Parallax BASIC Stamp 2e Programming Manual page 284

SERIN - BASIC Stamp Command Reference
The BS1's SERIN command is limited to above-mentioned features. If you
are not using a BS1, please continue reading about the additional features
below.
The decimal formatter is only one of a whole family of conversion
formatters available with SERIN on the BS2, BS2e, BS2sx and BS2p. See
Table 5.76 for a list of available conversion formatters. All of the
conversion formatters work similar to the decimal formatter (as described
in the "Decimal Formatter Specifics" section, above).
receive bytes of data, waiting for the first byte that falls within the range of
characters they accept (e.g., "0" or "1" for binary, "0" to "9" for decimal,
"0" to "9" and "A" to "F" for hex, and "+" or "-" for signed variations of
any type). Once they receive a numeric character, they keep accepting
input until a non-numeric character arrives or (in the case of the fixed
length formatters) the maximum specified number of digits arrives.
While very effective at filtering and converting input text, the formatters
aren't completely foolproof. As mentioned before, many conversion
formatters will keep accepting text until the first non-numeric text arrives,
even if the resulting value exceeds the size of the variable. After SERIN, a
byte variable will contain the lowest 8 bits of the value entered and a word
would contain the lowest 16 bits. You can control this to some degree by
using a formatter that specifies the number of digits, such as DEC2, which
would accept values only in the range of 0 to 99.
The BS2, BS2e, BS2sx and BS2p also have special formatters for handling a
string of characters, a sequence of characters and undesirable characters.
See Table 5.77 for a list of these special formatters. Also, see Appendix C
for example serial inputs and the result of using these formatters.
Page 282 • BASIC Stamp Programming Manual 2.0b • www.parallaxinc.com
1
2
A
DDITIONAL CONVERSION
FORMATTERS
The formatters
O
NCE AGAIN
POTENTIAL ROLLOVER ERRORS
2 2 2
e
p
sx
.
,
PAY ATTENTION TO
.
