- Page 1 Hygena- Tall boy 528/9060 Assembly lnstructions - please keep for future reference 538/8734 Dimensions Width - 24cm Depth - 28cm Height - 164cm Important– Please read these instructions fully before starting assembly Issue 1 - 21/03/16...
- Page 2 WARNING In order to help prevent overturning – To help prevent product toppling over please follow the below steps:- Do not allow children to climb or hang on the furniture Do not place heavy items in the top drawers Do not place heavy items on top of the furniture, unless the furniture has been designed for this purpose You will need to provide wall plugs and screws applicable for your wall type...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Please check you have all the panels listed below...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.In some cases more fittings may be supplied than are required. Wall strap x 1 4x32mm Screw x 2 Panel Stiffenersx 8...
- Page 6 Assembly lnstructions Step 1 Fitting Male camlock 1.Insert 9 x male camlocks to the top 5 , bottom left side 8 and bottom right side 10 and bottom front bar 7 .
- Page 7 Assembly lnstructions Step 2 Fitting dowels 1.Glue and insert 12 x dowels to upper left side 2 ,upper right side 3 , bottom 6 & middle front bar 9 , bottom left side 8 and bottom right side 10 .
- Page 8 Assembly lnstructions Step 3 1.Attach fixed shelf 1 upper right side 3 & upper left side 2 with 4 x screws using Hex key supplied to tighten. Step 4 1.Slide upper back 4 along grooves in upper left side 2 and upper right side 3 .
- Page 9 Assembly lnstructions Step 5 1.Attach top 5 to upper left side 2 & upper right side 2.Insert 4 x female camlocks to upper left side 2 & upper right side 3 . Use a screwdriver to turn the female camlock clockwise to lock.
- Page 10 Assembly lnstructions Step 7 1.Attach bottom 6 & middle front bar 9 to bottom left side 8 . 2.Insert 2 x female camlocks to bottom 6 . Use a screwdriver to turn the female camlock clockwise to lock. Step 8 1.Attach upper right side 10 to bottom 6 &...
- Page 11 Assembly lnstructions Step 9 1.Slide bottom back 11 along grooves of the unit as shown in diagram Step 10 1.Insert 4 x male camlocks to the fixed shelf 1 .
- Page 12 Assembly lnstructions Step 11 1.Attach the upper section to the bottom section by locating Male camlocks in panel 1 into adjacent holes in panels 8 and 10 . 2.Insert 4 x female camlocks to bottom left side 8 and bottom right side 10 . Use a screwdriver to turn the female camlock clockwise to lock.Please refer to the...
- Page 13 Assembly lnstructions Step 13 1. Attach upper door 12 and bottom door 13 to the unit with 8 x screws shown. 2.Use 8 x stickers cover camlock hole on upper left side 2 and upper right side 3 , bottom left side 8 and bottom right side 10 .
- Page 14 Assembly lnstructions Step 14 1.Insert shelf supports into the holes inside the unit in the desired position 2.Place adjustable shelves 14 on the shelf supports.
- Page 15 Assembly lnstructions Step 15 1.Insert 8 x panel Stiffeners into the back panel grooves as shown .These add support and give the unit rigidity. 2.Using screw & washer secure the 1 x nylon strap to the back of top...
- Page 16 Assembly lnstructions Step 16 WALL If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400800 Argos LTD. 489-499 Avebury boulevard, Central Milton Keynes, MK9 2NW...
