BT880-CC
BALL JOINT MOUNT
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions............................................................................................................................7
B-Tech Contact Details.......................................................................................................................8
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
CONTENTS
8mm (1/3") masonry bit
Drill
or 5mm (1/5") wood bit
www.btechavmounts.com
FEATURES
● Only 83mm (3.3") drop to end of ball joint
● Coverplate included for smart installation
● +/- 90° tilt adjustment, +/- 90° roll adjustment
and +/- 360° swivel
● Safety wire for extra security
● Can be used for ceiling or wall mounting
*
Must be used in conjunction with a suitable
B-Tech AV Interface
Level
Pencil
(optional)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for B-Tech BT880-CC
Summary of Contents for B-Tech BT880-CC
- Page 1 Must be used in conjunction with a suitable B-Tech AV Interface CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Product Dimensions..........................7 B-Tech Contact Details........................8 INSTALLATION TOOLS REQUIRED Crosshead Level 8mm (1/3") masonry bit Pencil Drill screwdriver (optional) or 5mm (1/5") wood bit B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com...
