PR electronics 9100 Series Product Manual

Hart transparent repeater
Hide thumbs Also See for 9100 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Product manual
9106
HART transparent repeater
T E M P E R AT U R E
|
I . S . I N T E R FA C E S
No. 910 6V10 8 - UK
Produc t ver sion: 910 6 - 0 02
|
CO M M U N I C AT I O N I N T E R FA C E S
|
M U LT I F U N C T I O N A L
|
I S O L AT I O N
PERFORMANCE
MADE
SMARTER
|
D I S P L AY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR electronics 9100 Series

Summary of Contents for PR electronics 9100 Series

  • Page 1 PERFORMANCE MADE SMARTER Product manual 9106 HART transparent repeater T E M P E R AT U R E I . S . I N T E R FA C E S CO M M U N I C AT I O N I N T E R FA C E S M U LT I F U N C T I O N A L I S O L AT I O N D I S P L AY...
  • Page 2 6 Product Pillars to meet your every need Individually outstanding, unrivalled in combination With our innovative, patented technologies, we make signal conditioning smarter and simpler. Our portfolio is composed of six product areas, where we offer a wide range of analog and digital devices covering over a thousand applications in industrial and factory automation.

  • Page 3: Table Of Contents

    HART TRANSPARENT REPEATER 9106 Table of contents Warning ....................Symbol identification .

  • Page 4: Warning

    General mounting, wire connection and disconnection. Troubleshooting the device. Repair of the device and replacement of circuit breakers must be done by PR electronics A/S only. Warning Do not open the front plate of the device as this will cause damage to the connector for the PR 4500 communication interfaces.

  • Page 5: How To Demount System 9000

    Should there be any doubt as to the correct handling of the device, please contact your local distributor or, alternatively, PR electronics A/S www.prelectronics.com The use of stranded wires is not permitted for mains wiring except when wires are fitted with cable ends.

  • Page 6: Application

    HART TRANSPARENT REPEATER 9106 • 24 VDC supply via power rail or connectors • Active and passive mA input • Active or passive output via the same two terminals • Splitter function - 1 in and 2 out • SIL2 / SIL3 Full Assessment and certified acc. to IEC 61508 Application •...

  • Page 7: Applications - 9106Axxx

    Applications - 9106Axxx Input signals: Output signals: Analog, 4...20 mA Channel 1 Channel 1 2-wire transmitter Passive 2-wire Current Channel 2 Power rail Status relay signal Rail, supply + Rail, supply - No connection No connection Power connection: Channel 2 Supply - 2-wire transmitter...

  • Page 8: Applications - 9106Bxxx

    Applications - 9106Bxxx Input signals: Output signals: Analog, 4...20 mA Channel 1 Channel 1 2-wire transmitter Passive 2-wire Current Channel 2 Power rail Status relay signal Rail, supply + Rail, supply - No connection No connection Power connection: Channel 2 Supply - 2-wire transmitter...

  • Page 9: Pr 4500 Communication Interfaces

    PR 4500 communication interfaces Functionality The simple and easily understandable menu structure and the explanatory help texts guide you effortlessly and automatically through the configuration steps, thus making the product very easy to use. Functions and configuration options are described in the section ”Configuration / operating the function keys”.

  • Page 10: Order

    Order Associated Type Barrier version Unit channels I.S. / Ex approvals apparatus 9106 Uo = 27.5 V Single ATEX, IECEx, FM, INMETRO, CCC, EAC-Ex Uo = 25.3 V Double cULus, ATEX, IECEx, FM, : -U9 INMETRO, CCC, EAC-Ex Example: 9106B2B Accessories 4501 = Display / programming front...
  • Page 11 Max. power Max. required Type Description dissipation power Passive input 9106x1Ax 1 ch. (Ex Uo 27.5 V) ≤ 0.8 W ≤ 1.1 W 9106x1Bx 2 ch. (Ex Uo 27.5 V) ≤ 1.2 W ≤ 1.9 W 9106B2Ax 1 ch. (Ex Uo 25.3 V) ≤...
  • Page 12 Ex barrier data 9106B1xx: ........Uo = 27.5 V Io = 92.6 mA Po = 0.64 W 9106B2xx: .

  • Page 13: Visualisation In The Pr 4500Xx Of Hardware / Software Error

    Visualisation in the PR 4500xx of hardware / software error Readout at hardware error Error search Readout Cause Communications test PR 4500 and 9106 NO.CO Connection error Configuration error or CRC mismatch, recovery EEprom error - check configuration FL.ER configuration is loaded User error II ! / II ! Loop limit exceeded...

