4.2. Application of color palette

Color palette
Spectra
Iron
Cool
White
Black
As shown in the figure, press " MENU " key to enter the main menu
and select " " (color palette) option and press "
enter the color palette list. Press "
navigation to select the color palette. Then press " SELECT " key to
select the color palette. Press "
to exit from the menu.
www.xintest.com.cn
" key to
" and " " keys in
" to return. Press " MENU " key
25

5. Introduction to "emissivity" sub-menu

5.1. Emissivity description

The emissivity of the product can be adjusted from 0.01 to 1.00 with the
default value of 0.95. Many common objects and materials (such as
timber, water, skin and textile fabric) can reflect the heat energy
effectively. So it is easy to obtain relatively correct measurement value.
The emissivity is usually set as 0.95 when the coarse objects that are
easy to give out energy. For semi-matte objects that give out less energy,
the emissivity is usually about 0.85 and the emissivity of semi-gloss
objects is 0.6. The shiny objects are divided into materials with low
radiation coefficient. The emissivity is usually set as 0.3 at the time of
measurement. Correct setting of the value of emissivity is very important
for you to carry out the most correct temperature measurement. The
surface emissivity will produce giant impact on surface temperature
measured by the product. Understanding the surface emissivity will
enable you to obtain correct temperature measurement result.
