable mounting bracket With the adjustable mounting bracket, the uPASS Reach can be ‘aimed’ at the desired detection area. It can also be used for mounting the reader to round or square masts (see appendix E for part numbers).

  • Page 12: Opening The Service Cover

    Reach | installation guide 2.5 Opening the service cover The service cover can be opened to access the connections (including the USB connector) and view the LED indicators. Open the screws on the bottom of the device to unlock the service cover. Once the service cover is unlocked, lift it off.

  • Page 13: Connections

    Reach | installation guide 3 Connections 3.1 Cable connections Cable connections to the uPASS Reach are made using the EMC cable glands. Assembly instructions Push the cap nut (1), seal insert (2) and gland contact socket (3) onto the cable.

  • Page 14: Wire Connections

    Reach | installation guide 3.2 Wire connections W ire connections to the uPASS Reach are user friendly spring cage terminal connectors. Connection procedure with spring cage terminal connectors. Strip wire lead for about 9 mm ( 0.35 inch Screwdriver Push the screwdriver straight down to release the spring cage.

  • Page 15: Communication

    In TRANSIT compatible mode these same connections are used. Remember that in this case the tags must be programmed in the NEDAP-XS format. Refer to the corresponding firmware manual for protocol details. Connections Wiegand...
  • Page 16 Reach | installation guide 3.4.1.1 Wiegand timing The figure below shows the Wiegand protocol timing. DATA-1 Timing constants Pulse interval time (Tpi) 1msec DATA-0 Pulse width time (Tpw) 50µsec Figure 13: Wiegand timing details 3.4.1.2 Magstripe timing The Magstripe (clock & data) interface follows the ISO7811/2 specifications. The figure below shows the timing for one character.

  • Page 17: Rs232 Connection

    Reach | installation guide 3.4.2 RS232 connection The uPASS Reach reader has an RS232 interface for communication with a host system or for configuring reader settings. Connections Receive data (input) Ground Transmit data (output) Maximum RS232 cable length of 15 meters (...

  • Page 18: Rs422 Connection

    Reach | installation guide 3.4.3 RS422 connection The uPASS Reach reader has an RS422 interface. The RS422 interface is similar to the RS232 interface. It shares the same communication protocol. The RS422 interface is commonly used when longer cable lengths are required.

  • Page 19: Rs485 Connection

    3.4.4 RS485 connection The uPASS Reach reader has an RS485 interface *. The RS485 interface can be used for point-to-point and multi-drop communication. * The RS485 interface is only available on uPASS Reach hardware revision C.07 and newer. Connections RS485 B (positive)
  • Page 20 Reach | installation guide RS485 multi-drop communication Multi-drop communication requires an addressable communication protocol, such as OSDP. For multi-drop communication disable the termination resistor (SW4-2 OFF) on all reader, except for the last reader. The termination resistor should be enabled on the last reader in a multi-drop communication system.

  • Page 21: Usb Connection

    Reach | installation guide 3.4.5 USB connection The uPASS Reach reader features an USB interface for service and installation purposes. The USB connector (Type B) is accessible behind the service cover. The USB interface can be used to configure the reader using the UHFTOOL software (as described in chapter 7.1).

  • Page 22: Digitial I/O

    Reach | installation guide 3.5 Digitial I/O 3.5.1 Relay output By default, the relay output is automatically activated upon identification of a tag. In OSDP operation, the relay output is set with command OSDP_OUT output #0. When the TRANSIT compatible processor is selected, the relay output is controlled by this processor. Please refer to the corresponding firmware manual for details.

  • Page 23: Read Disable Input

    3.5.2 Read disable input The reading of the uPASS Reach can be completely disabled with the RDIS input. This input is commonly used in combination with a sensor (e.g. inductive loop) that detects the presence of a person or vehicle. Use a potential-free (relay) contact to connect the internal 5V to the RDIS input.

  • Page 24: General Purpose Input

    Reach | installation guide 3.5.3 General purpose input A general-purpose input is available on the uPASS Reach reader. The function is described in the firmware manual. In OSDP operation this input is reported through OSDP_ISTATR message input #0. In TRANSIT compatible mode 3 inputs can be used.

  • Page 25: Tamper Switch

    Reach | installation guide 3.5.4 Tamper switch An internal magnet provides tamper indication when the service cover is opened. This contact may be connected to an external alarm system. The contacts are normally closed when the cover is in place.

  • Page 26: Nedap Antenna Interface

    The Nedap antenna modulation interface is used to connect the uPASS Reach to Nedap AEOS access control hardware such as the AP1001. The uPASS Reach simulates a 120kHz Nedap proximity card to the AP1001. In this case the uPASS Reach replaces the proximity antenna.

  • Page 27: Dip-Switch Settings

    TRANSIT compatible mode settings. Refer to the TRANSIT firmware manual for details. SW1 (1-4): Hardware settings. Described below. SW4 (1-4): Hardware settings. Only uPASS Reach model 2020. Described below. Figure 26: DIP-switches 4.1 Processor select uPASS Standard mode (default) TRANSIT compatible mode See chapter 1.2.

