5: BASIC Stamp Command Reference - EEPROM
EEPROM
1
EEPROM {Location,} ( DataItem {, DataItem,...} )
2 2
(See DATA)
sx p
Function
Write data to the EEPROM during program download.
• Location is an optional variable/constant (0 – 255) that specifies the
starting location in the EEPROM at which data should be stored. If
no location is given, data is written starting at the next available
location.
• DataItem is a constant (0 – 255) to be stored in EEPROM.
Explanation
When you download a program into the BASIC Stamp 1, it is stored in the
EEPROM starting at the highest address (255) and working towards the
lowest address. Most programs don't use the entire EEPROM, so the
lower portion is available for other uses. The EEPROM directive allows
you to define a set of data to store in the available EEPROM locations. It is
called a "directive" rather than a "command" because it performs an
activity at compile-time rather than at run-time (ie: the EEPROM directive
is not downloaded to the BASIC Stamp 1, but the data it contains is
downloaded).
The simplest form of the EEPROM directive is something like the
.
following:
EEPROM (100, 200, 52, 45)
This example, when downloaded, will cause the values 100, 200, 52 and 45
to be written to EEPROM locations 0, 1, 2 and 3, respectively. You can
then use the READ and WRITE commands in your code to access these
locations and the data you've stored there.
The EEPROM directive uses a counter, called a pointer, to keep track of
).
available EEPROM addresses. The value of the pointer is initially 0. When
a program is downloaded, the EEPROM directive stores the first byte
value at the current pointer address, then increments (adds 1 to) the
pointer. If the program contains more than one EEPROM directive,
BS1 BS2 BS2e BS2sx BS2p
BASIC Stamp Programming Manual 2.0c • www.parallaxinc.com • Page 111