  • Page 14: Connections

    Connections Power rail Supply and connections status relay 91 92 93 94 95 31 32 N.C. NC = no connection Inputs - SIL 2: 2-wire transmitter Current 2-wire transmitter Current Inputs - SIL 3: Current 2-wire transmitter Current Current Outputs: Current Passive 2-wire Current...

  • Page 15: Block Diagram

    Block diagram Power Rail connections * NC = No connection 50.0 Supply - Supply, Green Supply +19,2...31,2 VDC 16.0mA Ch. 1 status, Red Ch. 2 status, Red FLASH Status relay N.C. Status relay N.C. 2-wire transmitter 2-wire supply 4...20 mA Channel 1 Gnd.

  • Page 16: Signal Error Indications Without Display Front

    Signal error indications without display front List of LED and error signal indications Ch. 1: Ch. 2: Power rail Condition Green LED Status relay, N.C. signal status Device OK Blinking Energized No supply De-energized Device defective Blinking De-energized Ch. 1 defective (ch. 2 OK) Blinking De-energized Ch.

  • Page 17: Configuration / Operating The Function Keys

    Password protection: Programming access can be blocked by assigning a password. The password is saved in the device in order to ensure a high degree of protection against unauthorized modifications to the configuration. If the configured password is not known, please contact PR electronics support - www.prelectronics.com/contact. Loop limits In the menus LO.LIM and HI.LIM you can choose the current values which will trigger a loop error alarm from the status relay.

  • Page 18: Routing Diagram

    Routing diagram If no key is activated for 1 minute, the display will return to the default state 1.0 without saving configuration changes. 1 Increase value / choose next parameter 2 Decrease value / choose previous parameter 3 Save the chosen value and proceed to the next menu Hold 3 Back to previous menu / return to menu 1.0 without saving.

  • Page 19: Routing Diagram, Advanced Settings (Adv.set)

    Routing diagram, advanced settings (ADV.SET) DISP, PASS, LANG, RAIL LOOP DISP LOOP TAG1 TAG2 SETUP CONTRA DISP LIGHT TAGNO TAGNO Txt 6 Txt 9 Txt 12 Txt 10 Txt 11 Txt 11 9999 0000 PASS 0000 SETUP EN.PASS NEW.PAS Txt 6 Txt 15 Txt 16 To default...

  • Page 20: Help Text Overview

    Help text overview [01] Set correct password [PASS] [02] Enter advanced setup [ADV.SET] [03] Set low limit for loop error detection [LO.LIM1] [LO.LIM2] [04] Set high limit for loop error detection [HI.LIM1] [HI.LIM2] [05] Enable rail status signal output? [RAIL.ER] Enter display setup [SETUP] [06] Enter password setup [SETUP]...

  • Page 21: Iecex Installation Drawing

    For Installation in Zone 2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way. Only 4501 modules free of dust and moisture shall be installed.
  • Page 22 9106QI01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous area Non Hazardous area (terminal 11,12,13,14) Zone 0,1,2, 20, 21, 22 or Zone 2 (terminal 31,32,33,34) (terminal 91,92,93,94,95) -20 ≤Ta ≤ +60ºC : 253V, max 400Hz 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B...
  • Page 23 9106QI01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous area Non Hazardous area (terminal 11,12,13,14) Zone 0,1,2, 20, 21, 22 or Zone 2 (terminal 31,32,33,34) (terminal 91,92,93,94,95) -20 ≤Ta ≤ +60ºC : 253V, max 400Hz 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B, 9106B2A, 9106B2B...
  • Page 24 9106QI01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous area Non Hazardous area (terminal 11,12,13,14) Zone 0,1, 2, 20, 21, 22 or Zone 2 (terminal 31,32,33,34) (terminal 91,92,93,94,95) : 253V, max 400Hz -20 ≤Ta ≤ +60ºC 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B...
  • Page 25 9106QI01 LERBAKKEN 10, 8410 RØNDE DENMARK (terminal 11,12,13,14) Hazardous area Non Hazardous area (terminal 31,32,33,34) Zone 0,1,2, 20, 21, 22 or Zone 2 (terminal 91,92,93,94,95) : 253V, max 400Hz -20 ≤Ta ≤ +60ºC 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B, 9106B2A, 9106B2B...
  • Page 26 9106QI01 LERBAKKEN 10, 8410 RØNDE DENMARK 9106Axx, 9106Bxx, Installation: Hazardous area Zone 2 -20 ≤ Ta ≤ 60ºC 4501 9106 91 92 93 94 95 Power Rail Supply: 19.2 – 31.2 VDC Output: (terminal 31,32) (terminal 11,12,13,14) (terminal 91,92,93,94,95) Input CH1 (terminal 43,44) CH2 (terminal 53,54) Status Relay.

