I N S T A L L A T I O N
The CTA-2536 Dual Stud Wall Plate provides a
mounting solution for the following wall arms:
•
CTA-025 Single Stud Wall Arm
•
WMA-300 Wall Mount Arm
The CTA-2536 has a maximum weight capacity of
150 lbs. (68.0 kg).
BEFORE YOU BEGIN
•
CAUTION: To prevent damage to your equipment, which could affect or void the Factory warranty,
thoroughly study all instructions and illustrations before you begin to install the CTA-2536. Pay particular
attention to the Warnings and Cautions in this document.
•
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-582-6480.
CTA-2536
Internal Dual Stud Wall Plate
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE. 700
SAVAGE, MINNESOTA 55378 USA
I N S T R U C T I O N S
CTA-2536 Internal Dual Stud Wall Plate
8809-000028 (Rev. A)
2004 Chief Manufacturing
www.chiefmfg.com
11/04
Advertisement
Table of Contents
Related Manuals for CHIEF Internal Dual Stud Wall Plate CTA-2536
Summary of Contents for CHIEF Internal Dual Stud Wall Plate CTA-2536
-
Page 1: Before You Begin
CTA-2536. Pay particular attention to the Warnings and Cautions in this document. • If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-582-6480. CHIEF MANUFACTURING INC. 1-800-582-6480 952-894-6280 FAX 952-894-6918 8401 EAGLE CREEK PARKWAY, STE. -
Page 2: Important Warnings And Cautions
IMPORTANT WARNINGS AND CAUTIONS! WARNING A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions. -
Page 3: Table Of Contents
INSTALLATION The tools required for installation are as follows: • Electric drill and bit set • Stud sensor (mechanical or electronic) • ½” box-end wrench or ratchet with ½” socket • 13mm box-end wrench or ratchet with 13mm socket •... -
Page 4: Instructions
2. Determine a suitable mounting location. Keep in mind that the wall plate (10) must be mounted to wood studs that are 16” apart on center. 3. Using a stud sensor, locate the two wood studs where you will mount the wall plate (10). STEP 2 Installing the Wall Plate 1. -
Page 5: Attaching Wall Arm To Wall Plate
STEP 3 Attaching Wall Arm to Wall Plate 1. Locate the wall arm, six M8 flat washers (40), six M8 lock washers (50), and six M8 x 16mm button head screws (60). See Figure 3. 2. Attach wall arm to wall plate (10) as follows: a.
