FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of Industry
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
Warning!
Changes or modifications not expressly approved by the party responsible for
630.p65
Installation
Instructions
PROFESSIONAL INSTALLATION
STRONGLY RECOMMENDED
Installation Precautions:
Roll down window to avoid locking
keys in vehicle during installation
Avoid mounting components or
routing wires near hot surfaces
Avoid mounting components or
routing wires near moving parts
Tape or loom wires under hood
for protection and appearance
Use grommets when routing wires
through metal surfaces
Use a voltmeter for testing and
verifying circuits
Technical Support
For Authorized Dealers - (800) 421-3209
Canada. Operation is subject to the following two conditions:
may cause undesired operation.
compliance could void the user's authority to operate the equipment.
1
1
10/17/03, 7:29 PM