  • Page 27: Atex Installation Drawing

    For Installation in Zone 2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way. Only 4501 modules free of dust and moisture shall be installed.
  • Page 28 9106QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous area Non Hazardous area (terminal 11,12,13,14) Zone 0,1,2, 20, 21, 22 or Zone 2 (terminal 31,32,33,34) (terminal 91,92,93,94,95) -20 ≤Ta ≤ +60ºC : 253V, max 400Hz 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B...
  • Page 29 9106QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous area Non Hazardous area (terminal 11,12,13,14) Zone 0,1,2, 20, 21, 22 or Zone 2 (terminal 31,32,33,34) (terminal 91,92,93,94,95) -20 ≤Ta ≤ +60ºC : 253V, max 400Hz 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B, 9106B2A, 9106B2B...
  • Page 30 9106QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous area Non Hazardous area (terminal 11,12,13,14) Zone 0,1, 2, 20, 21, 22 or Zone 2 (terminal 31,32,33,34) (terminal 91,92,93,94,95) : 253V, max 400Hz -20 ≤Ta ≤ +60ºC 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B...
  • Page 31 9106QA01 LERBAKKEN 10, 8410 RØNDE DENMARK (terminal 11,12,13,14) Hazardous area Non Hazardous area (terminal 31,32,33,34) Zone 0,1,2, 20, 21, 22 or Zone 2 (terminal 91,92,93,94,95) : 253V, max 400Hz -20 ≤Ta ≤ +60ºC 4501 9106 91 92 93 94 95 Power Rail 9106B1A, 9106B1B, 9106B2A, 9106B2B...
  • Page 32 For Installation in Zone 2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way. Only 4501 modules free of dust and moisture shall be installed.

  • Page 33: Fm Installation Drawing

    For Installation in Div2/Zone2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way. Only 4501 modules free of dust and moisture shall be installed.
  • Page 34 9106QF01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location or Class I, Zone 0/1 Group IIC, [AEx ia] IIC Class I, Division 2, Group A,B,C,D T4 or Group IIC, [Ex ia Ga] IIC Gc or Class I Zone 2 Group IIC T4 Gc -20 ≤Ta ≤...
  • Page 35 9106QF01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location or Class I, Zone 0/1 Group IIC, [AEx ia] IIC Class I, Division 2, Group A,B,C,D T4 or Group IIC, [Ex ia Ga] IIC Gc or Class I Zone 2 Group IIC T4 Gc -20 ≤Ta ≤...
  • Page 36 9106QF01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location or Class I, Zone 0/1 Group IIC, [AEx ia] IIC Class I, Division 2, Group A,B,C,D T4 or Group IIC, [Ex ia Ga] IIC Gc or Class I Zone 2 Group IIC T4 Gc -20 ≤Ta ≤...
  • Page 37 9106QF01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location or Class I, Zone 0/1 Group IIC, [AEx ia] IIC Class I, Division 2, Group A,B,C,D T4 or Group IIC, [Ex ia Ga] IIC Gc or Class I Zone 2 Group IIC T4 Gc 4501 -20 ≤Ta ≤...

