Berkeley - 4+1 Sideboard

Assembly Instructions -

hygena

Dimensions

Width - 99.5cm

Depth - 39.5cm

Height - 71.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

Please keep for future reference

417/8976

MADE IN

BRITAIN

Issue 1 - 11/05/15

Need help?

Do you have a question about the Berkeley and is the answer not in the manual?

Questions and answers

Summary of Contents for hygena Berkeley

Page 1 Berkeley - 4+1 Sideboard Assembly Instructions - 417/8976 Please keep for future reference hygena Dimensions Width - 99.5cm Depth - 39.5cm MADE IN Height - 71.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 31kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left End Right End Divider (DF2882) (DF2883) (DF2884) (563 x 392mm) (563 x 392mm) (563 x 392mm) Base...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 4 drawer fronts Screw 2 metal dowels into each of the 4 drawer fronts Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 7 Runners must be pushed up against the drawer front Fit runners to the drawers Fit the runner to the bottom edge of the left drawer side , as shown, making sure that it is pushed up against the back of the drawer front .
Page 8 Assembly Instructions Step 9 Prepare the top Screw 6 metal dowels into the top Finished front edge Step 10 Fit the right end to the top Push the right end onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the right end...
Page 9 Assembly Instructions Step 11 screw screw screw Prepare the left end Fit 4 runners the left end The 1st screw uses the 2nd hole in from the front of the runner. Finished front edge The 2nd and 3rd screws use the holes that line up with the other panel holes.
Page 10 Assembly Instructions Step 12 Fit the left end to the Push the left end onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the left end Finished front edge Step 13 Prepare the divider Fit 4 runners the divider The 1st screw...
Page 11 Assembly Instructions Step 14 Fit the divider Push the divider onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the divider Note: Place a polystyrene block from the packaging Finished underneath the divider to front edge Polystyrene raise it up level with the...
Page 12 Assembly Instructions Step 16 Note: The raised part of the leg bracket must Fit the leg brackets to point towards the the base centre of the panel. Screw each leg bracket . to the base using 2 screws into the mark holes. Then use another 2 screws into the other...
Page 13 Assembly Instructions Step 18 Fit the legs Screw the legs into the leg brackets Carefully stand the unit up for the next step. Warning: The unit is heavy. Lift with care. Step 19 Fit the drawers Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to...
Page 14 Assembly Instructions Step 20 Fit the shelves Insert 4 shelf studs the required height. Lower the shelf down onto the shelf studs Step 21 Prepare the door Push fit 2 hinges into the door Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are...
Page 15 Assembly Instructions Step 22 Fit the door and handle Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate. Keep the hinge FLAT against the hinge plate as you slide it across as far as it will go.
Page 16 Assembly Instructions Step 23 Adjust the door if needed Before adjusting the door, use a spirit level to check the top (or base) of the unit is level, front- to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any...
Page 17 Assembly Instructions Step 24 Example Attach the Attach the Fit the overbalance Screw strap to the wall strap to the unit protector kit Washer Wall fixing Strap To prevent possible Strap (not supplied) overbalancing we Washer recommend that this unit is secured to a suitable Screw wall by fitting of the...
Page 20 ALR3152...
