Veeder-Root TLS-3 Series Troubleshooting Manual
Warnings & alarms
Hide thumbs
Also See for TLS-3 Series:
- Troubleshooting manual (160 pages) ,
- Site prep and installation manual (91 pages) ,
- Quick help (41 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Veeder-Root TLS-3 Series
Summary of Contents for Veeder-Root TLS-3 Series
- Page 1 Manual No: 577014-243 ● Revision A TLS System Warnings & Alarms Troubleshooting Guide...
- Page 2 Notice Veeder-Root makes no warranty of any kind with regard to this publication, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this publication.
- Page 3 TLS Warnings And Alarms TLS Warnings And Alarms The TLS console is constantly monitoring its probes and sensors for warning and alarm conditions, such as fuel leaks, excessively high or low fuel levels, and equipment problems. In the Operating Mode with no warning or alarm condition active, the TLS-3XX consoles display ‘ALL FUNCTIONS NORMAL’...
- Page 4 Displayed Alarm Messages Displayed Alarm Messages Common Alarm messages and a possible cause/action for the Alarms are listed in the table below. Actual Alarms displayed by a particular console will depend upon the features installed. Short Device IDs used in the table below: C = 2-wire CL sensor Co = Comm device G = Groundwater sensor...
- Page 5 Displayed Alarm Messages Short Message Device ID Cause Action Email Failed Alarm The console did not successfully send email when Verify the address book settings for the con- configured to email. tact are correct (email address of recipient), (TLS4/TLS-450PLUS only) verify network connectivity is available (Ethernet card is installed).
- Page 6 Displayed Alarm Messages Short Message Device ID Cause Action iButton Fault Alarm System iButton failure. Replace iButton with valid one. <No ID> (TLS4/TLS-450PLUS only) System detected Damaged or Corrupted iButton. The warning has been active 20 days and has transitioned to an alarm. The alarm will be active a maximum of 10 days.
- Page 7 Fuel level has exceeded a programmed limit. Stop delivery. Check for spillage. Potential overflow of tank may occur. Printer Out Of Paper Replace the paper roll only with Veeder-Root (TLS4/TLS-450PLUS only) supplied paper rolls: Paper roll is empty. P/N 514100-456 - TLS-4/450PLUS...
- Page 8 Displayed Alarm Messages Short Message Device ID Cause Action Printer Error (TLS4/TLS-450PLUS only) Printer feed roller release is open.. Push the release lever to the up position. Printer Error System (TLS-3XX only) Probe Out Hardware failure - probe or interconnecting wiring Call for service following the procedures to console.
- Page 9 For technical support, sales or other assistance, please visit: www.veeder.com...
