3."Video" sub-menu

3.1. View video

Press the " MENU " button to enter the main menu, and select "
(videos) in the main menu.
171229-105030
171229-105031
171229-105032
171229-105033
Press the " " key to enter the video list, press the "
keys in the navigation keys to select a video, and then press the
" SELECT " key to view the video.
When viewing a video, press the "
video, and press the " " button to view the next video. When
playing a video, press the "SELECT" button to pause playback, and
press the "SELECT" button again to resume playback.

3.2. Delete video

When viewing the video, press the "
"Delete video?" will appear on the screen. If you want to select "Yes" at
this time, please press the " MENU " key to confirm the deletion of the
video. If you want to choose "No", please press the " SELECT " button
to confirm not to delete the video
www.xintest.com.cn
"
" " "
" button to view the previous
" button, and the prompt
23

4. Introduction to "color palette" sub-menu

4.1. Color palette description

The palette can be used to change the pseudo-color display of the
infrared image on the display. Some tune Swatches are better
suited for specific applications and can be set up as needed. The
palette is divided into: rainbow, iron red, cool, white hot, black hot,
five palettes. These palettes work best with high thermal contrast
and provide additional color contrast between high and low
temperatures.
Suitable selection of color palette displays the details of the target
objective better. Rainbow, iron oxide red and cold color palettes
focus on display of color. Such color palettes are very suitable for
high heat contrast and are used to improve the color contrast
between high temperature and low temperature. But the black &
white and white & black color palettes provide even linear color.
The following is the image of the same object with selection of different
color palettes.
5 5
L L
Rainbow Iron oxide red Cold color
www.xintest.com.cn
24
5 5 5
L L
White heat Black heat
