Speaker assembly

Description
Speaker assembly
Before removing the speaker assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
5.
Remove the following components:
a.
Bottom door (see
b.
Hard drive (see
c.
Optical drive (see
d. WLAN module (see
e. WWAN module (see
f. Fan (see
g. Heat sink (see
h. Keyboard (see
i.
Bottom cover (see
Remove the speaker assembly:
1.
Position the bottom cover with the front toward you.
2. Remove the two Phillips PM2.0×3.0 screws (1) that secure the speaker assembly to the bottom
cover.
Battery on page
Bottom door on page
Hard drive on page
Optical drive on page
WLAN module on page
WWAN module on page
Fan on page 87)
Heat sink on page
Keyboard on page
Bottom cover on page
60).
66).
71)
67)
78)
76)
89)
95)
97)
Component replacement procedures
Spare part number
641186-001
101
