Autel MaxiPRO MP808BT Manual

Hide thumbs Also See for MaxiPRO MP808BT:
Table of Contents

Advertisement

Quick Links

Download this manual
Trademarks
®
®
Autel
, MaxiSys
®
MaxiPRO
are trademarks of Autel Intelligent Technology Corp., Ltd., registered
in China, the United States and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the
latest information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While
information of this manual has been carefully checked for accuracy, no guarantee
is given for the completeness and correctness of the contents, including but not
limited to the product specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or any
economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying
extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
support@autel.com
For technical assistance in all other markets, please contact your local selling
agent.
®
, MaxiPRO
, MaxiScan
®
, MaxiCheck
i
®
, MaxiRecorder
®
, and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MaxiPRO MP808BT and is the answer not in the manual?

Questions and answers

Related Manuals for Autel MaxiPRO MP808BT

Summary of Contents for Autel MaxiPRO MP808BT

  • Page 1 Autel will not be liable for any direct, special, incidental, indirect damages or any economic consequential damages (including the loss of profits).

  • Page 2: Safety Information

    Safety Instructions The safety messages herein cover situations Autel is aware of. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize your personal safety.
  • Page 3 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life. SAFETY WARNINGS Always perform automotive testing in a safe environment.

  • Page 4: Table Of Contents

    Safety Instructions ......................ii 1 Using This Manual ......................1 Conventions ........................1 2 General Introduction ......................3 MaxiPRO MP808BT Display Tablet ................4 VCI – Vehicle Communication Interface ..............8 Other Accessories ......................10 3 Getting Started ........................11 Powering Up .........................
  • Page 5 Language ........................78 Printing Setting ......................79 Notification Center ....................... 81 Auto Update ........................82 System Settings ......................83 About ..........................84 8 Update ..........................85 Tablet Update ....................... 85 MaxiVCI Mini Update ....................87 9 VCI Manager ........................88 BT Pairing ........................
  • Page 6 17 Maintenance and Service ....................123 Maintenance Instructions ..................123 Troubleshooting Checklist ..................124 About Battery Usage ....................124 Service Procedures ..................... 126 18 Compliance Information ....................129 19 Warranty ........................132 Limited One Year Warranty ..................132...

  • Page 7: Using This Manual

    Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may contain modules and optional equipment that are not included in your system. Contact your sales representative for availability of other modules and optional tools or accessories.
  • Page 8 Important IMPORTANT indicates a situation which, if not avoided, may result in damage to the test equipment or vehicle. Example: IMPORTANT Keep the cable away from heat, oil, sharp edges and moving parts. Replace damaged cables immediately. Hyperlink Hyperlinks, or links, that take you to other related articles, procedures, and illustrations are available in electronic documents.

  • Page 9: General Introduction

    DTCs for all available modules of the majority of the makes and models on the market, the MaxiPRO MP808BT is your ideal auto diagnostic and service tool. MP808BT provides you with superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery Management System), and DPF (Diesel Particulate Filter).

  • Page 10: Maxipro Mp808Bt Display Tablet

    MaxiPRO MP808BT Display Tablet Functional Description Figure 2-1 Display Tablet Front View 7.0” LCD Capacitive Touchscreen. Ambient Light Sensor – detects ambient brightness. Power LED – indicates battery level & charging or system status. Vehicle Communication LED – flashes green when the Display Tablet is communicating/linking with the vehicle’s system.
  • Page 11 Figure 2-2 Display Tablet Back View Collapsible Stand – extends from the back to allow hands-free viewing of the Display Tablet. Heat Sink MaxiVCI Mini Holder Built-in Battery Figure 2-3 Display Tablet Top View Mini USB OTG Port 10. Micro SD Card Slot – holds the micro SD card. 11.
  • Page 12  Internal Battery Pack  External Power Supply Internal Battery Pack The tablet can be powered with the internal rechargeable battery, which if fully charged can provide sufficient power for about 7 hours of continuous operation. External Power Supply The tablet can be powered from a wall socket using the USB charging cable and the USB external power adapter.
  • Page 13 Item Description  Input: N/A Audio input/output  Output: buzzer  3.7 V/5000 mAh lithium-polymer Power and Battery battery  Charges via 5 VDC power supply Tested Battery Life Around 7 hours of continuous use Battery Charging 5 V/1.5 A Input 600 mA (LCD on with default brightness, Power Consumption...

