Mounting
5 Mounting
5.1

Mounting requirements

5.1.1 Suitable mounting position
 1 Mounting position of Levelflex FMP55
• Rod probes/rope probes: mount in the bypass/stilling well.
• Coax probes can be mounted at any distance from the wall.
• When mounting outdoors, a weather protection cover can be used to protect the device
against extreme weather conditions.
• Minimum distance from the end of the probe to the bottom of the vessel: 10 mm (0.4 in)
5.1.2 Securing the probe
Securing coax probes
For WHG approval: a support is required for probe lengths ≥ 3 m (10 ft).
10
Levelflex FMP55 HART
A0011281
