G-SERIES
G-SERIES SELF-SERVICE MERCHANDISER WITH HEATED SHELVES AND DECK
> SCC PROPRIETARY THERMOSTATS AT CASE REAR
> REMOVABLE WIRE RACKS ON HEATED SHELVES
> REAR SLIDING DOORS
Operating Manuals\G-Series\G-Series_Heated_Self-Service Unit_20-95651.pub
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION AND
OPERATING MANUAL
Model GHSS476HRD.5718
888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
20-95651
Important! See Installation
Section Of Manual To
Confirm Proper Placement of
"Caution-Hot" Labels on Heat-
ed Shelves
Rev B Date: 10.4.2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Structural Concepts G Series

  • Page 1 READ AND SAVE THESE INSTRUCTIONS G-SERIES INSTALLATION AND OPERATING MANUAL 20-95651 G-SERIES SELF-SERVICE MERCHANDISER WITH HEATED SHELVES AND DECK > SCC PROPRIETARY THERMOSTATS AT CASE REAR > REMOVABLE WIRE RACKS ON HEATED SHELVES > REAR SLIDING DOORS Important! See Installation Section Of Manual To Confirm Proper Placement of “Caution-Hot”...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS .....….. INSTALLATION: SKID REMOVAL / POSITIONING CASE / FRAME SUPPORT RAIL SHIMMING …. INSTALLATION, CONT’D: ATTACHING SPLASH GUARD BRACKET TO REAR FRAME SUPPORT RAIL ………………………………………………………………………….……………… INSTALLATION, CONT’D: IMPORTANT! HEATED SHELF LABEL PLACEMENT …………...……….
  • Page 3: Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs - Page 1 Of 2

    150 °Fahrenheit / 66 °Celsius. performance. These Structural Concepts® self-service heated THERMOMETERS merchandisers are designed to hold pre-heated hot Thermometers in equipment reflect internal air foods at 140 °F to 165 °F (60 °C to 74 °C).
  • Page 4 OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS - PAGE 2 of 2 PRECAUTIONS Following are important precautions to prevent damage to unit, merchandise or product. Please read carefully! CAUTION! LAMP REPLACEMENT GUIDELINES CAUTION LED lamp replacements must meet factory specifications. CAUTION! GFCI BREAKER USE REQUIREMENT If N.E.C.
  • Page 5: Installation: Skid Removal / Positioning Case / Frame Support Rail Shimming

    INSTALLATION: PALLET REMOVAL / POSITIONING CASE / FRAME SUPPORT RAIL SHIMMING 1. Remove Unit From Pallet Caution: Case must always remain supported or center of gravity will allow case to fall. Slide unit to rear of pallet and lean backward off skid. Slide pallet out from under case while case is being supported.
  • Page 6: Installation, Cont'd: Attaching Splash Guard Bracket To Rear Frame

    INSTALLATION, CONT’D: ATTACHING SPLASH GUARD BRACKET TO REAR FRAME SUPPORT RAIL bracket (that rests on floor). Center back of 4. Attaching and Sealing Splash Guard Bracket bracket flush against frame support rail. To Frame Support Rail at Case Rear Then, attach to frame support rail with The separately shipped splash guard bracket is SCC-supplied screws.
  • Page 7: Installation, Cont'd: Important! Heated Shelf Label Placement

    Illustration below shows proper placement of “Danger-Hot” labels. Two labels must be placed on each shelf and lower panel (as shown below). If labels are NOT properly attached, contact Structural Concepts. See SCC TECHNICAL SERVICE CONTACT INFORMATION section in this manual for contact information.
  • Page 8: Installation, Cont'd: Removable Front & Rear Toe-Kicks

    INSTALLATION, CONT’D: REMOVABLE FRONT & REAR TOE-KICKS 7. Removable Rear Toe-Kick (Screw-Retained) 6. Removable Front Toe-Kick (Magnetized) Rear toe-kick is usually attached at case Front toe-kick is usually shipped separately. shipment. Front toe-kick is removable by grasping Rear toe-kick is removable by removing two (2) toe-kick’s upper lip and pulling toward you (to screws and lifting away from case.
  • Page 9: Startup: Main Power Switch / Lights Switch / Thermostats

