RCTIME - BASIC Stamp Command Reference
Charge time = 4 x 220 x (0.1 x 10
So it takes only 88 µs for the cap to charge/discharge, meaning that the 1
ms charge/discharge time of the example is plenty.
A final note about Figure 5.29: You may be wondering why the 220 Ω
resistor is necessary at all. Consider what would happen if resistor R in
Figure 5.29a were a pot, and were adjusted to 0 Ω . When the I/O pin went
high to discharge the cap, it would see a short direct to ground. The 220 Ω
series resistor would limit the short circuit current to 5V/220 Ω = 23 mA
and protect the BASIC Stamp from damage. (Actual current would be
quite a bit less due to internal resistance of the pin's output driver, but you
get the idea.)
Demo Program (RCTIME1.bs2)
' This program shows the standard use of the RCTIME instruction measuring an RC
' charge/discharge time. Use the circuit in the RCTIME description (in the manual)
' with R = 10 k pot and C = 0.1 µf. Connect the circuit to pin 7 and run the program.
' Adjust the pot and watch the value shown on the Debug screen change.
'{$STAMP BS2}
Result VAR WORD
Again:
HIGH 7
PAUSE 1
RCTIME 7, 1, Result
DEBUG CLS, DEC Result
GOTO Again
