TRANSIT ENTRY | INSTALLATION GUIDE
Connections
3.5.3 GENERAL PURPOSE INPUTS
Three general purpose inputs are available on the TRANSIT Entry reader. The inputs
are active low.
Connections
IN1
General purpose input 1
IN2
General purpose input 2
IN3
General purpose input 3
GND
Ground
Figure 16: GPIO inputs
General purpose inputs
16/30