  • Page 14: Vci - Vehicle Communication Interface

    VCI – Vehicle Communication Interface The wireless diagnostic interface MaxiVCI Mini is a small vehicle communication interface (VCI) used to connect to a vehicle’s data link connector (DLC) and connect wirelessly with the tablet for vehicle data transmission. Functional Description Figure 2-4 MaxiVCI Mini Views Vehicle Data Connector (16-Pin) –...
  • Page 15 Table 2-3 Connection LED on the Front Panel Color Description  Lights solid green when the device is successfully connected via the USB cable but is not communicating with the vehicle. Green  Blinks green when device successfully connected via the USB cable and is communicating with the vehicle.

  • Page 16: Other Accessories

    Power Sources The MaxiVCI Mini operates on 12-volt vehicle power, which is received through the vehicle’s DLC. The unit powers on whenever it is connected to the vehicle’s DLC. Other Accessories MaxiVCI Mini Connects to the vehicle’s DLC and provides wireless connection between the tablet and the vehicle.

  • Page 17: Getting Started

    The power LED light will illuminate green. The system boots up and displays the lock screen. Slide the Lock icon to the left to enter the MaxiPRO Job Menu or slide to the right to unlock. Figure 3-1 Sample MaxiPRO MP808BT Job Menu Application Buttons Locator and Navigation Buttons...
  • Page 18 Accesses MaxiPRO system settings menu and Settings general tablet menu. See Settings on page 77. Checks for the latest update available for the Update MaxiPRO system, and performs updates. See Update on page 85. Launches Support platform which Support synchronizes Autel’s on-line service base...
  • Page 19 See Quick Link on page 119. Provides quick search for the supported Function functions and vehicles of Autel diagnostic tools. Viewer Function Viewer on page 120. Locator and Navigation Buttons Operations of the Navigation buttons at the bottom of the screen are...
  • Page 20 Button Name Description Android Returns to Android System’s Home screen. Home Displays a list of applications that are currently Recent in use. Tap an app icon to launch. To remove Apps an app, swipe it to the top or bottom. Chrome Launches the Android built-in browser.

  • Page 21: Powering Down

    Table 3-3 System Status Icons Button Name Description Calculator Launches calculator when pressed. Clock Launches clock when pressed. Enables/disables BT when pressed. Wi-Fi Enables/disables Wi-Fi when pressed. Airplane Enables/disables Airplane Mode when Mode pressed. System Launches the Android System Settings Settings screen when pressed.

  • Page 22: Diagnostics

    (ABS), airbag system (SRS). Establishing Vehicle Communication The Diagnostics operations require connecting the MaxiPRO MP808BT Diagnostic Platform to the test vehicle through the MaxiVCI Mini. To establish proper vehicle communication to the tablet, please perform the following steps: Connect the MaxiVCI Mini to the vehicle’s DLC for both communication...
  • Page 23 VCI Connection The MaxiVCI Mini Power LED will light solid green when properly connected to the vehicle and ready to establish communication with the tablet. The wireless diagnostic interface MaxiVCI Mini supports 2 communication methods with the tablet, wireless BT and USB. BT Connection BT pairing is recommended as the first choice for the communication between the tablet and the MaxiVCI Mini.

  • Page 24: Getting Started

     Check if the MaxiVCI Mini is properly positioned.  Check if the Connection LED on the MaxiVCI Mini is illuminated for BT or USB.  In case of BT connection, check if the network is configured correctly, or if the right MaxiVCI Mini has been paired up with the tablet. ...
  • Page 25 When the tablet device is properly connected to the vehicle, the platform is ready to start vehicle diagnosis. Tap on the Diagnostics application button on the MaxiPRO MP808BT Job Menu to access the Vehicle Menu. Figure 4-1 Sample Vehicle Menu...

  • Page 26: Vehicle Identification

    Button Name Description Europe Displays the European vehicle menu. Asia Displays the Asian vehicle menu. Search Searches for a specific vehicle make. Cancel Exits the search screen or cancels an operation. Vehicle Manufacturer Buttons To begin, select the manufacturer button of the test vehicle, followed by the vehicle mode and year.
  • Page 27 Figure 4-2 Sample Auto VIN Screen 3. Select Auto Detect. Once the test vehicle is identified, the screen will display the vehicle VIN. Tap OK at the bottom right to confirm the vehicle VIN. If the VIN does not match with the test vehicle’s VIN, enter VIN manually or tap Read to acquire VIN again.
  • Page 28 Figure 4-4 Sample Vehicle Profile Screen 5. The tool establishes communication with the vehicle and reads the control unit information. Choose Auto Scan to scan all the test vehicles’ available systems or tap Control Unit to access a specific system to diagnose. Figure 4-5 Sample Diagnostic Screen...
  • Page 29 Manual VIN Input For vehicles not supporting the Auto VIN Scan function, you may manually enter the vehicle VIN. To perform Manual VIN Input 1. Tap the Diagnostics application button from the MaxiPRO Job Menu. The Vehicle Menu displays. 2. Tap the VIN Scan button on the top toolbar to open the dropdown list. 3.
  • Page 30 Automatic Selection Figure 4-7 Sample Selection Screen The Auto VIN Scan can be selected after selecting the test vehicle manufacturer.  To perform Automatic Selection 1. Tap the Diagnostics application button from the MaxiPRO Job Menu. The Vehicle Menu displays. 2.