  • Page 28: Rs232 / Rs422 / Rs485 Selection

    RS485 multi-drop communication (last device) RS485 connection details are described in chapter 3.4.4 (page 19). Note that SW4 and the RS485 interface are only available on uPASS Reach hardware revision C.07 and newer. RS422-485 termination resistor The RS422-485 termination resistor is required to prevent unwanted signal reflections on long communication lines.

  • Page 29: Testmode

    Reach | installation guide 4.4 Testmode While 'testmode' is enabled, the outputs O-1, O-2 and O-3 continuously output a special test pattern. This is useful to test the Wiegand and Magstripe connections. SW1-3 SW1-3 Normal mode Testmode enabled. Connect O-1, O-2 and O-3 successively to input 1 (IN1) and watch the input 1 status LED.

  • Page 30: Led Indications

    Reach | installation guide 5 LED indications A number of LED’s indicate the current status of the uPASS Reach reader. RESET TEST Figure 28: LED indications The table below describes the function of each LED. Description LED bar indicating the received tag signal strength. This LED bar may also indicate the presence of radio interference.

  • Page 31: Uhf Frequencies

    6.1 Frequency regulations The uPASS Reach reader operates on the 860 – 960 MHz band. Regulations in this band are not standardized world- wide. It is important to ensure that the uPASS reader is operated using the correct country / frequency setting.

  • Page 32: Reader Configuration

    Reach | installation guide 7 Reader configuration The uPASS reader settings can be configured easily using the UHFTOOL software. Software developers can find the communication protocol description in the firmware manual. 7.1 UHFTOOL software Figure 29: UHFTOOL software 7.2 Settings Click 'View', 'Show config sidebar' or press F11 to show the configuration sidebar.

  • Page 33: Read Data

    By default, the reader is configured to select ANY TAG and read its EPC number. Select NEDAP to read only Nedap tags. NEDAP DUAL-ID enables the uPASS to search for Nedap vehicle-id tags. When a vehicle-id tag is found, the uPASS searches for driver-id tags.

  • Page 34: Decode Nedap-Xs

    Enable decode Nedap-XS when you do not want to use the TRANSIT compatible processor or the antenna modulation interface. The uPASS will decode the Nedap-XS tag data and output its tag-number in readable format. You can also enable to output or verify the customer code.

  • Page 35: Relay / Timing

    The 'Vehicle hold time' setting is the time, after a vehicle-id tag has been found, for which the reader will search for driver-id tags. This setting is only used in the NEDAP DUAL-ID mode. The Random off time parameter can be used to enable time sharing between multiple readers on the same frequency.

  • Page 36: Expert Settings

    Wiegand or magstripe interface. 'Enable vehicle id-events' allows enabling or disabling the id-event messages for vehicle-ids. This may be useful in combination with the NEDAP DUAL-ID mode and an access control panel that does not support the dual-id feature. 36/44...

  • Page 37: Output Message Format

    Reach | installation guide 7.3.2 Output message format Configure output message format. Figure 35: Output message format settings The serial output message format is configurable: <prefix> [<tagstatus>] [<epclen>] [<epc>] [<datlen>] [<data>] <suffix> [ CR/LF ] Example output: 40010257CB21DD0E34244E103FFFC809A862A1EC1500<CR><LF> Customized example Output: X012345<CR><LF>...

  • Page 38: Extra Output

    Reach | installation guide 7.3.3 Extra output Optionally enable Wiegand or magstripe output for tags that are not programmed by NEDAP in a Wiegand, Magstripe or NEDAP-XS format. 'Protocol': Disabled Do not use the extra output feature. Wiegand Enable Wiegand output.

  • Page 39: Frequency

    Reach | installation guide 7.3.4 Frequency Here is shown the reader's operating frequency region. When frequency hopping is not required, you can select a fixed frequency channel within the available frequency band. Figure 37: Frequency settings 7.3.5 Read range Enable the squelch to reduce the read range.

  • Page 40: Firmware Update

    Reach | installation guide 7.4 Firmware update When the UHFTOOL software is connected to the reader, it automatically checks the firmware version of the reader. If necessary the software recommends to perform a firmware update. Recent reader firmware versions are included within the software.

  • Page 41: A Technical Specifications

    Reach | installation guide A Technical specifications Item Specification Remark Dimensions 200x220x46.5mm ( 7.87 x 8.66 x 1.83 inch Weight 0.75 kg ( 1.65 lbs Enclosure color RAL7016 (light grey) Enclosure material Polycarbonate Chassis material Aluminium Cable entry fittings...

  • Page 42: B Disposal Of Equipment

    Reach | installation guide B Disposal of equipment The products will be disposed of by the end-user and discharge Nedap for any liability or responsibility thereof. The WEEE symbol in Europe indicates that the relevant electrical product or battery should not be disposed of as general household waste in Europe.
  • Page 43 Reach | installation guide ISED EMC Declaration This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de Classe B est conforme à la norme Canadienne ICES-003. FCC Information to the user This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 44: E Part Numbers

    Reach | installation guide E Part numbers Readers NEDAP uPASS Reach Region 1 (ETSI) 9942319 NEDAP uPASS Reach Region 2 and 3 (FCC) 9945466 Accessories Adjustable mounting bracket 9875840 Weather protection hood 7591152 Pole mounting kit (includes 7591152) 9943803...