    STARTUP: MAIN POWER SWITCH / LIGHTS SWITCH / THERMOSTATS 1. Main Power Switch 3. Thermostats Main power switch is at case rear. Thermostats are at case rear Main power switch controls power to lights AND Thermostats control heat to deck and all three thermostats.
  • Page 10: Startup, Cont'd: Operation And Shutdown (Authorized Personnel Only!)

    STARTUP, CONTINUED: OPERATION AND SHUTDOWN (AUTHORIZED PERSONNEL ONLY!) 4. Merchandiser Daily Start-Up Turn main power switch and lights switch on. LED lights should all come on at once. Temperature controls are pre-set at factory to recommended settings. Press pre-heat buttons. Pre-heat lights will illuminate.
  • Page 11: General Layout: Case Front

    GENERAL LAYOUT: CASE FRONT Genera Layout: Case Front Note: Model GHSS476HRD.5718 Is Shown. Note: Model GHSS476HRD.5718 is shown. It may not It May Not Exactly Reflect Every Feature exactly reflect every feature or option of your Or Option Of Your Particular Model. particular model.
  • Page 12: General Layout, Cont'd: Case Rear

    GENERAL LAYOUT, CONT’D: CASE REAR Genera Layout: Case Rear Note: Model GHSS476HRD.5718 Is Shown. Note: Model GHSS476HRD.5718 is shown. It may not It May Not Exactly Reflect Every Feature exactly reflect every feature or option of your Or Option Of Your Particular Model. particular model.
  • Page 13: General Layout, Cont'd: Led Light Switch And Fixtures / Led Removal

    See illustrations at lower left. from its spring. Disconnect plug from LED’s socket. Contact Structural Concepts’ Technical Service Department for replacement parts (see the Technical Service section of operating manual for information). LED’s Oval Form Plug’s...
  • Page 14: Cleaning Schedule: Case Exterior - Daily, Weekly And Monthly

    CLEANING SCHEDULE: CASE EXTERIOR - DAILY, WEEKLY AND MONTHLY Cleaning Daily Weekly Monthly Task Wood or Laminate Surfaces Case Clean with warm, soapy water and clean cloth or sponge. Exterior Dry with clean cloth or paper towel. Insulated Glass / Rear Sliding Door Glass Clean outside surfaces of glass with household or commercial glass cleaner.
  • Page 15: Cleaning Schedule, Cont'd: Case Interior - Daily

    CLEANING SCHEDULE, CONT’D: CASE INTERIOR - DAILY Caution! TURN MAIN POWER SWITCH TO “OFF” and allow case to cool at least 45 minutes before cleaning case interior! Cleaning Daily Task Glass Clean inside surfaces of glass with a household or commercial glass cleaner. Case Wipe dry with clean cloth or paper towel.
  • Page 16: Serial Label & Location / Technical Information / Additional Information

    Product is not heating Heating elements may be malfunctioning. at all Call Structural Concepts Technical Service (at last page of this manual). Move product to separate location until unit is repaired. LED lights are not Check that light switch is in the on position.
  • Page 17 For additional technical information and service, see the TECHNICAL SERVICE page in this manual for instructions on contacting Structural Concepts’ Technical Service Department. See images below for samples of both refrigerated and non-refrigerated serial labels.
  • Page 18: Scc Technical Service Contact Information & Warranty Information

    DAMAGE, STORE’S AMBIENT CONDITIONS, ETC.) LIMITED WARRANTY Overview: All sales by Structural Concepts Corporation (hereafter referred to as “SCC”) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty Scope: Warranty is for equipment sold in the United States, Canada, Mexico and Puerto Rico. Equipment sold elsewhere may carry modified warranties.