  • Page 31: Navigation

    Navigation Navigating the Diagnostics interface and selecting test are discussed in this section. Figure 4-8 Sample Diagnostics Screen Diagnostics Screen Layout The diagnostic screens typically include four sections. Diagnostics Toolbar Status Information Bar Main Section Functional Buttons Diagnostics Toolbar The Diagnostics Toolbar contains a number of buttons such as print and save.
  • Page 32 Table 4-2 Diagnostics Toolbar Buttons Button Name Description Home Returns to the MaxiPRO Job Menu. Vehicle Exits the service session of the currently identified Swap test vehicle and returns to the vehicle menu screen. Opens the settings screen. See Settings on page Settings for details.
  • Page 33 4. Tap the Send button to submit the report form via the Internet. A confirmation message displays when the report has been successful sent. Status Information Bar The Status Information Bar at the top of the Main Section displays the following items: Menu Title –...

  • Page 34: Diagnosis

    Warning Messages This type of messages displays a warning that a selected action may result in an irreversible change or loss of data. An example of this type of message is the “Erase Codes” message. Error Messages Error messages display when a system or procedural error has occurred. Examples of possible errors include a disconnection or communication interruption.
  • Page 35 Auto Scan The Auto Scan function performs a comprehensive scanning over all the ECUs in the vehicle’s ECU to locate systems faults and retrieve DTCs. An example of Auto Scan interface is pictured as below: Figure 4-9 Sample Auto Scan Operation Screen Navigation Bar Main Section Functional Buttons...
  • Page 36  Fault(s) | #: Fault(s) indicates there is/are detected fault code(s) present; “#” indicates the number of the detected faults.  Pass | No Fault: Indicates the system has passed the scanning process and no fault has been detected. Column 4 – to perform further diagnosis or testing on a specific system item, ○...
  • Page 37 Control Units Figure 4-10 Sample Function Menu Manually locate a required control system for testing through a series of choices. Follow the menu driven procedures and make proper selections; the application guides the user to the proper diagnostic function menu based on selections.
  • Page 38 4. Locate the required system for testing by Auto Scan or through menu driven selections in Control Units. 5. Select the desired diagnostic function from the Function Menu. ECU Information This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers and other specifications.
  • Page 39 Figure 4-12 Sample Read Codes Screen Diagnostics Toolbar Buttons – see Table 4- 2 Diagnostics Toolbar Buttons on page 26 for detailed descriptions of the operations for each button. Main Section Code Column – displays the retrieved codes from the vehicle. ...
  • Page 40  To erase codes 1. Tap Erase Codes from the Function Menu. 2. A warning message displays to advise of data loss if this function is completed. a) Tap Yes to continue. A confirming screen displays when the operation is successfully done. b) Tap No to exit.
  • Page 41 4- 2 Diagnostics Toolbar Buttons page 26 for detailed descriptions of the operations for each button. Main Section Name Column – displays the parameter names.  a) Check Box – tap the check box on the left side of the parameter name to make item selection.
  • Page 42 NOTE Status parameters, such as a switch reading, can primarily be viewed in text form such as ON, OFF, ACTIVE, and ABORT. Whereas, value parameter, such as a sensor reading, can be displayed in text mode and additional graph modes. 3) Waveform Graph Mode –...
  • Page 43 4. Select a desired sample color from the middle column. 5. Select a desired sample line thickness from the right column. 6. Repeat step 3-5 to edit the waveform for each parameter item. 7. Tap Done to save the setting and exit, or tap Cancel to exit without saving.
  • Page 44 Figure 4-14 Sample Setting Mode in Live Data There are four navigation buttons on top of the Setting mode screen. Selected Button – displays the configuration screen to set the threshold  values, an upper limit and a lower limit, for triggering the buzzer alarm.
  • Page 45 7. Tap Done to save the setting and return to the Live Data screen; or tap Cancel to exit without saving. If the threshold limits are successfully set, two horizontal lines will display on each of the data graphs (when Waveform Graph Mode is applied) to indicate the alarm point.

