Additional Ports

Antenna / LED / Programming Port

Mount the supplied antenna/receiver to a clear spot on the vehicle's windshield that
will not block the driver's vision. A good location is usually high on the windshield
near the rear view mirror. Be careful not to mount the antenna/receiver on any
metallic window film, as this will effect system range. Route the antenna/receiver
cable to the control module and plug into the antenna port.
Data Bus Interface Port
This 4 pin port is used for Flashlogic Door Lock and Transponder Databus Interfaces
to communicate with the vehicle's Databus. When using the DBI port to control the
Flashlogic Door Lock and Transponder Interface modules the following options may
be available. Please refer to the D2D (Data to Data) function list available per vehicle
on the tech service web site.
Tach Input
Door Trigger
Door Lock Control
Dome Light Supervision
Factory Alarm Arm / Disarm
Manual Arm / Disarm Inputs (factory keyless controls system)

Telematic Interface Port

This 4 pin port is used for telematic Interface accessories, such as Car Connection
Pro, which can control some of the following features.
Door Lock Control
Sliding Doors
Car Find
20
Brake Safety Shut Down
Trunk/Hatch Open
Passlock / Passkey Interface (GM Only)
Transponder Interface Activation
Diesel Glow Plug Input
Trunk Release
AUX Output
Remote Start
