CHIEF SSC Bracket SSC-1 Installation Instructions

I N S T A L L A T I O N
The SSC bracket is designed for adding additional security to installations. By installing the SSC, a locking
device can be placed to obscure access to fastening hardware.

Unpack and check contents

(Qty. 3) Bracket SSC-1 [up to 10-24 (M5)], SSC-2 [up to ¼" (M7)], or SSC-3 [from M7 to 5/16"(M8)]
1. Remove screw to be secured.
2. If screw to be secured is not a cap screw, replace existing screw with a cap screw.
3. Install bracket and secure using cap screw (see Figure 2).
4. Install locking device in bracket, making sure locking device is large enough to cover access to cap
screw (see Figure 3).
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
12800 HIGHWAY 13 SOUTH, SUITE 500
SAVAGE, MINNESOTA 55378 USA
BRACKET
SSC-1, SSC-2, SSC-3
:
(see Figure 1)
Figure 1.
Figure 2.
Figure 3.
I N S T R U C T I O N S
Lock not included
8802-000124
2003 Chief Manufacturing
www.chiefmfg.com
01/04
