051-070-024 – Double Division Platform Assembly
051-070-024 – Double Division Platform Assembly
Item Part Number
1
2
3
4
5
6
7
400-051-010-01
TMS STRING PINSPOTTER OWNER'S MANUAL
Description
051-070-051 DOUBLE DIVISION PLATFORM
051-070-021 TUBE CLAMP
7012-003118-350 CB 5/16-18 X 3.50 GR5 ZN
7038-003118-000 KN 5/16-18 ZN
051-070-088 DOUBLE DIVISION COVER
049-006-531 FHPWS 10 X 2.00 ZN
051-070-087 STEP SUPPORT
Rev. Date: 6/17
Page 5-61
