BT8573
LARGE FLAT SCREEN
TWIN POLE FLOOR STAND
INSTALLATION GUIDE
SPECIFICATIONS
• Recommended for screens up to: 70" (177cm)
• Max load: 70kg (154lbs)
• Suitable for screens with VESA
• Universal design suitable to mount screens in a
landscape or portrait orientation
• Integrated cable management
• Dimensions: H.1826 x W.800 x D.600mm
(H.71.90" x W.31.50" x D.23.62")
• Simple 'hook-on' installation with all mounting
hardware included
®
fixings up to 600 x 400mm
www.btechavmounts.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for B-Tech AV Mounts BT8573
Summary of Contents for B-Tech AV Mounts BT8573
- Page 1 BT8573 LARGE FLAT SCREEN TWIN POLE FLOOR STAND INSTALLATION GUIDE SPECIFICATIONS • Recommended for screens up to: 70" (177cm) • Max load: 70kg (154lbs) ® • Suitable for screens with VESA fixings up to 600 x 400mm • Universal design suitable to mount screens in a landscape or portrait orientation •...
-
Page 2: Installation Safety Instructions
Please check carefully to make sure there are no missing or defective parts - defective parts must never be used. B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire. - Page 4 BT8573 PARTS LIST PLEASE KEEP THIS FOR FUTURE REFERENCE...
-
Page 5: Installation Tools Required
ITEM PART NAME FLOOR BASE COVER PLATE Ø50mm POLE 1.8M POLE END CAP M16 x 50mm HEX SCREW 10AF HEX KEY Ø50mm COLLAR COLLAR COVER M8 x 12mm HEX SCREW M8 SPRING WASHER M8 x 15mm GRUB SCREW 4AF HEX KEY 5AF HEX KEY MOUNTING PLATE INTERFACE ARMS... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS ATTACH POLES TO BASE Fix item 3 to items 1 & 2 using item 5. M16 x 50mm Note: Use the double sided tape on the bottom HEX SCREW of the item 2 to fix the cover in place on item 1. DOUBLE SIDED TAPE Note: Position poles so the cable management holes... - Page 7 ASSEMBLE MOUNTING PLATE ONTO POLES i. Attach 4x item 7 to item 14 using items 9 & 10. M8 x 12mm Note: Ensure grub screws (item 11) are HEX SCREW SPRING WASHER positioned on the back of the collar (item 7). ii.
- Page 8 FIX INTERFACE ARMS TO SCREEN Fix items 15 to the back of the screen using the interface kit (items A-M). Note: Ensure the arms are facing the correct way round and the same holes are used on both arms. A - I SCREW INTERFACE WASHER...
- Page 9 MOUNT SCREEN ONTO STAND Hook screen onto item 14. SCREEN Note: If necessary, once mounted laterally adjust the screen by hand.
- Page 10 OPTIONAL SCREEN ADJUSTMENT If necessary, level the screen with the height adjustment screws at the top of item 15. OPTIONAL HEIGHT ADJUSTMENT SCREW SCREEN SECURE SCREEN TO STAND Lock screen onto item 14 using the safety screws on the bottom of item 15. SCREEN CABLE MANAGEMENT...
- Page 11 25mm 341.2mm SIDE VIEW VIEW 50.8mm 800mm SCREEN INTERFACE WITHOUT ADAPTORS 8.5mm 5.5mm 37mm Max. 455mm 500mm THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
- Page 12 ©2021 B-Tech International Design and Manufacturing Ltd. All rights reserved. B-Tech AV Mounts is a division of B-Tech International Design and Manufacturing Ltd. B-Tech AV Mounts and the B-Tech logo are registered trade marks. All other brands and product names are trademarks of their respective owners.
