Additional Ports

The LED included in the kit will serve as a visual indicator of the alarm's status. It

should be installed in the dash, located where it can be easily seen from outside

the vehicle, yet not be distracting to the driver. Once a location has been

selected, check behind the panel for wire routing access, and to confirm the drill

will not damage any existing components as it passes through the panel. Drill a

1/4" hole, and pass the red and blue wires from the LED through the hole, from

the front of the panel. Firmly press the body of LED into the hole until fully seated.

Programming / Valet Button Port

Select a mounting location that is within reach of the ignition switch, as this

switch in combination with the ignition switch, will be used to program the certain

features of the system. It is suggested that the switch be mounted to the lower

dash panel in the driver's area within reach of the driver.