  • Page 46: Generic Obd Ii Operations

    6. Tap Done to save the setting and return to the Live Data screen; or tap Cancel to cancel without saving and exit Setting.  Done Button - confirms and saves the setting, and returns to the Live Data screen. Cancel Button –...
  • Page 47 3. Select a specific protocol under the Protocol option. Wait for the OBD II Diagnostic Menu to display. Figure 4-15 Sample OBD II Diagnostic Menu NOTE Tapping the button displayed beside the function name opens a bubble with additional function information. 4.
  • Page 48 Function Descriptions This section describes the various functions of each diagnostic option: DTC & FFD Figure 4-16 Sample DTC & FFD Screen When this function is selected, the screen displays a list of Stored and Pending Codes. A snowflake button will display on the right side of the DTC item when the Freeze Frame data is available for viewing.
  • Page 49 a) If a test failed during the drive cycle, the DTC associated with that test is reported. If the pending fault does not occur again within 40 to 80 warm-up cycles, the fault is automatically cleared from memory. b) Test results reported by this service do not necessarily indicate a faulty component or system.

  • Page 50: Exiting Diagnostics

    Live data can be displayed in various modes, see Live Data on page detailed information. On-Board Monitor Use this option to view the results of On-Board Monitor tests. The tests are useful after servicing or after erasing a vehicle’s control module memory. Component Test This service enables bi-directional control of the ECM so that the diagnostic tool is able to transmit control commands to operate the vehicle systems.
  • Page 51 1. From an active diagnostic screen, tap the Back or ESC functional button to exit a diagnostic session step-by-step. 2. Or tap the Vehicle Swap button on the diagnostics toolbar to return to the Vehicle Menu screen. 3. From the Vehicle Menu screen, tap the Home button on the top toolbar;...

  • Page 52: Service

    Service The Service section is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu driven executive commands. Follow on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.
  • Page 53 NOTE All required work must be carried out before the service indicators are reset. Failure to do so may result in incorrect service values and cause DTCs to be stored by the relevant control module. NOTE For some vehicles, the scan tool can reset additional service lights such as maintenance cycle and service interval.
  • Page 54 5. Tap CBS vehicle date correction on the Oil Reset function list to start the operation. The screen will display the date and time and ask for confirmation. If the displayed date and time are correct, tap Yes to confirm. If not, tap No and go to the Settings menu to set the correct date and time.
  • Page 55 8. The tool will display a function list menu as below. Press the corresponding number button to perform the desired function. Tap ESC to exit. Figure 5-4 Sample Oil Reset Service Screen 3 9. When the reset is done, the screen will display “Service function finished”.

  • Page 56: Electronic Parking Brake (Epb) Service

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electronic Parking Brake system. To perform EPB functions 1. Tap the Service application button from the MaxiPRO Job Menu.
  • Page 57 Figure 5-6 Sample EPB Function List 4. Follow the step-by-step on-screen instruction to complete the service. Using Parking brake: Initial operation as an example. 5. Press ESC button to exit. Parking brake: Initial operation This service function would start up the parking brake. It must be conducted after the following operation: •...
  • Page 58 Screen 1 Tap Yes to proceed with this service function or the No button at the bottom left to exit. When the operation is successfully completed, a “Completed successfully” message will display on the screen, press Continue to exit. Figure 5-8 Sample Parking brake: Initial operation Screen 2...

  • Page 59: Battery Management System (Bms) Service

    Battery Management System (BMS) Service The Battery Management System (BMS) allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle. NOTE This function is not supported by all vehicles. The screens shown in this section are examples.
  • Page 60 2. Tap BMS button and wait for the vehicle manufacturer screen. You can tap VIN Scan or the vehicle make to acquire vehicle VIN information and tap Yes to confirm. See Vehicle Identification on page for detail. 3. Tap Register battery exchange in the Battery function list. The list may vary by test vehicle.
  • Page 61 F2 Enter battery replacement: Higher/lower capacity F3 Enter battery replacement: Changing from the normal lead-acid battery (white housing) to AGM battery (black housing) ESC End service function. Figure 5-11 Sample BMS Screen 2 Take the second function as an example. Figure 5-12 Sample BMS Screen 3 6.

