Canon imagePROGRAF iPF825 Setup Manual page 11

If the printer is already connected to the network
• If the printer is already connected to the
network, confi rm the static IP address
assigned to the printer. Ask your network
administrator for further information.
• If the printer is on, the Link indicator is
green for 100Base-TX connections and
MEMO
amber for 10Base-T connections.
3
Confi rm that the required installation
items are selected in the Installation
List window, and then click Next.
• Point at a software title to view a summary
of the software.
MEMO
6
On the Printer Selection window, select
The printer is connected to computers
in a network and click Next.
• Printers already connected to the network
are labeled Available in the list of IP
MEMO
addresses.
• If the desired printer is not shown in
the Printer List, select Specify the IP
address of available printers in the
network in Method of Printer Selection.
The IP Address Specifi cation window
appears. Follow steps 8-11 on page 12 to
fi nish installing the printer driver and the
User Manual.
11
The printer driver settings take effect
after the computer restarts. The printer
driver is now installed. An iPFxxxx
Support desktop icon is created after
installation.
(iPFxxxx represents the printer model.)
Next, follow steps 12-16 on page 8 to
install the User Manual.
1
Make sure the printer is on. Turn the
computer on and insert the provided
User Software CD-ROM for your
particular operating system in the CD-
ROM drive.
4
On the Select Country or Region of
Use window, select the country or region
of use and click Next.
7
After reading the precautions in the
Getting Ready window, select Find
available printers in the network and
click Next.
9
After reviewing the installation results on
the Complete Installation window, click
Next.
When entering the printer's IP address manually
• If the printer is already connected to the
network, confi rm the static IP address
assigned to the printer. Ask your network
administrator for further information.
• If the printer is on, the Link indicator is
green for 100Base-TX connections and
MEMO
amber for 10Base-T connections.
11
2
In the Setup Menu window, click Install
Printer Driver .
• To choose a different language, click
Language .
MEMO
5
After reading the license agreement,
click Yes.
8
Available printers are listed in the Search
Results window.
Select the desired printer in the Printer
List. In Method of Printer Selection,
select Use the selected printers, and
then click Next to start the installation
process.
10
In the Finish window, select Restart my
computer now and click Restart.
1
Make sure the printer is on. Turn the
computer on and insert the provided
User Software CD-ROM for your
particular operating system in the CD-
ROM drive.
