MAINTENANCE: REFRIGERATION PACKAGE ILLUSTRATION (FROM S.C. MODEL GHDSS850R)
9. Refrigeration Package Configuration
• Illustration shown is from self-contained model GHDSS850R.
• Your particular refrigeration package may have a slightly different refrigeration package layout.
Condenser Coil
Condenser
Coils
Hot Gas
Condensate
Coils and Pan
Overflow Pan
(For Hot Gas
Condensate Pan)
Overflow Pan
Electrical Box)
Condenser Coil
Fans & Housing
Housing
Filter Dryer
Receiver
Scroll
Sight Glass
Compressor
18
Condenser Coil
Wicking Material
(Typical)
Hot Gas
Condensate
Coil Pan
Accumulator
Electrical Box
(Starter Unit &
Relay)
