J2 Switch Signal Summary
HDD LED Connector
N.C.
Infrared Connector
N.C.
PWR
SUSPEND
IDE LED Activity Light (J2 pin1-4)
This connector connects to the hard disk activity indicator light on the case.
Infrared Port Module Connector (J2 pin6-10)
The system board provides a 5-pin infrared connector-R1 for an optional
wireless transmitting and receiving module. Pin 6 through 10 are Transmit,
GND, Receive (low speed), Receive (high speed), and Vcc, respectively.
PWR Switch (J2 pin12, 13)
Power Switch: Toggle this pin for turning on/off of the Power supply (for ATX
power only).
SUSPEND Switch (J2 pin14, 15)
Toggle this jumper forces the system to sleep and the system won't wake up
until the hardware event is coming. (The BIOS Power Management setting
must be enabled.)
J2
Pin
Signal Description
1
+5V
2
HDD LED Signal
3
HDD LED Signal
4
+5V
5
No Connection
6
Infrared Transmit Signal
7
GND
Infrared Receive Signal
8
(low speed)
Infrared Receive Signal
9
(high speed)
10
+5V
11
No Connection
12
GND
13
Power Switch(for ATX Power)
SUSPEND signal
14
GND
15
12
