- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Quick Connect/Disconnect Bracket Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description KSA-1024...
-
Page 2: Installation Instructions
Chief® and Centris™ are registered trademarks of Milestone Reinforce the structure as required before installing the AV Technologies. All rights reserved. - Page 3 Installation Instructions KSA-1024 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
- Page 4 KSA-1024 Installation Instructions TOOLS REQUIRED FOR INSTALLATION AND PARTS 5/32" (included) (security) B(1) C(1) M4 x 8mm 5/32" (included) (security) A(1) [Quick Connect/Disconnect Bracket] + Assembly kit G(4) D(4) E(4) H(4) F(4) M4 x 12mm M4 x 20mm 1/2 x .194 x 1/2"...
- Page 5 Installation Instructions KSA-1024 Assembly And Installation Attach Bracket to Centris Plate Make sure quick connect/disconnect bracket flag is in the Attach Quick Connect/Disconnect Bracket to open position. (See Figure 3) Display Place quick connect/disconnect bracket over Centris plate Lay display face side down on a level, non-abrasive making sure upper lip of bracket covers top of Centris plate.
- Page 6 KSA-1024 Installation Instructions Tighten thumbnut on bracket flag to secure bracket to Centris plate. (See Figure 5) Figure 5 Optional Security Screw Installation Use enclosed 5/32" security hex key (C) to install M4 x 8mm button head security screw (B) into security hole on bracket.
- Page 7 Installation Instructions KSA-1024...