  • Page 62: Steering Angle Sensor (Sas) Service

    Figure 5-13 Sample BMS Screen 4 8. When the battery exchange is successfully entered, tap Continue to complete the operation. Figure 5-14 Sample BMS Screen 5 Steering Angle Sensor (SAS) Service Steering Angle Sensor Calibration permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM.
  • Page 63 NOTE AUTEL accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair.
  • Page 64 Figure 5-15 Sample SAS Function Menu Steering Angle Sensor adjustment This function allows users to perform steering angle sensor calibration and clear records. The function options vary by vehicles. Tap Steering Angle Sensor adjustment from the SAS function menu to enter the function screen. The steering angle must be calibrated after following jobs: -Replacement of steering column switch cluster -Encoding of DSC control unit...
  • Page 65 The run flat indicator must be additionally initialized after adjusting the steering angle sensor on completion of the following work: -Encoding of DSC control unit -Replacement of DSC control unit Tap continue to proceed. Figure 5-17 Sample SAS Function Screen 2 Read the complete information carefully and tap Yes to the next step, tap No to exit.
  • Page 66 Follow the step-by-step on-screen instruction to continue. Figure 5-19 Sample SAS Function Screen 4 Read the complete information carefully and tap Yes to end the test module or tap No to continue. Figure 5-20 Sample SAS Function Screen 5...
  • Page 67 Exactly set front wheels to straight-ahead position. The steering wheel must be positioned horizontally. Tap Continue to the next step. Figure 5-21 Sample SAS Function Screen 6 Read the attention carefully and tap Continue to the next step. Figure 5-22 Sample SAS Function Screen 7...
  • Page 68 The adjustment procedure is started in this step, please wait until the “Adjustment was successful” message displayed. Tap Continue to proceed. Figure 5-23 Sample SAS Function Screen 8 10) Confirm the degrees of the steering angle and then tap Yes to continue. Figure 5-24 Sample SAS Function Screen 9...
  • Page 69 11) Adjustment of the steering angle was carried out correctly. Tap Continue to end the test module. Figure 5-25 Sample SAS Function Screen 10...

  • Page 70: Diesel Particle Filter (Dpf) Service

    Diesel Particle Filter (DPF) Service The Diesel Particle Filter (DPF) function manages DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit. The ECM monitors driving style and selects a suitable time to employ regeneration. Cars driven a lot at idling speed and low load will attempt to regenerate earlier than cars driven more with high load and speed.
  • Page 71 the vehicle while the other person observes the screen on the Tool. Do not attempt to drive and observe the scan tool at the same time. This is dangerous and puts your life and the lives of other motors and pedestrians at risk.
  • Page 72 Read the Note carefully and tap Continue to the next step. Figure 5-27 Sample DPF Function Screen 1 A series of instruction screens display for users to perform the Request regeneration step by step. Figure 5-28 Sample DPF Function Screen 2...
  • Page 73 The particulate filter can only be regenerated by driving the vehicle and it requires approximately 45 minutes. Tap Continue to the next step. Figure 5-29 Sample DPF Function Screen 3 The tool will display a function list menu as below. Press the corresponding number button to perform the desired function.
  • Page 74 When perform successfully, a “Regeneration was successfully requested” message will display on the screen. Tap Continue to the next step. Figure 5-31 Sample DPF Function Screen 5 Switch off the ignition and tap Continue to the next step. Figure 5-32 Sample DPF Function Screen 6...
  • Page 75 Turn on ignition again and start engine. Read the notes on the screen carefully and then tap Continue to the next step. Figure 5-33 Sample DPF Function Screen 7 Read the information carefully and then tap Continue to the next step. Figure 5-34 Sample DPF Function Screen 8...
  • Page 76 10. The current regeneration status is shown in the following step. Read the information carefully and then tap Continue to the next step. Figure 5-35 Sample DPF Function Screen 9 11. A series of instruction screens display for users to perform the particle filter regeneration step by step.
  • Page 77 12. Tap F1 to continue display the status of current regeneration or tap ESC to exit. Figure 5-37 Sample DPF Function Screen 10...

  • Page 78: Data Manager

    Data Manager The Data Manager application is used to store, print, and review the saved files. Most operations are controlled through the toolbar. Selecting the Data Manager application opens the file system menu. Different file types are sorted separately under different options, there are five types of information files to be viewed or played back.
  • Page 79 Figure 6-2 Sample Image Screen Toolbar Buttons – used to edit, print and delete the image files. See the following table for detailed information. Main Section – displays the stored images. Table 6-1 Toolbar Buttons in Image Screen Button Name Description Back Returns to the previous screen.
  • Page 80 > Support > Downloads > Autel Update Tools, and install to your windows-PC. The Maxi PC Suite consists of Autel Printer, MaxiSys Pinter and PC Suite. 2. Double click on Setup.exe item. 3. Select the installation language and the printer driver installation wizard will load momentarily.
  • Page 81 4. Select the images that need to be deleted by tapping the thumbnail images, the selected thumbnail displays a tick icon at the bottom right corner. 5. Tap the Delete button, and then Delete Selected, then the selected images will be deleted. PDF Files The PDF section stores and displays all saved data PDF files.
  • Page 82 Use the Navigation Toolbar buttons to playback the record data from frame to frame. Tap Back to exit data playback. Apps Uninstall This section manages the firmware applications installed on the MaxiPRO Diagnostics System. Select this section to open a management screen, on which you all the available vehicle diagnostic application can be reviewed.