  • Page 38: Ul Installation Drawing

    For Installation in Div2/Zone2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way. Only 4501 modules free of dust and moisture shall be installed.
  • Page 39 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK Installation notes 9106Axx and 9106Bxx: The module must be installed in an tool-secured enclosure suitable for the application in accordance with the National Electrical Code (ANSI/NFPA 70) for installation in the United States, the Canadian Electrical Code for installations in Canada, or other local codes, as applicable.
  • Page 40 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK The 9106B may also be connected to a simple apparatus as defined in Article 504.2 and installed and temperature classified in accordance with Article 504.10(D) of the National Electrical Code (ANSI/NFPA 70), or other local codes, as applicable. Capacitance and inductance of the field wiring from the intrinsically safe equipment to the associated apparatus shall be calculated and must be included in the system calculations as shown in Table 1.
  • Page 41 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location Zone 0,1, 2 Group IIC, IIB, IIA or Class I, Division 2, Group ABCD T4 Zone 20, 21 Class I Zone 2 Group IIC T4 -20 ≤Ta ≤...
  • Page 42 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location Zone 0,1, 2 Group IIC, IIB, IIA or Class I, Division 2, Group ABCD T4 Zone 20, 21 Class I Zone 2 Group IIC T4 -20 ≤Ta ≤...
  • Page 43 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location Zone 0,1, 2 Group IIC, IIB, IIA or Class I, Division 2, Group ABCD T4 Zone 20, 21 Class I Zone 2 Group IIC T4 -20 ≤Ta ≤...
  • Page 44 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK Hazardous Classified Location Unclassified Location or Class I/II/III, Division 1, Group A,B,C,D,E,F,G Hazardous Classified Location Zone 0,1, 2 Group IIC, IIB, IIA or Class I, Division 2, Group ABCD T4 Zone 20, 21 Class I Zone 2 Group IIC T4 4501 -20 ≤Ta ≤...
  • Page 45 9106QU01 LERBAKKEN 10, 8410 RØNDE DENMARK 9106Axx Installation: Unclassified Location or Supply terminal (31,32) Hazardous Classified Location Voltage: 19.2 – 31.2 VDC Class I, Division 2 Group A,B,C,D T4 Class I, Zone 2, Group IIC, IIB, IIA T4 Status relay, terminal (33,34) Class I Division 2 or Zone 2 installation: Voltage max:...

  • Page 46: Desenho De Instalaçao Inmetro

    9106QB01 LERBAKKEN 10, 8410 RØNDE DENMARK INMETRO - Desenhos para Instalação Para instalação segura do 9106B o manual seguinte deve ser observado. O módulo deve ser instalado somente por profissionais qualificados que estão familiarizados com as leis nacionais e internacionais, diretrizes e normas que se aplicam a esta área. Ano de fabricação pode ser obtido a partir dos dois primeiros dígitos do número de série.
  • Page 47 9106QB01 LERBAKKEN 10, 8410 RØNDE DENMARK Área de Risco Área de não Risco (terminais 11,12,13,14) Zona 0,1,2, 20, 21, 22 ou Zona 2 (terminais 31,32,33,34) (terminais 91,92,93,94,95) -20 ≤Ta ≤ +60ºC : 253 V, máx. 400 Hz 4501 9106 91 92 93 94 95 TRILHO DE ENERGIA 9106B1A, 9106B1B...
  • Page 48 9106QB01 LERBAKKEN 10, 8410 RØNDE DENMARK Área de Risco Área de não Risco (terminais 11,12,13,14) Zona 0,1,2, 20, 21, 22 ou Zona 2 (terminais 31,32,33,34) (terminais 91,92,93,94,95) -20 ≤Ta ≤ +60ºC : 253 V, máx. 400 Hz 4501 9106 91 92 93 94 95 TRILHO DE ENERGIA 9106B1A, 9106B1B, 9106B2A, 9106B2B...
  • Page 49 9106QB01 LERBAKKEN 10, 8410 RØNDE DENMARK Área de Risco Área de não Risco (terminais 11,12,13,14) Zona 0,1, 2, 20, 21, 22 ou Zona 2 (terminais 31,32,33,34) (terminais 91,92,93,94,95) : 253 V, máx. 400 Hz -20 ≤Ta ≤ +60ºC 4501 9106 91 92 93 94 95 TRILHO DE ENERGIA...
  • Page 50 9106QB01 LERBAKKEN 10, 8410 RØNDE DENMARK (terminais 11,12,13,14) Área de Risco Área de não Risco (terminais 31,32,33,34) Zona 0,1,2, 20, 21, 22 ou Zona 2 (terminais 91,92,93,94,95) : 253 V, máx. 400 Hz -20 ≤Ta ≤ +60ºC 4501 9106 91 92 93 94 95 TRILHO DE ENERGIA 9106B1A, 9106B1B, 9106B2A, 9106B2B...

  • Page 51: Document History

    Document history The following list provides notes concerning revisions of this document. Rev. ID Date Notes 1703 Installation drawings updated. Ex barrier data changed. Specifications for max. required power added. 1931 9106A-version included in manual. Variant with UL 913 approval added. CCOE approval discontinued.
