Nedap TRANSIT Ultimate Quick Reference Manual
Rfid reader
Hide thumbs
Also See for TRANSIT Ultimate:
- Installation manual (36 pages) ,
- Installation manual (40 pages)
Related Manuals for Nedap TRANSIT Ultimate
Summary of Contents for Nedap TRANSIT Ultimate
- Page 1 TRANSIT Ultimate quick reference guide 2020-04-10 | v5.05 | Doc. no. 5284651 www.nedapidentification.com...
-
Page 2: Safety Precautions
• The TRANSIT Ultimate shall only be installed and serviced by qualified service personnel. • To be sure of safety, do not modify or add anything other indicated by NEDAP N.V. • Installation TRANSIT Ultimate is IP66 rated and allow for operating temperatures from -30°C – +60°C. -
Page 3: Power Supply
(3 x 18 AWG). Max length: according to local regulations. The TRANSIT Ultimate features an USB interface for service and installation purposes. FTDI USB Virtual Com Port driver available. While the USB interface is in use, the optional communication interface board is disabled. -
Page 4: Led Indications
TRANSIT Ultimate | quick reference guide LED indications Description RX_LEVEL LED bar indicating the received microwave tag signal strength. This LED bar also indicates the presence of radio interference. In case of interference, try switching to a different frequency. SQ-EN Squelch enabled. -
Page 5: Frequency Setting
TRANSIT Ultimate | quick reference guide Frequency setting The TRANSIT Ultimate reader operates in the 2.45GHz ISM frequency band. When two or more readers are within a range of 15 meters (50 feet), these readers should be set on a different operating frequency. -
Page 6: Dip Switches
TRANSIT Ultimate | quick reference guide 2.4600 2.4606 2.4612 2.4618 CH11 2.4624 2.4630 2.4636 2.4642 The selected frequency has to comply with local radio regulations. ETSI frequency range from 2.446 to 2.454 GHz.