  • Page 83: Settings

    Settings Tap the Settings button to adjust the default setting and view information about the MaxiPRO system. There are seven options available for the MaxiPRO system settings:  Unit  Language  Printing Setting  Notification Center  Auto Update ...

  • Page 84: Language

    Figure 7-1 Sample Unit Setting Screen Language This option allows you to adjust the display language for the MaxiPRO system.  To adjust the language setting 1. Tap the Settings application on the MaxiPRO Job Menu. 2. Tap the Language option on the left column. Figure 7-2 Sample Language Setting Screen 3.

  • Page 85: Printing Setting

    Printing Setting Configure this option to enable the tablet to print through a specified Wi-Fi network connection.  To setup the printer connection 1. Tap the Settings application on the MaxiPRO Job Menu. 2. Tap the Printing Setting option on the left column. 3.
  • Page 86  To install the printer driver program to a computer 1. Download the Maxi PC Suite from www.autel.com and install to your windows-PC. 2. Double click on Setup.exe item. 3. Select the installation language and the wizard will load momentarily.

  • Page 87: Notification Center

    Notification Center This option allows you to turn the Notification Center function on or off. The Notification Center function configures the MaxiPRO tablet to receive regular on-line messages from the server for system update notifications or other service information via the Internet. It is highly recommended to keep this function ON all the time, to ensure notifications of updates are received.

  • Page 88: Auto Update

    Auto Update The Auto Update allows the tool to automatically update the OS, the MaxiPRO system, and the Vehicle coverage software. Each can be configured to update automatically at specified times. Tap the ON/OFF button and set the desired automatic update time. ...

  • Page 89: System Settings

    NOTE The tool must be connected to the Internet at the time download is scheduled. To connect the MaxiVCI Mini to the test vehicle, simply insert the Vehicle Data Connector on the MaxiVCI Mini into the vehicle’s DLC which is generally located under the vehicle dash and the MaxiVCI Mini will be automatically powered on.

  • Page 90: About

     Long press a specific app shortcut button to display the app menu. The shortcut can be altered here.  Press and drag the App Switcher icon to alter the icon position on the screen. Refer to Android documentation for additional information about Android system settings.

  • Page 91: Update

    Update This chapter describes the update operation for both the MP808BT tablet and the MaxiVCI Mini. The software and firmware updates of the tablet can be completed on the tablet via Internet, while the updates for MaxiVCI Mini can be completed either via the connection with the tablet or via the connection with a PC.
  • Page 92 Navigation and Controls Home Button – returns to the MaxiPRO Job Menu.  Update All – updates all available updates.  Diagnostics Tab – displays all available vehicle diagnostic software.  Search Bar – search specific update item by inputting the file name, ...

  • Page 93: Maxivci Mini Update

    Down the Maxi PC Suite from www.autel.com > Support > Downloads > Autel Update Tools, and install it onto your windows-PC. Using a USB cable, connect the MaxiVCI Mini to a PC. Launch the PC Suite on the PC which is installed after the installation of Maxi PC Suite and click MaxiVCI Mini icon in the Device Selection window.

  • Page 94: Vci Manager

    VCI Manager This application pairs the tablet with the MaxiVCI Mini, checks the communication status and update the VCI software. Figure 9-1 Sample VCI Manager Screen Connection Mode – there are three connection modes available for selection. The connection state is displayed alongside. ...

  • Page 95: Update

     To pair the MaxiVCI Mini with the Tablet Power on the tablet. Insert the 16-pin vehicle data connector of the MaxiVCI Mini to the vehicle data link connector (DLC). Tap the VCI Manager application on the MaxiPRO Job Menu of the tablet.

  • Page 96: Shop Manager

    Shop Manager The Shop Manager application manages the workshop information, customer information records, and test vehicle history records. There are three main functions available:  Vehicle History  Workshop Information  Customer Manager The operations of these functions of the Shop Manager application are mainly manipulated by the toolbar buttons, which are listed and described in the table below: Table 10-1 Top Toolbar Buttons in Shop Manager...

  • Page 97: Vehicle History

    Button Name Description Vehicle Displays Vehicle History which History corresponding test vehicle records. Done Completes editing and saves the file. Vehicle History This function stores test vehicle history records, including vehicle information and the retrieved DTCs from previous diagnostic sessions. All information is displayed in summarized details.
  • Page 98 6. The vehicle’s Diagnostics screen displays. Now a new diagnostic session is activated, see Diagnostics on page for detailed instructions on vehicle diagnostic operations. Historical Test Record The Historical Test record sheet is a detailed data form that includes general vehicle information such as vehicle year, make and model.

  • Page 99: Workshop Information

    NOTE The vehicle VIN number, or license and the customer information account are correlated by default. Adding one of the information will automatically associate the other item in the record sheet, provided that the later one exists. 6. Tap Add to Customer to supplement the Historical Test record sheet to an existing customer account, or add a new associated account with the test vehicle record.

  • Page 100: Customer Manager

    5. Tap Done to save the updated workshop information sheet, or tap Cancel to exit without saving. Customer Manager Use the Customer Manager function to create and edit customer accounts and correlate with the associated test vehicle history records.  To create a customer account 1.
  • Page 101  To delete a customer account 1. Tap the Shop Manager application on the MaxiPRO Job Menu. 2. Select Customer Manager and select a customer account by tapping the corresponding name card. A Customer Information sheet displays. 3. Tap the Edit button on the top toolbar to start editing. 4.
  • Page 102 1. Functional Buttons – navigates and makes various controls of the function. 2. Main Section – displays the note list on the left column and the detail information of the selected note on the right column. Table 10-2 Function Buttons in History Notes Button Name Description...

  • Page 103: Academy

    Academy Autel provides various tutorial articles and technical bulletins produced by top-notch technicians and product experts. Please view the materials that are saved on the tablet or view technical articles from our online forum by clicking the links displayed under this application.

  • Page 104: Remote Desk

    The Remote Desk application launches the TeamViewer Quick Support program, which is a simple, fast and secure remote control screen. You can use the application to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your MaxiPRO tablet on their PC via the TeamViewer software.
  • Page 105 3. Your partner must install the Remote Control software to his/her computer by downloading the TeamViewer full version program online (http://www.teamviewer.com), and then start the software on his/her computer at the same time, in order to provide support and take control of the tablet remotely. 4.

  • Page 106: Maxifix

    MaxiFix The MaxiFix application launches the on-line troubleshooter database, which not only provides you virtually all common diagnostic trouble code (DTC) database for most vehicles, but also serves as a forum allowing you to network with other MaxiPRO users, and gives you access to a vast database of repair and diagnostic tips along with proven filed fixes.
  • Page 107 The Main Screen – located at the center of the screen displaying content based on the vehicle attributes and keywords specified. The tabs on the main screen vary in accordance with the section selected on the Navigation Menu, allowing you to switch between functions. The Navigation Menu –...
  • Page 108 After completing the vehicle selection procedure, the identified vehicle is shown on the Header. Terminology MaxiFix Tip A MaxiFix Tip provides practical information of real fix of a specific vehicle repair issue with detailed descriptions. It is combined with proven fix and vehicle specific data, and filed into an all-in-one information source to provide you with quick and easy repair solutions.

  • Page 109: Operations

    b) Real Fix Tips – provides repair tips from actual shop practices and are presented in an easy to understand Complaint, Cause, Correction format. If you still can’t find the information you want, you can ask the MaxiFix community for help by clicking Ask on the Navigation Menu at the bottom of the screen.
  • Page 110 Home Home is the first option on the Navigation Menu at the bottom of the screen. Tapping it opens your MaxiFix home page. There is a list of questions posted on the community, and you can scroll down the page to the bottom and view more questions by tapping View More.
  • Page 111 2. Click Ask on the Navigation Menu at the bottom of the screen to open the Ask page. 3. On the Ask page find Ask for Help, fill in the following sections to ask a question. The Ask page has four sections: Subject –...
  • Page 112 My Profile – allows you to view your Autel account information including:  your Autel ID, personal information, MaxiFix score, phone number and register time, and edit your portrait. Vehicle Preference –used to set up a list of preferred vehicles. The ...
  • Page 113 View Profile Information You can view your personal profile by clicking on your account ID or “My Profile” in My MaxiFix section or edit portrait where applicable, and visit other community members’ profile by clicking their portrait. Information included in your profile determines how you are presented to the community, and what type of information will be sent to you from the community.
  • Page 114  Answers can only be rated by the MaxiFix member who asked the question. Close a Question When a repair question that you've posted to the community is resolved, you are encouraged to write down the case as a way to share a good solution. This will help the other MaxiFix members to find useful information for practical fix.
  • Page 115 window. To allow the administrator to respond to your question or issue, the following information should be provided:  Your name  A contact email address  A contact phone number...

  • Page 116: Support

    2. If you already have an Autel account, sign in with your account ID and password. 3. If you are a new member to Autel, click on the Create Autel ID button on the left side of the screen to create an ID.

  • Page 117: Support Screen Layout

    Support Screen Layout The Support application interface is navigated via four simple buttons on the top navigation bar, operation of each is described below in turn from left to right: Home Button – returns to the MaxiPRO Job Menu.  Back –...

  • Page 118: User Complaint

     User Info - displays detailed information of your registered on-line Autel account, such as your Autel ID, Name, Address and other contact information, etc. Device Info – displays the registered product information, including the  Serial Number, Registration Date, Expire Date, and Warranty Period.
  • Page 119 Period Filter – displays only the complaint records within the defined  period on the list. Status Filter – displays the corresponding complaint records  according to the selected case status. New Complaint Button – starts a new complaint case. ...

  • Page 120: Data Logging

    7. Select the required processing time on the last section according to the urgency of the case. 8. Tap Submit to send the completed form to Autel’s online service center, or tap Reset to refill it. The submitted complaints will be carefully read and handled by the service personnel, and the respond speed may depend on the processing time you’ve required.

  • Page 121: Communities

    The Communities section launches and synchronizes with the Technical Forums on Autel’s official website www.autel.com, where you are allowed to discuss technical topics or share information with, as well as ask for technical advices or offer technical supports to all other members in Autel’s online support communities.
  • Page 122 Figure 14-4 Sample Communities Home Screen  To start a discussion 1. Tap Start a discussion on the Communities Home screen. A list of the major forums is displayed. 2. Select the appropriate device heading. For example, if you are going to ask a question about the MaxiPRO tablet, tap MaxiPRO to start a discussion.

  • Page 123: Training Channels

    Stuff – displays all the discussions you’ve posted at various forums in a list.  Training Channels The Training section provides quick links to Autel’s online video accounts. Select a video channel by the language to see all the available online tutorial videos from Autel for various technical supports, such as product usage...

  • Page 124: Faq Database

    The FAQ section provides you comprehensive references for questions frequently asked and answered about the use of Autel’s online member account, and shopping and payment procedures. Account – displays questions and answers about the use of Autel’s online  user account.

  • Page 125: Quick Link

    Quick Link The Quick Link application provides convenient access to Autel’s official website and to additional in automotive service sites. Figure 15-1 Sample Quick Link Screen  To open a quick link 1. Tap the Quick Link application on the MaxiPRO Job Menu. The Quick Link application screen displays.

  • Page 126: Function Viewer

    Function Viewer The Function Viewer allows you to search the functions supported by our tools and the software version information. There are two ways of searching, either by searching the tool and the vehicle or searching the functions.  To Search by the vehicle 1.
  • Page 127 Figure 16-2 Sample Function Viewer Screen 2  Search by the functions 1. Tap the Function Viewer application on the MaxiPRO Job Menu. The Function Viewer application screen displays. 2. Tap the tool name on the top left to drop down the tool list, tap the one you want to search.
  • Page 128 Figure 16-3 Sample Function Viewer Screen 3...

  • Page 129: Maintenance And Service

    Maintenance and Service Maintenance Instructions Follow these guidelines to maintain your tool and ensure its optimum performance.  Use a soft cloth and alcohol or a mild window cleaner to clean the touch screen of the tablet.  Do not use any abrasive cleansers, detergent, or automotive chemicals to the tablet.

  • Page 130: Troubleshooting Checklist

    Your device may have not been connected to the charger properly. Check the connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to...
  • Page 131 DANGER The built-in Lithium-ion Polymer battery is factory replaceable only; incorrect replacement or tampering with the battery pack may cause an explosion. Do not use a damaged battery charger.  Do not disassemble or open crush, bend or deform, puncture or shred. ...

  • Page 132: Service Procedures

    Email: support@autel.com  Address: 7th, 8th, 10th floor, Building B1, Zhiyuan, Xueyuan Road, Xili, Nanshan, Shenzhen, 518055, China AUTEL NORTH AMERICA  Phone: 855-AUTEL-US (855-288-3587) Monday-Friday 9am-6pm EST  Website: www.autel.com  Email: ussupport@autel.com  Address: Suite 200, 175 Central Avenue, Farmingdale, New York, USA.
  • Page 133 Address: 155 Islington Street, Melbourne, Collingwood, VIC Repair Service If it becomes necessary to return your device for repair, please contact us first and then download the repair service form from www.autel.com, and fill it in. The following information must be included: ...
  • Page 134 Your purchase order should include the following information:  Contact information  Product or part name  Item description  Purchase quantity...

  • Page 135: Compliance Information

    Compliance Information FCC Compliance FCC ID: WQ8-1610MX808 This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 136 -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 137 CE COMPLIANCE This product is declared to conform to the essential requirements of the following Directives and carries the CE mark accordingly: EMC Directive 2014/30/EU R&TTE Directive 2014/53/EU Low Voltage Directive 2014/35/EU...

  • Page 138: Warranty

    Warranty Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiPRO Diagnostic Device that should this product or any part thereof during normal usage and under normal conditions be proven defective in material or workmanship and results in product failure...
  • Page 139 IMPORTANT All contents of the product may be deleted during the process of repair. You should create a back-up copy of any contents of your product before delivering the product for warranty service.

Table of Contents
